VAILLANT
ECOTEC PLUS 612 VU 126/5-5 A R4 2015 ONWARDS - (5 Gas Section R4)
Appliance Code: 41-044-78

Appliance Diagram


5 Gas Section R4 diagram for Vaillant Ecotec Plus 612 VU 126/5-5 A R4 2015 OnwardsClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020135147, Air inlet pipe AIR INLET PIPE
Vaillant part no. 0020135147		 £21.19
2 Part number 0020135150, Support air inlet duct SUPPORT AIR INLET DUCT
Vaillant part no. 0020135150		 £6.66
3 Part number 0020135148, Air inlet pipe AIR INLET PIPE
Vaillant part no. 0020135148		 £21.19
4 Part number 0020135151, Support air inlet duct SUPPORT AIR INLET DUCT
Vaillant part no. 0020135151		 £6.66
5 Part number 0020026537, Nut, M6 (PK5) NUT, M6 (PK5)
Vaillant part no. 0020026537		 £6.66
6 Part number 0020135152, Washer, (PK10) WASHER, (PK10)
Vaillant part no. 0020135152		 £6.66
7 Part number 0020133833, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020133833		 £6.66
8 Part number 0020135138, Fan FAN
Vaillant part no. 0020135138		 £214.69
9 Part number 193594, Gasket GASKET
Vaillant part no. 193594		 £6.69
10 Part number 0020233882, NOW USE 0010045492 CABLE, FAN 230V NOW USE 0010045492 CABLE, FAN 230V
Vaillant part no. 0020233882
10   CABLE, FAN 230 V
Vaillant part no. 0010045492		 £8.08
11 Part number 193597, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 193597		 £6.69
12 Part number 0020135120, O-ring venturi (PK5) O-RING VENTURI (PK5)
Vaillant part no. 0020135120		 £13.82
13 Part number 0020135122, Venturi VENTURI
Vaillant part no. 0020135122		 £128.48
14 Part number 0020136647, Cap (over venturi filter) CAP (OVER VENTURI FILTER)
Vaillant part no. 0020136647		 £6.66
15 Part number 0020135126, Throttle jet, + gas coding plug (yellow) THROTTLE JET, + GAS CODING PLUG (YELLOW)
Vaillant part no. 0020135126		 £47.92
15 Part number 0020135128, Throttle jet, + gas coding plug (grey) THROTTLE JET, + GAS CODING PLUG (GREY)
Vaillant part no. 0020135128		 £48.88
16 Part number 0020136636, Clip (PK10) CLIP (PK10)
Vaillant part no. 0020136636		 £21.29
17 Part number 0020135149, Gasket air inlet duct GASKET AIR INLET DUCT
Vaillant part no. 0020135149		 £6.66
18 Part number 0020135136, Gas pipe GAS PIPE
Vaillant part no. 0020135136		 £24.60
19 Part number 0020135135, O-ring (PK10) O-RING (PK10)
Vaillant part no. 0020135135		 £11.30
20 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
21 Part number 0020148381, Gas section with regulator GAS SECTION WITH REGULATOR
Vaillant part no. 0020148381		 £188.85
22 Part number 0020135145, Support gas section SUPPORT GAS SECTION
Vaillant part no. 0020135145		 £17.54
23 Part number 108628, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 108628		 £6.66
24 Part number 509685, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 509685		 £6.66
25 Part number 0020141340, Gas pipe, top GAS PIPE, TOP
Vaillant part no. 0020141340		 £29.58
27 Part number 0020141343, OBSOLETE Gas pipe, bottom OBSOLETE GAS PIPE, BOTTOM
Vaillant part no. 0020141343
28 Part number 0020136643, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020136643		 £6.66
