VAILLANT
ECOMAX 835E VUW 356-C 2002 -2008 - (08 Connection Parts)
Appliance Code: 47-044-27

Appliance Diagram


08 Connection Parts diagram for Vaillant Ecomax 835E VUW 356-C 2002 -2008Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 022736, Tube TUBE
Vaillant part no. 022736		 £30.77
2 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140		 £7.05
3 Part number 140015, Screw - De-aeration SCREW - DE-AERATION
Vaillant part no. 140015		 £6.66
4 Part number 080387, Tube, flexible TUBE, FLEXIBLE
Vaillant part no. 080387		 £12.57
5 Part number 0020052092, Clamp (PK2) CLAMP (PK2)
Vaillant part no. 0020052092		 £6.66
6 Part number 252805, Sensor - NTC SENSOR - NTC
Vaillant part no. 252805		 £22.68
7 Part number 022745, Connection tube CONNECTION TUBE
Vaillant part no. 022745		 £74.28
8 Part number 074517, Filter FILTER
Vaillant part no. 074517		 £11.55
9   CONNECTION TUBE
Vaillant part no. 022666
10 Part number 160959, NOW USE 0010030636 pump NOW USE 0010030636 PUMP
Vaillant part no. 160959
10   PUMP, HIGH-EFFICIENCY (IF THIS IS THE REPLACEMENT PART THEN PART NUMBER 0010030685 CABLE IS ALSO REQUIRED)
Vaillant part no. 0010030636		 £344.51
11 Part number 061707, automatic de-aerator AUTOMATIC DE-AERATOR
Vaillant part no. 061707		 £19.76
12 Part number 022668, Tube TUBE
Vaillant part no. 022668		 £37.75
13 Part number 150238, automatic bypass valve AUTOMATIC BYPASS VALVE
Vaillant part no. 150238		 £32.27
14 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
15 Part number 252457, Diverter valve DIVERTER VALVE
Vaillant part no. 252457		 £139.42
16 Part number 140429, Actuator - diverter valve ACTUATOR - DIVERTER VALVE
Vaillant part no. 140429		 £57.18
17 Part number 022746, Connection tube CONNECTION TUBE
Vaillant part no. 022746
18 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
19 Part number 219622, Spring clamp (PK10) SPRING CLAMP (PK10)
Vaillant part no. 219622		 £9.49
20 Part number 022744, Connection tube CONNECTION TUBE
Vaillant part no. 022744		 £26.17
21 Part number 022743, Connection tube CONNECTION TUBE
Vaillant part no. 022743		 £30.71
22 Part number 194831, Impeller IMPELLER
Vaillant part no. 194831		 £70.40
23 Part number 711933, Sensor, hall effect SENSOR, HALL EFFECT
Vaillant part no. 711933		 £22.46
24 Part number 256149, Wiring harness WIRING HARNESS
Vaillant part no. 256149
25 Part number 256161, cable tree CABLE TREE
Vaillant part no. 256161
26 Part number 022640, Tube TUBE
Vaillant part no. 022640		 £29.58
27 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
28 Part number 181051, Expansion vessel 10 ltr. EXPANSION VESSEL 10 LTR.
Vaillant part no. 181051		 £135.15
29 Part number 981149, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981149		 £7.96
30 Part number 0020107694, Clip, (PK5) CLIP, (PK5)
Vaillant part no. 0020107694		 £7.03
31 Part number 981154, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981154		 £6.69
32 Part number 022673, Tube (M12x1) TUBE (M12X1)
Vaillant part no. 022673		 £10.45
33 Part number 981146, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981146		 £6.69
34 Part number 014720, drain cock DRAIN COCK
Vaillant part no. 014720		 £51.58
35 Part number 095610, Tube, flexible TUBE, FLEXIBLE
Vaillant part no. 095610		 £17.58
36 Part number 981165, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981165		 £6.69
37 Part number 014676, Non-return valve NON-RETURN VALVE
Vaillant part no. 014676		 £19.20
38 Part number 022675, Tube TUBE
Vaillant part no. 022675
39 Part number 190728, Pressure relief valve PRESSURE RELIEF VALVE
Vaillant part no. 190728		 £28.14
40 Part number 136376, NOW USE 0010047543 nipple NOW USE 0010047543 NIPPLE
Vaillant part no. 136376
40   NIPPLE
Vaillant part no. 0010047543		 £1.60
41 Part number 022596, Tube (G 1/4) TUBE (G 1/4)
Vaillant part no. 022596		 £15.62
42 Part number 022597, Tube TUBE
Vaillant part no. 022597		 £10.13
43 Part number 190751, Pressure relief valve PRESSURE RELIEF VALVE
Vaillant part no. 190751		 £81.42
44 Part number 014738, Drain cock (M12x1/G1/4) DRAIN COCK (M12X1/G1/4)
Vaillant part no. 014738		 £26.99
45 Part number 219636, Clip (PK2) CLIP (PK2)
Vaillant part no. 219636		 £7.05
46 Part number 113952, Tube TUBE
Vaillant part no. 113952		 £30.16
47 Part number 712087, pressure sensor PRESSURE SENSOR
Vaillant part no. 712087		 £22.89
