VAILLANT
MAG MINI 11-0/0 XZ 2004-2009 - (1 Water Valve)
Appliance Code: 11-0/0 XZ

Appliance Diagram


1 Water Valve diagram for Vaillant Mag Mini 11-0/0 XZ 2004-2009Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 115300, Diaphragm DIAPHRAGM
Vaillant part no. 115300		 £7.38
2 Part number 115301, Water quantity regulator WATER QUANTITY REGULATOR
Vaillant part no. 115301		 £6.71
3 Part number 115302, Water valve, upper part WATER VALVE, UPPER PART
Vaillant part no. 115302		 £15.03
4 Part number 115303, Water valve, lower part WATER VALVE, LOWER PART
Vaillant part no. 115303		 £36.94
5 Part number 115304, Water valve WATER VALVE
Vaillant part no. 115304		 £69.14
6 Part number 115311, Venturi VENTURI
Vaillant part no. 115311		 £6.71
7 Part number 115314, Temperature selector TEMPERATURE SELECTOR
Vaillant part no. 115314		 £6.71
8 Part number 115318, Water filter WATER FILTER
Vaillant part no. 115318		 £6.71
9 Part number 115166, Adapter ADAPTER
Vaillant part no. 115166		 £6.45
10 Part number 115320, Screw (PK10) SCREW (PK10)
Vaillant part no. 115320		 £6.71
