VAILLANT
THERMOCOMPACT 620E VU 202/2-5 2001-2002 - (06 Heat Exchanger 2001-2002)
Appliance Code: 41-044-24 2001-2002

Appliance Diagram


06 Heat Exchanger 2001-2002 diagram for Vaillant Thermocompact 620E VU 202/2-5 2001-2002Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 065098, Heat exchanger (77 fins) HEAT EXCHANGER (77 FINS)
Vaillant part no. 065098		 £282.75
2 Part number 252805, Sensor - NTC SENSOR - NTC
Vaillant part no. 252805		 £22.68
3 Part number 981151, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981151		 £7.86
4 Part number 219621, Spring clamp, (PK10) SPRING CLAMP, (PK10)
Vaillant part no. 219621		 £9.49
5 Part number 0020107695, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020107695		 £6.66
6 Part number 117547, Combustion chamber COMBUSTION CHAMBER
Vaillant part no. 117547
6A Part number 0020082195, Insulation (set) INSULATION (SET)
Vaillant part no. 0020082195		 £40.98
