VAILLANT
ECOTEC EXCLUSIVE 835 VUW 356/5-7 - (08b Hydraulics Parts)
Appliance Code: 47-044-66

Appliance Diagram


08b Hydraulics Parts diagram for Vaillant Ecotec Exclusive 835 VUW 356/5-7Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 181051, Expansion vessel 10 ltr. EXPANSION VESSEL 10 LTR.
Vaillant part no. 181051		 £135.15
2 Part number 0020144598, SUPPORT (EXPANSION VESSEL) SUPPORT (EXPANSION VESSEL)
Vaillant part no. 0020144598		 £6.66
3 Part number 0020136643, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020136643		 £6.66
4 Part number 0020144605, Tube, expansion vessel TUBE, EXPANSION VESSEL
Vaillant part no. 0020144605		 £10.76
6 Part number 0020144608, ADAPTER ADAPTER
Vaillant part no. 0020144608		 £6.66
7 Part number 0020144606, pressure gauge PRESSURE GAUGE
Vaillant part no. 0020144606		 £34.33
8 Part number 193592, Sensor NTC (CH flow/CH return) SENSOR NTC (CH FLOW/CH RETURN)
Vaillant part no. 193592		 £9.67
9 Part number 0020059717, sensor (water pressure) SENSOR (WATER PRESSURE)
Vaillant part no. 0020059717		 £25.74
10 Part number 0020087657, ADAPTER ADAPTER
Vaillant part no. 0020087657		 £12.58
11A Part number 0020233892, TUBE TUBE
Vaillant part no. 0020233892		 £12.17
11B Part number 0020233894, TUBE TUBE
Vaillant part no. 0020233894		 £10.37
12A Part number 0020178129, TUBE TUBE
Vaillant part no. 0020178129		 £12.22
12B Part number 0020045923, Sensor, Vortex, DN15 SENSOR, VORTEX, DN15
Vaillant part no. 0020045923		 £43.39
12C Part number 0020233891, TUBE TUBE
Vaillant part no. 0020233891		 £12.17
13 Part number 103417, Clip, (PK10) CLIP, (PK10)
Vaillant part no. 103417		 £9.86
14 Part number 178992, Clip, (PK10) CLIP, (PK10)
Vaillant part no. 178992		 £8.18
15 Part number 0020107694, Clip, (PK5) CLIP, (PK5)
Vaillant part no. 0020107694		 £7.03
16 Part number 981149, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981149		 £7.96
17 Part number 103415, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 103415		 £7.67
18 Part number 193537, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 193537		 £9.48
19 Part number 193539, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 193539		 £16.67
20 Part number 178993, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 178993		 £6.69
21 Part number 0020233890, TUBE TUBE
Vaillant part no. 0020233890		 £16.87
22 Part number 0020233888, TUBE TUBE
Vaillant part no. 0020233888		 £21.83
23 Part number 0020233886, WATER HAMMER ARRESTOR WATER HAMMER ARRESTOR
Vaillant part no. 0020233886		 £110.24
24 Part number 0020233887, INSULATION INSULATION
Vaillant part no. 0020233887		 £25.37
25 Part number 0020233889, TUBE TUBE
Vaillant part no. 0020233889		 £29.45
26 Part number 012987, Limiter 11.7l/min LIMITER 11.7L/MIN
Vaillant part no. 012987		 £16.66
27 Part number 074514, Filter FILTER
Vaillant part no. 074514		 £6.66
28 Part number 0020144600, Nut, 3/4 (PK4) NUT, 3/4 (PK4)
Vaillant part no. 0020144600		 £6.66
29 Part number 0020233895, Clip, (PK10) CLIP, (PK10)
Vaillant part no. 0020233895		 £26.43
30 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
31 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
32 Part number 178986, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 178986		 £6.66
33 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140		 £7.05
