VAILLANT
THERMOCOMPACT 620E VU 202/2-5 2000-2001,
THERMOCOMPACT 620E VU 202/2-5 2001-2002,
THERMOCOMPACT 620E VU 202/2-5 R1 2002-2003,
THERMOCOMPACT 620E VU 202/2-5 R2 2003-2004,
THERMOCOMPACT 620E VU 202/2-5 R3 2004-2008 - (05 Gas Section)
Appliance Code: 41-044-24

Appliance Diagram


05 Gas Section diagram for Vaillant Thermocompact 620E VU 202/2-5 2000-2001Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 053462, Gas section H-gas GAS SECTION H-GAS
Vaillant part no. 053462
£161.79
1 Part number 053463, Gas section GAS SECTION
Vaillant part no. 053463
£153.47
1 Part number 053473, Gas section, H-gas GAS SECTION, H-GAS
Vaillant part no. 053473
£184.54
1 Part number 053499, Gas section P/B-gas GAS SECTION P/B-GAS
Vaillant part no. 053499

2 Part number 090915, Connection cable CONNECTION CABLE
Vaillant part no. 090915
£14.02
2 Part number 090929, Connection cable CONNECTION CABLE
Vaillant part no. 090929

2 Part number 114192, Connection cable CONNECTION CABLE
Vaillant part no. 114192

4   TUBE GAS VU
Vaillant part no. 123467
£21.04
5 Part number 982319, O-ring O-RING
Vaillant part no. 982319
£5.13
6 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140
£7.05
7 Part number 219622, Spring clamp (PK10) SPRING CLAMP (PK10)
Vaillant part no. 219622
£9.49
8 Part number 123423, Gas tube GAS TUBE
Vaillant part no. 123423
£20.13
9 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142
£8.62
10 Part number 049750, Throttle jet 2 x 3.50 THROTTLE JET 2 X 3.50
Vaillant part no. 049750
£8.97
11 Part number 147759, Adapter piece ADAPTER PIECE
Vaillant part no. 147759
£10.13
12 Part number 105901, Lens head screw M4x10 (PK10) LENS HEAD SCREW M4X10 (PK10)
Vaillant part no. 105901
£21.29
13 Part number 0020085467, Gasket GASKET
Vaillant part no. 0020085467
£6.54
