VALOR GAS FIRE
618 - (Fire Front 4)
Appliance Code: 32-810-88

Appliance Diagram


Fire Front 4 diagram for Valor Gas Fire 618Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE BNR TRAY UNIT ASSY
Valor Gas Fire part no. 0508939

2   OBSOLETE PILOT BNR ASSY
Valor Gas Fire part no. 0508769

4   OBSOLETE PILOT HEAD ASSY
Valor Gas Fire part no. 0508789

5 Part number 0508799, OBSOLETE PILOT BNR INJECTOR OBSOLETE PILOT BNR INJECTOR
Valor Gas Fire part no. 0508799

6 Part number 0508809, THERMOCOUPLE THERMOCOUPLE
Valor Gas Fire part no. 0508809

7   OBSOLETE FRONT SUPPORT
Valor Gas Fire part no. 0508819

10   OBSOLETE GAS TAP
Valor Gas Fire part no. 0508829

11   LOCK NUT
Valor Gas Fire part no. 0502739
12 Part number 0502759, OBSOLETE CONTROL KNOB OBSOLETE CONTROL KNOB
Valor Gas Fire part no. 0502759

13   OBSOLETE INJECTOR
Valor Gas Fire part no. 0508839

15 Part number 0542349, OBSOLETE Electrode 245-255MM Lead OBSOLETE ELECTRODE 245-255MM LEAD
Valor Gas Fire part no. 0542349

16   OBSOLETE PIPE : TAP INJ.
Valor Gas Fire part no. 0508849

17   PIPE : TAP-PILOT
Valor Gas Fire part no. 0508859
18   OBSOLETE PIPE: INLET
Valor Gas Fire part no. 0508869

19   OBSOLETE INLET PIPE BRACKET
Valor Gas Fire part no. 0513449

20   SCREW
Valor Gas Fire part no. 0513359
21   OBSOLETE INLET ELBOW
Valor Gas Fire part no. 0510379

21   OBSOLETE OLIVE
Valor Gas Fire part no. 0519779

21   OBSOLETE OLIVE NUT
Valor Gas Fire part no. 0523389

22   OBSOLETE BACK BRICK
Valor Gas Fire part no. 0508949

23 Part number 0508889, OBSOLETE CERAMIC GRID OBSOLETE CERAMIC GRID
Valor Gas Fire part no. 0508889

24   OBSOLETE PACK - ADDITIONAL COAL
Valor Gas Fire part no. 0510349

24   OBSOLETE PACK - MAIN COALS
Valor Gas Fire part no. 0508899

25 Part number 0508909, PACK - VERMICULITE PACK - VERMICULITE
Valor Gas Fire part no. 0508909

26   OBSOLETE WOOD SCREW
Valor Gas Fire part no. 0543599

27   RAWL PLUG
Valor Gas Fire part no. 0534659
28   OBSOLETE INNER FIXING BRKT
Valor Gas Fire part no. 0509139

29   SCREW M5X10 PAN.POZ.BLACK
Valor Gas Fire part no. 633988
29 Part number 0502649, NOW USE 633988 M5X10 POZI PAN HD SCREW BLACK NOW USE 633988 M5X10 POZI PAN HD SCREW BLACK
Valor Gas Fire part no. 0502649

30   NUT
Valor Gas Fire part no. 0534679
31   OBSOLETE INSTALLATION INST
Valor Gas Fire part no. 0508919

32   OBSOLETE USERS INSTRUCTIONS
Valor Gas Fire part no. 0508929

100   OBSOLETE FIRE FRONT 618A CHEVIOT
Valor Gas Fire part no. 0561821

101   OBSOLETE FRONT CASTING ASSY
Valor Gas Fire part no. 0509009

102   OBSOLETE DECORATIVE SWAG
Valor Gas Fire part no. 0508969

103   FIX
Valor Gas Fire part no. 0534419
104   SCREW
Valor Gas Fire part no. 0535569
105   OBSOLETE DECORATIVE KNOB
Valor Gas Fire part no. 0514439

106   OBSOLETE CORNER (FRONT CASTING)
Valor Gas Fire part no. 0514449

107   OBSOLETE HEARTH CASTING ASSY
Valor Gas Fire part no. 0509019

108   OBSOLETE PULL RING
Valor Gas Fire part no. 0508989

109   OBSOLETE 3/16 X 1 MUSH ZP SCREW
Valor Gas Fire part no. 0527189

110   GROMMET
Valor Gas Fire part no. 0508999
200   OBSOLETE FIRE FRONT - 618B PORTLAND - BLACK FINISH
Valor Gas Fire part no. 0561831

201   OBSOLETE FRONT CASTING
Valor Gas Fire part no. 0509529

202   OBSOLETE HEARTH CASTING ASSY
Valor Gas Fire part no. 0509539

203   OBSOLETE PULL KNOB
Valor Gas Fire part no. 0509519

204   OBSOLETE M5X16 POZI PN TT BLAC
Valor Gas Fire part no. 0552919

300   OBSOLETE FIRE FRONT 618C GRAMPIAN
Valor Gas Fire part no. 0561841

301   OBSOLETE FRONT CASTING
Valor Gas Fire part no. 0509569

302   OBSOLETE HEARTH CASTING ASSY
Valor Gas Fire part no. 0509579

400   OBSOLETE FIRE FRONT 618D ARGYLL
Valor Gas Fire part no. 0561851

401   OBSOLETE FRONT CASTING ASSY
Valor Gas Fire part no. 0509629

402   OBSOLETE CROSS RAIL
Valor Gas Fire part no. 0509639

407   OBSOLETE HEARTH CASTING ASSY
Valor Gas Fire part no. 0509649

408   PULL RING
Valor Gas Fire part no. 0509619
500   OBSOLETE FIRE FRONT 618E PHOENIX
Valor Gas Fire part no. 0561861

501   OBSOLETE FRONT CASTING ASSY
Valor Gas Fire part no. 0509739

502   OBSOLETE FENDER RAIL
Valor Gas Fire part no. 0509749

503   OBSOLETE TRIM - FRONT CASTING
Valor Gas Fire part no. 0509759

504   OBSOLETE DECORATIVE SWAG
Valor Gas Fire part no. 0509729

506   OBSOLETE SCREW
Valor Gas Fire part no. 0552879

507   OBSOLETE PILLAR CAP
Valor Gas Fire part no. 0509699

509   OBSOLETE HEARTH CASTING ASSY
Valor Gas Fire part no. 0509769

510   OBSOLETE PULL RING & FIXINGS
Valor Gas Fire part no. 0509719

600   OBSOLETE FIRE FRONT 618F VISAGE
Valor Gas Fire part no. 0561871

601   OBSOLETE FRONT CASTING
Valor Gas Fire part no. 0510449

602   OBSOLETE CENTRE QUADRANT
Valor Gas Fire part no. 0510399

603   OBSOLETE RAIL & INSERT ASSY
Valor Gas Fire part no. 0510459

604   OBSOLETE SCREW M6X25 CSK POZI BLACK
Valor Gas Fire part no. 0510419

605   OBSOLETE HEARTH CASTING ASSY
Valor Gas Fire part no. 0510469

606   OBSOLETE HANDLE
Valor Gas Fire part no. 0510439
