VAILLANT
THERMOCOMPACT FF VC GB 242 E - (16 Pump)
Appliance Code: 41-044-07

Appliance Diagram


16 Pump diagram for Vaillant Thermocompact FF VC GB 242 EClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 161107, NOW USE 0010030636 Pump NOW USE 0010030636 PUMP
Vaillant part no. 161107
1 Part number 161106, NOW USE 0010032797 Pump NOW USE 0010032797 PUMP
Vaillant part no. 161106
1   PUMP, HIGH-EFFICIENCY
Vaillant part no. 0010032797		 £248.78
1   PUMP, HIGH-EFFICIENCY (IF THIS IS THE REPLACEMENT PART THEN PART NUMBER 0010030685 CABLE IS ALSO REQUIRED)
Vaillant part no. 0010030636		 £344.51
4 Part number 251370, capacitor CAPACITOR
Vaillant part no. 251370		 £15.31
6 Part number 060009, Screw SCREW
Vaillant part no. 060009		 £6.66
7 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140		 £7.05
8 Part number 136333, sensing point SENSING POINT
Vaillant part no. 136333		 £3.91
9 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
10 Part number 981168, OBSOLETE packing ring (set of 10) OBSOLETE PACKING RING (SET OF 10)
Vaillant part no. 981168
