VALOR GAS FIRE
ELEGANT 304 RADIANT/CONVECTOR GAS FIRE - (First Line Spares)
Appliance Code: 32-810-35

Appliance Diagram


First Line Spares diagram for Valor Gas Fire Elegant 304 Radiant/Convector Gas FireClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0535419, OBSOLETE FLUE SPIGOT OBSOLETE FLUE SPIGOT
Valor Gas Fire part no. 0535419

2   OBSOLETE FLUE SPIGOT RESTRICT
Valor Gas Fire part no. 0536219

3   8X3/8 SCREW
Valor Gas Fire part no. 0511569
4   OBSOLETE ASSEMBLY - WOOD CASING
Valor Gas Fire part no. 040K471

5   OBSOLETE ASSEMBLY - METAL CASING
Valor Gas Fire part no. 050K312

6 Part number 0534629, SCREW SCREW
Valor Gas Fire part no. 0534629
7   OBSOLETE WOOD SCREW NO.8 X 3/8IN. TWINFAST REC
Valor Gas Fire part no. 100K410

8   OBSOLETE HEAT EXCHANGER ASSEMBLY
Valor Gas Fire part no. 0535469

9   OBSOLETE SPACER
Valor Gas Fire part no. 0535479

10   OBSOLETE SCREW
Valor Gas Fire part no. 0535489

11   OBSOLETE WASHER
Valor Gas Fire part no. 0515509

12 Part number 635506, NUT M5 FULL BRASS NUT M5 FULL BRASS
Valor Gas Fire part no. 635506

12 Part number 0532279, NUT NUT
Valor Gas Fire part no. 0532279

13 Part number 0536259, OBSOLETE RADIANT BOX OBSOLETE RADIANT BOX
Valor Gas Fire part no. 0536259

14   OBSOLETE SCREW M4X10
Valor Gas Fire part no. 0541089

15   OBSOLETE RADIANT UPPER SUPPORT
Valor Gas Fire part no. 0535519

16   OBSOLETE RADIANT LOWER SUPPORT
Valor Gas Fire part no. 0535529

17   OBSOLETE AIR GUIDE PLATE
Valor Gas Fire part no. 0535539

18   OBSOLETE INSULATION BOARD
Valor Gas Fire part no. 0536159

19 Part number 0535549, NOW USE 0544649 Radiant NOW USE 0544649 RADIANT
Valor Gas Fire part no. 0535549

19 Part number 0544649, RADIANT ASSEMBLY RADIANT ASSEMBLY
Valor Gas Fire part no. 0544649
20   OBSOLETE BURNER 303/333
Valor Gas Fire part no. 0535559

21   SCREW
Valor Gas Fire part no. 0535569
22 Part number 636102, OBSOLETE NUT WING M5 SN OBSOLETE NUT WING M5 SN
Valor Gas Fire part no. 636102

22 Part number 0533249, OBSOLETE WING NUT OBSOLETE WING NUT
Valor Gas Fire part no. 0533249

23   OBSOLETE GAS TAP
Valor Gas Fire part no. 0536039

24   OBSOLETE PIEZO
Valor Gas Fire part no. 0536049

25   OBSOLETE PRESSURE TEST POINT SCREW 2BA X 5/16I
Valor Gas Fire part no. 0512629

26   LOCK NUT
Valor Gas Fire part no. 0502739
27 Part number 0535599, UPPER CAT28 SIZE135 INJECTOR UPPER CAT28 SIZE135 INJECTOR
Valor Gas Fire part no. 0535599
28 Part number 0535609, LOWER CAT28 SIZE270INJECTOR LOWER CAT28 SIZE270INJECTOR
Valor Gas Fire part no. 0535609
29 Part number 0531559, ELECTRODE ELECTRODE
Valor Gas Fire part no. 0531559
30   OBSOLETE IGNITION LEAD
Valor Gas Fire part no. 0535619

31   OBSOLETE INLET PIPE ASS
Valor Gas Fire part no. 0536059

32   PIPE FIXING BRACKET
Valor Gas Fire part no. 0535639
33   OBSOLETE FIRE CONTROL SPINDLE WITH: COTTER PIN 3/32IN DIA
Valor Gas Fire part no. 420K278

34   OBSOLETE COTTER PIN
Valor Gas Fire part no. 0528389

35   OBSOLETE WASHER
Valor Gas Fire part no. 0532529

36   OBSOLETE CONTROL KNOB - ARTHRITIC
Valor Gas Fire part no. 8593815

36   OBSOLETE KNOB & CLIP ASSEMBLY
Valor Gas Fire part no. 0536079

37   OBSOLETE UPPER CHASSIS
Valor Gas Fire part no. 0536089

38   OBSOLETE ASSEMBLY - UPPER FRONT PANEL
Valor Gas Fire part no. 040K473

39   OBSOLETE CAPTIVE NUT
Valor Gas Fire part no. 0531069

40   OBSOLETE SCREW
Valor Gas Fire part no. 0529289

41   OBSOLETE FLOOR PLATE& SILENCER
Valor Gas Fire part no. 0536169

42   OBSOLETE FIBRE BOARD SILENCER
Valor Gas Fire part no. 0536179

43   OBSOLETE SILENCER FIXING MESH
Valor Gas Fire part no. 0536189

44   OBSOLETE SCREW
Valor Gas Fire part no. 0536209

45   OBSOLETE LOCATION STUD
Valor Gas Fire part no. 0535769

46   OBSOLETE LOCATION BRACKET
Valor Gas Fire part no. 0535779

47   OBSOLETE FRONT PANEL ASSEMBLY BOTTOM
Valor Gas Fire part no. 0536289

48   OBSOLETE L/HAND REFLEC/R
Valor Gas Fire part no. 0535799

49   OBSOLETE R/HAND REFLEC/R
Valor Gas Fire part no. 0535809

50   OBSOLETE SCREW
Valor Gas Fire part no. 0536119

51   OBSOLETE DRESS GUARD
Valor Gas Fire part no. 0536129

52   OBSOLETE LEVELLING SCREW
Valor Gas Fire part no. 0535979

53   OBSOLETE NUT
Valor Gas Fire part no. 0532259

54   OBSOLETE CLOSURE PLATE
Valor Gas Fire part no. 0536299

55   OBSOLETE COOLER PLATE
Valor Gas Fire part no. 0536549

56 Part number 0532519, ELBOW ELBOW
Valor Gas Fire part no. 0532519
57   OBSOLETE INSTRUCTIONS - USERS
Valor Gas Fire part no. 620A659

58   OBSOLETE INSTRUCTIONS - INSTALLATION
Valor Gas Fire part no. 620A660

59   OBSOLETE CHANNEL SUPPORT
Valor Gas Fire part no. 0536329
