VALOR GAS FIRE
FIRELITE PLUS (BROWN CASE) MODEL NO.328 - (Controls)
Appliance Code: 32-811-36

Appliance Diagram


Controls diagram for Valor Gas Fire Firelite Plus (Brown Case) Model No.328Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE INSTALLERS INSTRUCTIONS
Valor Gas Fire part no. 0544839

0   OBSOLETE USERS INSTRUCTIONS
Valor Gas Fire part no. 0544849

1   OBSOLETE CASING UNIT ASSY - BLACK
Valor Gas Fire part no. 0544859

1   OBSOLETE CASING UNIT ASS - BROWN
Valor Gas Fire part no. 0544809

2   OBSOLETE SUPPORT BRKT
Valor Gas Fire part no. 0544789

4   OBSOLETE WALL MTG BRKT
Valor Gas Fire part no. 0544679

6   OBSOLETE INLET PIPE BRKT
Valor Gas Fire part no. 0544799

8   OBSOLETE LOCATION BRACKET
Valor Gas Fire part no. 0535779

9   OBSOLETE LOCATION STUD
Valor Gas Fire part no. 0535769

10   OBSOLETE M5X35MM HEX HD BLACK SCREW
Valor Gas Fire part no. 0514459

11   NUT
Valor Gas Fire part no. 0534679
12   OBSOLETE INDICATOR
Valor Gas Fire part no. 0530939

13   OBSOLETE HEAT EXCHANGER ASSY
Valor Gas Fire part no. 0544689

14   OBSOLETE HEAT EXCH. FRONT BAFFL
Valor Gas Fire part no. 0539549

15 Part number 0534629, SCREW SCREW
Valor Gas Fire part no. 0534629
17 Part number 0536259, OBSOLETE RADIANT BOX OBSOLETE RADIANT BOX
Valor Gas Fire part no. 0536259

18   OBSOLETE SPACER
Valor Gas Fire part no. 0535479

19   OBSOLETE SCREW
Valor Gas Fire part no. 0535489

20   OBSOLETE WASHER
Valor Gas Fire part no. 0515509

21 Part number 0532279, NUT NUT
Valor Gas Fire part no. 0532279

21 Part number 635506, NUT M5 FULL BRASS NUT M5 FULL BRASS
Valor Gas Fire part no. 635506

22   OBSOLETE NO8X3/8 SELF TAP SCREW
Valor Gas Fire part no. 0536809

23   OBSOLETE RADIANT UPPER SUPPORT
Valor Gas Fire part no. 0535519

25   OBSOLETE AIR GUIDE PLATE
Valor Gas Fire part no. 0535539

26   OBSOLETE RADIANT LOWER SUPPORT
Valor Gas Fire part no. 0535529

28   OBSOLETE INSULATION BOARD
Valor Gas Fire part no. 0536159

29   OBSOLETE BURNER 303/333
Valor Gas Fire part no. 0535559

30   SCREW
Valor Gas Fire part no. 0535569
32 Part number 636102, OBSOLETE NUT WING M5 SN OBSOLETE NUT WING M5 SN
Valor Gas Fire part no. 636102

32 Part number 0533249, OBSOLETE WING NUT OBSOLETE WING NUT
Valor Gas Fire part no. 0533249

34   IGNITOR-PIEZO-REF 66111 (VERN)
Valor Gas Fire part no. 042941

34 Part number 0536939, PIEZO GENERATOR PACK PIEZO GENERATOR PACK
Valor Gas Fire part no. 0536939

35   LOCK NUT
Valor Gas Fire part no. 0502739
36 Part number 0544619, OBSOLETE INJECTOR CAT 16 SIZE 120 OBSOLETE INJECTOR CAT 16 SIZE 120
Valor Gas Fire part no. 0544619

37   OBSOLETE INJECTOR BRAY CAT 28 SIZE 250B
Valor Gas Fire part no. 0545199

38   OBSOLETE PILOT FIXING BRKT
Valor Gas Fire part no. 0544699

42   OBSOLETE NO8 X 3/8 PAN HD POZI SCREWS
Valor Gas Fire part no. 0536699

43   OBSOLETE ELECTRODE LEAD ASSY
Valor Gas Fire part no. 0544629

44   OBSOLETE PIPE ASSY : PILOT
Valor Gas Fire part no. 0544709

45   OBSOLETE PIPE ASSY : INLET
Valor Gas Fire part no. 0544719

46   PIPE FIXING BRACKET
Valor Gas Fire part no. 0535639
48 Part number 0532519, ELBOW ELBOW
Valor Gas Fire part no. 0532519
49   OBSOLETE UPPER FRONT ASSY BLACK
Valor Gas Fire part no. 0523739

49   OBSOLETE UPPER FRONT ASSY
Valor Gas Fire part no. 0523619

50   OBSOLETE SPIRE FIX
Valor Gas Fire part no. 0511329

53   OBSOLETE CONTROL SPINDLE ASSY
Valor Gas Fire part no. 0544819

54 Part number 0536949, SPLIT PIN SPLIT PIN
Valor Gas Fire part no. 0536949
55   OBSOLETE WASHER
Valor Gas Fire part no. 0532529

56   OBSOLETE BOTTOM PANEL ASSY
Valor Gas Fire part no. 0544869

56   OBSOLETE BOTTOM PANEL ASSY
Valor Gas Fire part no. 0544829

57   OBSOLETE VALOR N/PLATE
Valor Gas Fire part no. 0504639

58   FIX
Valor Gas Fire part no. 0534419
59   OBSOLETE RH REFLECTOR
Valor Gas Fire part no. 0523659

60   OBSOLETE LH REFLECTOR
Valor Gas Fire part no. 0523669

62 Part number 0544649, RADIANT ASSEMBLY RADIANT ASSEMBLY
Valor Gas Fire part no. 0544649
63   OBSOLETE DRESS GUARD
Valor Gas Fire part no. 0523689

64   OBSOLETE FLUE SPIGOT RESTRICTOR
Valor Gas Fire part no. 0544749

65 Part number 0544759, CLOSURE PLATE CLOSURE PLATE
Valor Gas Fire part no. 0544759
66 Part number 0535419, OBSOLETE FLUE SPIGOT OBSOLETE FLUE SPIGOT
Valor Gas Fire part no. 0535419

67   OBSOLETE FLOOR PLATE
Valor Gas Fire part no. 0523699
