VAILLANT
GEOTHERM VWS 81/2 230V - (7 Casing Parts)
Appliance Code: 0010002779

Appliance Diagram


7 Casing Parts diagram for Vaillant Geotherm VWS 81/2 230VClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 0020038757, Sticker Set (Operation Panel) STICKER SET (OPERATION PANEL)
Vaillant part no. 0020038757
£7.92
0   STRAP, SOUND-INSULATION
Vaillant part no. 0020046115
£45.44
0 Part number 0020150157, Screw, M6x16 ISO 14583 (PK10) SCREW, M6X16 ISO 14583 (PK10)
Vaillant part no. 0020150157
£6.53
0   SUPPORT, COLUMN
Vaillant part no. 0020117276
£17.97
1   FRONT PANEL (BELOW)
Vaillant part no. 0020038739
£273.38
2   SIDE PANEL (LEFT)
Vaillant part no. 0020031983
£166.81
3   SIDE PANEL (RIGHT)
Vaillant part no. 0020031987
£166.81
4   FRONT PANEL (TOP)
Vaillant part no. 0020031988
£181.90
5 Part number 0020031989, Cover COVER
Vaillant part no. 0020031989
£70.43
6 Part number 0020031990, Cover, rear COVER, REAR
Vaillant part no. 0020031990
£44.70
7 Part number 0020031996, Casing, control CASING, CONTROL
Vaillant part no. 0020031996
£136.70
8   FRONT PANEL
Vaillant part no. 0020031999
£214.69
9 Part number 0020038755, Handle ring, kit of 3 HANDLE RING, KIT OF 3
Vaillant part no. 0020038755
£6.66
10 Part number 091629, Fastening set covering, 10 of each FASTENING SET COVERING, 10 OF EACH
Vaillant part no. 091629
£10.76
20   HEAT INSULATION, KEYHOLE
Vaillant part no. 0020046106
£8.31
21 Part number 0020198221, Foot FOOT
Vaillant part no. 0020198221
£6.71
