VALOR GAS FIRE
FLAMENCO - (Overview)
Appliance Code: 32-810-56

Appliance Diagram


Overview diagram for Valor Gas Fire FlamencoClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE OUTER BACK RIVETED A
Valor Gas Fire part no. 0507769

2   OBSOLETE HEAT EXCH UNIT ASSY
Valor Gas Fire part no. 0504729

3   OBSOLETE LH HEAT EX/OUTER BACK
Valor Gas Fire part no. 0504739

4   OBSOLETE RH HEAT EX/OUTER BACK
Valor Gas Fire part no. 0504749

6   OBSOLETE HT EX/FIREBOX BRKT
Valor Gas Fire part no. 0504759

7   OBSOLETE NO.8X1/2 POZI PAN BLACK SCREW
Valor Gas Fire part no. 0548989

8   OBSOLETE GASKET
Valor Gas Fire part no. 0504769

10   OBSOLETE SCREW
Valor Gas Fire part no. 0513059

11   OBSOLETE FLUE BAFFLE ASSY
Valor Gas Fire part no. 0507779

12   OBSOLETE EARTH LEAD ASSY
Valor Gas Fire part no. 0504779

13   OBSOLETE NO8X3/8 SELF TAP SCREW
Valor Gas Fire part no. 0536809

14   OBSOLETE RH TOP WALL MTG BRKT
Valor Gas Fire part no. 0507789

15   OBSOLETE LH TOP WALL MTG BRKT
Valor Gas Fire part no. 0507799

17   OBSOLETE TAP FIXING BRKT
Valor Gas Fire part no. 0504789

18   OBSOLETE GAS TAP
Valor Gas Fire part no. 0504799

19   OBSOLETE CONTROL SPINDLE ADAPTER
Valor Gas Fire part no. 0516669

20   OBSOLETE COTTER PIN
Valor Gas Fire part no. 0528389

21   OBSOLETE CONTROL SPINDLE
Valor Gas Fire part no. 0504809

22   OBSOLETE TENSION 160/180 PIN
Valor Gas Fire part no. 0516679

23   LOCK NUT
Valor Gas Fire part no. 0502739
25   OBSOLETE RH FOOT & RIVNUT ASSY
Valor Gas Fire part no. 0507809

26   OBSOLETE LH FOOT & RIVNUT ASSY
Valor Gas Fire part no. 0507819

27   OBSOLETE LEVELLING SCREW
Valor Gas Fire part no. 0535979

28   OBSOLETE NUT
Valor Gas Fire part no. 0532259

29   OBSOLETE AIR GUIDE TRAY
Valor Gas Fire part no. 0505319

31   OBSOLETE BOTTOM WALL MTG BRKT
Valor Gas Fire part no. 0507829

32   M4X12 POZI PAN TT CH/B
Valor Gas Fire part no. 0552839
33   OBSOLETE FIREBOX WELDED ASSY
Valor Gas Fire part no. 0504839

34   OBSOLETE FIREBOX LOCATION BRKT
Valor Gas Fire part no. 0504849

35   OBSOLETE FIREBOX EXTENSION
Valor Gas Fire part no. 0504859

36   OBSOLETE SCREW
Valor Gas Fire part no. 0534729

37   OBSOLETE IGNITION REPLACEMENT K
Valor Gas Fire part no. 0507689

38   OBSOLETE SPARK & EARTH ELECTRODE ASSY
Valor Gas Fire part no. 0504869

39 Part number 0504879, OBSOLETE THERMOCOUPLE OBSOLETE THERMOCOUPLE
Valor Gas Fire part no. 0504879

41   OBSOLETE FIREBOX FRONT TOP PLATE ASSY
Valor Gas Fire part no. 0504889

42   OBSOLETE M5 STUD
Valor Gas Fire part no. 0549319

43   OBSOLETE WINDOW SEAL 463
Valor Gas Fire part no. 0504899

44   OBSOLETE STAPLE
Valor Gas Fire part no. 0504909

45   OBSOLETE TOP FRONT PLATE GASKET
Valor Gas Fire part no. 0504919

46   OBSOLETE FRONT TOP PLATE SIDE GASKET
Valor Gas Fire part no. 0504929

48   OBSOLETE RH REAR CASE SIDE EXT
Valor Gas Fire part no. 0507889

49   OBSOLETE LH REAR CASE SIDE EXT
Valor Gas Fire part no. 0507899

50   OBSOLETE NO.6X3/8 PAN POZI ZPS
Valor Gas Fire part no. 0514929

51   OBSOLETE BURNER BOX UNIT ASSY
Valor Gas Fire part no. 0504939

51   OBSOLETE SILENCER SERVICE KIT
Valor Gas Fire part no. 11298300

52   OBSOLETE INJECTOR CARRIER
Valor Gas Fire part no. 81180000

53   OBSOLETE INJECTOR SPECIAL
Valor Gas Fire part no. 81180100

53   INJECTOR
Valor Gas Fire part no. 0504949
55   OBSOLETE FRONT FUEL SUPPORT ASSY
Valor Gas Fire part no. 0504959

57   OBSOLETE FLAME BUR. REST/TOR
Valor Gas Fire part no. 0548579

58   OBSOLETE PIPE ASSY - TAP/FLAME BNR
Valor Gas Fire part no. 0504969

59   OBSOLETE PIPE ASSY TAP/FRONT INJ
Valor Gas Fire part no. 0504979

60   OBSOLETE PIPE ASSY - TAP/REAR INJ
Valor Gas Fire part no. 0504989

61   OBSOLETE INLET PIPE ASSY
Valor Gas Fire part no. 0507839

62   OBSOLETE INLET PIPE RETAINING
Valor Gas Fire part no. 0517199

64   OBSOLETE F.E BNR ASSY
Valor Gas Fire part no. 0505009

65   OBSOLETE M3.X 6 SCREW
Valor Gas Fire part no. 0547299

66 Part number 0532519, ELBOW ELBOW
Valor Gas Fire part no. 0532519
67   OBSOLETE COAL BED
Valor Gas Fire part no. 0505019

68 Part number 0505029, OBSOLETE WINDOW UNIT ASSY 460 OBSOLETE WINDOW UNIT ASSY 460
Valor Gas Fire part no. 0505029

69 Part number 0533249, OBSOLETE WING NUT OBSOLETE WING NUT
Valor Gas Fire part no. 0533249

69 Part number 636102, OBSOLETE NUT WING M5 SN OBSOLETE NUT WING M5 SN
Valor Gas Fire part no. 636102

70   OBSOLETE REAR CASE WELDED ASSY
Valor Gas Fire part no. 0507419

72   OBSOLETE NO.6AB X 5/8 PZ PN BL
Valor Gas Fire part no. 0557389

73   OBSOLETE BEZEL INSULATION
Valor Gas Fire part no. 0557249

74 Part number 0505049, OBSOLETE CONTROL KNOB OBSOLETE CONTROL KNOB
Valor Gas Fire part no. 0505049

75   OBSOLETE CONTROLS BEZEL
Valor Gas Fire part no. 0557259

76   OBSOLETE BUTTON
Valor Gas Fire part no. 0516819

77 Part number 0507669, PIEZO IGNITOR UNIT PIEZO IGNITOR UNIT
Valor Gas Fire part no. 0507669

78   OBSOLETE INSULATION SLEEVE
Valor Gas Fire part no. 0505279

78   OBSOLETE ELECTRODE LEAD
Valor Gas Fire part no. 0505069

79   OBSOLETE EDGE REF:22440-07CLI
Valor Gas Fire part no. 0549519

80   OBSOLETE CABLE/PIPE CLIP (EDGE TYPE) - SPRING
Valor Gas Fire part no. 080160179

80   OBSOLETE EDGE CLIP
Valor Gas Fire part no. 0507679

81   OBSOLETE FRONT CAS 460/4
Valor Gas Fire part no. 0505079

82   OBSOLETE M5 STUD
Valor Gas Fire part no. 0557569

83   OBSOLETE CASE FRONT HEATSHIELD
Valor Gas Fire part no. 0505089

84   OBSOLETE LOWER GRILLE & BADGE ASSY
Valor Gas Fire part no. 0507849

86   OBSOLETE UPPER GRILLE
Valor Gas Fire part no. 0505119

88   OBSOLETE DECORATIVE KNOB
Valor Gas Fire part no. 0517679

89   OBSOLETE M4X10 POZI PAN ZP SCR
Valor Gas Fire part no. 0549219

90   OBSOLETE RH SIDE WINDOW TRIM
Valor Gas Fire part no. 0505129

91   OBSOLETE LH SIDE WINDOW TRIM
Valor Gas Fire part no. 0505139

92   OBSOLETE TIE TRIM
Valor Gas Fire part no. 0505149

94   OBSOLETE TOP WINDOW TRIM
Valor Gas Fire part no. 0505159

95   OBSOLETE WINDOW TRIM
Valor Gas Fire part no. 0505169

97   OBSOLETE HORIZONTAL CASE TRIM
Valor Gas Fire part no. 0505179

98   OBSOLETE NO.6X1/4 A/B PN PZ SC
Valor Gas Fire part no. 0557909

99   OBSOLETE KNURLED THUMB NUT
Valor Gas Fire part no. 0514679

100   OBSOLETE .8MM BLACK FIBRE WASHER
Valor Gas Fire part no. 0549419

102   OBSOLETE CLOSURE PLATE
Valor Gas Fire part no. 0507429

103   8X3/8 SCREW
Valor Gas Fire part no. 0511569
103   OBSOLETE FLUE SPIGOT
Valor Gas Fire part no. 0507879

104   OBSOLETE 12X2 RD HD SLOT ZP WD/SCREW
Valor Gas Fire part no. 0549759

105   OBSOLETE NO.12 HEAVY DUTY WALL PLUG
Valor Gas Fire part no. 0516879

106   OBSOLETE USERS INSTRUCTIONS
Valor Gas Fire part no. 0507869

107   OBSOLETE INSTALLATION INSTRUCTIONS
Valor Gas Fire part no. 0507859
