VAILLANT
ECOMAX VU 226 E 1995-2000 - (08 Connection Parts Expansion Vessel)
Appliance Code: 41-044-12

Appliance Diagram


08 Connection Parts Expansion Vessel diagram for Vaillant Ecomax VU 226 E 1995-2000Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 181022, Expansion vessel 12 ltr. EXPANSION VESSEL 12 LTR.
Vaillant part no. 181022
2 Part number 116477, hexagonal screw HEXAGONAL SCREW
Vaillant part no. 116477		 £3,91
3 Part number 981176, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981176		 £8,15
4 Part number 161083, pump PUMP
Vaillant part no. 161083
5 Part number 061707, automatic de-aerator AUTOMATIC DE-AERATOR
Vaillant part no. 061707		 £20,36
6 Part number 118951, Pan head screw, M6x28,5 PAN HEAD SCREW, M6X28,5
Vaillant part no. 118951		 £4,92
7 Part number 981151, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981151		 £8,09
8 Part number 0020107784, Support SUPPORT
Vaillant part no. 0020107784
9 Part number 0020107716, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020107716		 £5,13
10 Part number 0020107695, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020107695		 £6,86
11 Part number 014631, diverter valve DIVERTER VALVE
Vaillant part no. 014631		 £50,77
12 Part number 089247, connection tube CONNECTION TUBE
Vaillant part no. 089247
13   OBSOLETE CONNECTION GROUP
Vaillant part no. 080712
14   CONNECTION TUBE
Vaillant part no. 089024		 £23,52
15 Part number 081082, connection CONNECTION
Vaillant part no. 081082
16 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7,24
17 Part number 150224, By-pass valve BY-PASS VALVE
Vaillant part no. 150224		 £12,58
17 Part number 150225, By-pass valve BY-PASS VALVE
Vaillant part no. 150225
17 Part number 150232, OBSOLETE by-pass valve OBSOLETE BY-PASS VALVE
Vaillant part no. 150232
18 Part number 129231, t-piece T-PIECE
Vaillant part no. 129231		 £59,95
19 Part number 981175, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981175
20 Part number 082424, flange plate FLANGE PLATE
Vaillant part no. 082424		 £18,74
21   CONNECTION TUBE
Vaillant part no. 089023		 £22,79
22 Part number 981152, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981152		 £7,24
23 Part number 126158, spring clamp SPRING CLAMP
Vaillant part no. 126158
24   PRICE ON APPLICATION
Vaillant part no. 0000
25   PRICE ON APPLICATION
Vaillant part no. 0000
26 Part number 118946, lens head screw LENS HEAD SCREW
Vaillant part no. 118946		 £3,91
27 Part number 011263, water valve WATER VALVE
Vaillant part no. 011263		 £126,94
28 Part number 080965, cold water connection tube COLD WATER CONNECTION TUBE
Vaillant part no. 080965
29 Part number 981165, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981165		 £6,89
30 Part number 0020107708, CLIP CLIP
Vaillant part no. 0020107708		 £6,53
30   BRACKET
Vaillant part no. 154181		 £5,13
31 Part number 089058, cold water connection tube COLD WATER CONNECTION TUBE
Vaillant part no. 089058		 £10,65
32 Part number 981170, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981170		 £6,89
33 Part number 154149, bow BOW
Vaillant part no. 154149		 £5,13
34   WARM WATER CONNECTION TUBE
Vaillant part no. 089022		 £19,96
35   PRICE ON APPLICATION
Vaillant part no. 0000
37 Part number 012952, LIMITER Vuw 2 36 E LIMITER VUW 2 36 E
Vaillant part no. 012952		 £4,36
37   WATER QUANTITY LIMITER VUW 2 86 E
Vaillant part no. 012953		 £3,91
38   NIPPLE
Vaillant part no. 136387		 £14,99
39 Part number 981161, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981161		 £6,86
40 Part number 070334, screw SCREW
Vaillant part no. 070334
42 Part number 136389, nipple NIPPLE
Vaillant part no. 136389
43 Part number 0020107786, SUPPORT SUPPORT
Vaillant part no. 0020107786
44 Part number 981234, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981234		 £7,25
45 Part number 084138, Hose HOSE
Vaillant part no. 084138		 £42,25
