VAILLANT
ECOTEC EXCLUSIVE 843 VUW 436/5-7 - (05 Gas Section)
Appliance Code: 47-044-67

Appliance Diagram


05 Gas Section diagram for Vaillant Ecotec Exclusive 843 VUW 436/5-7Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020233508, AIR INLET DUCT AIR INLET DUCT
Vaillant part no. 0020233508
£34.79
3 Part number 0020135151, Support air inlet duct SUPPORT AIR INLET DUCT
Vaillant part no. 0020135151
£6.66
4 Part number 0020026537, Nut, M6 (PK5) NUT, M6 (PK5)
Vaillant part no. 0020026537
£6.66
5 Part number 0020133833, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020133833
£6.66
6 Part number 0020135152, Washer, (PK10) WASHER, (PK10)
Vaillant part no. 0020135152
£6.66
7 Part number 981111, Gasket GASKET
Vaillant part no. 981111
£6.66
12 Part number 0020233881, FAN FAN
Vaillant part no. 0020233881
£242.77
13 Part number 193594, Gasket GASKET
Vaillant part no. 193594
£6.69
14 Part number 0020233882, NOW USE 0010045492 CABLE, FAN 230V NOW USE 0010045492 CABLE, FAN 230V
Vaillant part no. 0020233882

14   CABLE, FAN 230 V
Vaillant part no. 0010045492
£8.08
15 Part number 193597, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 193597
£6.69
16 Part number 0020209514, GAS CONTROL VALVE GAS CONTROL VALVE
Vaillant part no. 0020209514
£136.58
17 Part number 0020195462, Gasket GASKET
Vaillant part no. 0020195462
£6.53
18 Part number 509685, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 509685
£6.66
19 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140
£7.05
20 Part number 0020209516, GAS PIPE, FLEXIBLE GAS PIPE, FLEXIBLE
Vaillant part no. 0020209516
£27.14
21 Part number 0020209518, GAS PIPE GAS PIPE
Vaillant part no. 0020209518
£18.19
22 Part number 0020136643, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020136643
£6.66
23 Part number 0020241698, Gas valve, M28 x 20 GAS VALVE, M28 X 20
Vaillant part no. 0020241698
£36.71
24 Part number 0020241704, HANDLE, GAS COCK HANDLE, GAS COCK
Vaillant part no. 0020241704
£6.39
25 Part number 0020221257, ELBOW ELBOW
Vaillant part no. 0020221257
£10.37
26 Part number 080177, nut NUT
Vaillant part no. 080177
£6.66
27 Part number 080184, Compression ring, 20 mm COMPRESSION RING, 20 MM
Vaillant part no. 080184
£6.66
