VAILLANT
ECOTEC VU GB 466/4-5 H - (04 Burner)
Appliance Code: VU GB 466/4-5 H

Appliance Diagram


04 Burner diagram for Vaillant Ecotec VU GB 466/4-5 HClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

01 Part number 050430, Burner BURNER
Vaillant part no. 050430		 £117.20
02 Part number 981103, Gasket burner GASKET BURNER
Vaillant part no. 981103		 £8.62
03 Part number 105900, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 105900		 £6.66
04 Part number 0020026537, Nut, M6 (PK5) NUT, M6 (PK5)
Vaillant part no. 0020026537		 £6.66
05 Part number 161245, inspection glass INSPECTION GLASS
Vaillant part no. 161245		 £6.66
06 Part number 090709, Electrode ELECTRODE
Vaillant part no. 090709		 £22.46
07 Part number 981330, gasket electrode GASKET ELECTRODE
Vaillant part no. 981330		 £6.21
08 Part number 0010027341, SCREW, (X10) ISO 7045 SCREW, (X10) ISO 7045
Vaillant part no. 0010027341		 £6.02
09 Part number 0020075412, Plug (Ignition) PLUG (IGNITION)
Vaillant part no. 0020075412		 £6.45
09 Part number 193590, ignition cable IGNITION CABLE
Vaillant part no. 193590		 £21.76
10   COVER PLATE (FAN)
Vaillant part no. 0020105684		 £34.31
10 Part number 190248, Fan FAN
Vaillant part no. 190248		 £522.73
11 Part number 981104, Gasket GASKET
Vaillant part no. 981104		 £7.92
12 Part number 981045, Gasket GASKET
Vaillant part no. 981045		 £6.66
13 Part number 0020110999, Gas section GAS SECTION
Vaillant part no. 0020110999		 £200.39
13 Part number 081697, Connection piece CONNECTION PIECE
Vaillant part no. 081697		 £26.71
14 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
15 Part number 123434, Gas connection tube GAS CONNECTION TUBE
Vaillant part no. 123434		 £46.32
16 Part number 0020039719, Wiring harness, fan WIRING HARNESS, FAN
Vaillant part no. 0020039719		 £61.34
16 Part number 0020045928, Wiring Harness WIRING HARNESS
Vaillant part no. 0020045928		 £34.97
17 Part number 210734, insulation INSULATION
Vaillant part no. 210734		 £29.12
18 Part number 116688, Air gas mixing tube AIR GAS MIXING TUBE
Vaillant part no. 116688		 £49.31
19 Part number 981333, seal heat exchanger door / mixing arm SEAL HEAT EXCHANGER DOOR / MIXING ARM
Vaillant part no. 981333		 £6.66
20 Part number 105836, Cylinder screw, (kit 2 x 4) CYLINDER SCREW, (KIT 2 X 4)
Vaillant part no. 105836		 £6.66
21 Part number 0020038679, Gasket kit GASKET KIT
Vaillant part no. 0020038679		 £19.11
22 Part number 0020038679, Gasket kit GASKET KIT
Vaillant part no. 0020038679		 £19.11
23 Part number 139247, screw SCREW
Vaillant part no. 139247
24 Part number 118882, Flat head screw FLAT HEAD SCREW
Vaillant part no. 118882
25 Part number 145877, Air inlet duct AIR INLET DUCT
Vaillant part no. 145877		 £30.19
26 Part number 981111, Gasket GASKET
Vaillant part no. 981111		 £6.66
28 Part number 087195, NOW USE 0010048102 Bracket, Air Inlet Pipe NOW USE 0010048102 BRACKET, AIR INLET PIPE
Vaillant part no. 087195
28   RETAINER
Vaillant part no. 0010048102		 £5.19
29 Part number 0020133833, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020133833		 £6.66
31 Part number 088134, flange FLANGE
Vaillant part no. 088134		 £97.18
32 Part number 0020012126, Compression Fitting COMPRESSION FITTING
Vaillant part no. 0020012126		 £12.58
33 Part number 009299, OBSOLETE GAS COCK STRAIGHT 1INCH OBSOLETE GAS COCK STRAIGHT 1INCH
Vaillant part no. 009299
