VAILLANT
ECOTEC PLUS 937 VUI 376/5-5 2012-2012,
ECOTEC PLUS 937 VUI 376/5-5 R1 2012-2013,
ECOTEC PLUS 937 VUI 376/5-5 R2 2013-2014,
ECOTEC PLUS 937 VUI 376/5-5 R4 2014-2015 - (08C Hydraulics VIH R2)
Appliance Code: 47-044-43 R2

Appliance Diagram


08C Hydraulics VIH R2 diagram for Vaillant Ecotec Plus 937 VUI 376/5-5 R2 2013-2014Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020039781, Storage Water Heater STORAGE WATER HEATER
Vaillant part no. 0020039781
£520.54
2 Part number 181081, expansion vessel 1 ltr. EXPANSION VESSEL 1 LTR.
Vaillant part no. 181081
£104.27
3 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142
£8.62
4 Part number 0020039784, Pipe PIPE
Vaillant part no. 0020039784
£19.49
5 Part number 0020039785, Pipe PIPE
Vaillant part no. 0020039785
£36.39
6 Part number 190745, Pressure relief valve, 10 bar PRESSURE RELIEF VALVE, 10 BAR
Vaillant part no. 190745
£18.86
7 Part number 178992, Clip, (PK10) CLIP, (PK10)
Vaillant part no. 178992
£8.18
8 Part number 219622, Spring clamp (PK10) SPRING CLAMP (PK10)
Vaillant part no. 219622
£9.49
10 Part number 193537, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 193537
£9.48
11 Part number 193598, Nut, (PK4) NUT, (PK4)
Vaillant part no. 193598
£6.66
12 Part number 0020039787, Pipe PIPE
Vaillant part no. 0020039787
£25.09
13 Part number 0020039788, Pipe PIPE
Vaillant part no. 0020039788
£30.57
14 Part number 0020039789, Pipe PIPE
Vaillant part no. 0020039789

15 Part number 179032, Connection piece CONNECTION PIECE
Vaillant part no. 179032
£24.60
16 Part number 178992, Clip, (PK10) CLIP, (PK10)
Vaillant part no. 178992
£8.18
17 Part number 178988, Flow sensor FLOW SENSOR
Vaillant part no. 178988
£26.24
18 Part number 178966, clip CLIP
Vaillant part no. 178966
£6.66
19 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163
£7.03
20 Part number 178991, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 178991
£6.66
21 Part number 0020039790, Pipe PIPE
Vaillant part no. 0020039790
£14.45
22 Part number 0020039791, Pipe PIPE
Vaillant part no. 0020039791
£16.66
23 Part number 0020039792, Pipe PIPE
Vaillant part no. 0020039792
£14.45
24 Part number 0020039793, NOW USE 0010037393 Pump NOW USE 0010037393 PUMP
Vaillant part no. 0020039793

24   PUMP
Vaillant part no. 0010037393
£230.41
25 Part number 0020039794, Pipe PIPE
Vaillant part no. 0020039794
£17.92
26   PRICE ON APPLICATION
Vaillant part no. 0000

27 Part number 0020111282, Printed circuit board PRINTED CIRCUIT BOARD
Vaillant part no. 0020111282
£58.12
28 Part number 0020180999, Wiring harness WIRING HARNESS
Vaillant part no. 0020180999
£44.39
29 Part number 0020068120, Sensor, NTC 19mm SENSOR, NTC 19MM
Vaillant part no. 0020068120
£19.53
30 Part number 0020039796, Sensor - NTC (DHW outlet pipe) SENSOR - NTC (DHW OUTLET PIPE)
Vaillant part no. 0020039796
£6.80
31 Part number 103429, Sensor NTC, DHW outlet pipe SENSOR NTC, DHW OUTLET PIPE
Vaillant part no. 103429
£8.63
32 Part number 136376, NOW USE 0010047543 nipple NOW USE 0010047543 NIPPLE
Vaillant part no. 136376

32   NIPPLE
Vaillant part no. 0010047543
£1.60
33 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140
£7.05
34 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142
£8.62
35 Part number 074514, Filter FILTER
Vaillant part no. 074514
£6.66
36 Part number 011603, Limiter 14l/min LIMITER 14L/MIN
Vaillant part no. 011603
£6.66
37 Part number 092002, Connection piece CONNECTION PIECE
Vaillant part no. 092002
£6.66
41 Part number 0020138668, Tube (plastic) TUBE (PLASTIC)
Vaillant part no. 0020138668
£11.56
42 Part number 0020175889, Support (pump) SUPPORT (PUMP)
Vaillant part no. 0020175889
£19.38
