VAILLANT
ECOMAX 824E VUW 246E-C 1999-2001 - (07 Casing)
Appliance Code: 47-044-07

Appliance Diagram


07 Casing diagram for Vaillant Ecomax 824E VUW 246E-C 1999-2001Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 077362, Covering COVERING
Vaillant part no. 077362		 £343.00
2   OBSOLETE FRAME, CPL.
Vaillant part no. 136720
3 Part number 980661, Gasket GASKET
Vaillant part no. 980661		 £5.13
4 Part number 088368, fitting FITTING
Vaillant part no. 088368		 £6.66
5 Part number 088367, fitting FITTING
Vaillant part no. 088367		 £6.66
6 Part number 980660, Gasket GASKET
Vaillant part no. 980660		 £5.13
7 Part number 201865, Grommet - electrical GROMMET - ELECTRICAL
Vaillant part no. 201865		 £5.42
8 Part number 0020107695, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020107695		 £6.66
8 Part number 235715, NOW USE 0020107695 Tapping screw ISO 7049 NOW USE 0020107695 TAPPING SCREW ISO 7049
Vaillant part no. 235715
