VAILLANT
ECOMAX 665 VU (CONDENSING SYSTEM) 2006-2008 - (08 Connection Parts)
Appliance Code: 20-062-02

Appliance Diagram


08 Connection Parts diagram for Vaillant Ecomax 665 VU (Condensing System) 2006-2008Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 180912, heat exchanger HEAT EXCHANGER
Vaillant part no. 180912		 £1,372.23
2 Part number 981311, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981311		 £7.05
3 Part number 180918, O-ring (PK10) O-RING (PK10)
Vaillant part no. 180918		 £6.66
4 Part number 180922, Tube TUBE
Vaillant part no. 180922
5 Part number 252805, Sensor - NTC SENSOR - NTC
Vaillant part no. 252805		 £22.68
6 Part number 733171, flat plug FLAT PLUG
Vaillant part no. 733171
8 Part number 180924, Tube TUBE
Vaillant part no. 180924
9 Part number 180926, Distributor Tube DISTRIBUTOR TUBE
Vaillant part no. 180926		 £91.28
10 Part number 981272, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981272		 £6.66
11 Part number 180928, Connection CONNECTION
Vaillant part no. 180928		 £38.14
12 Part number 180929, NOW USE 0020211454 pump NOW USE 0020211454 PUMP
Vaillant part no. 180929
12 Part number 0020211454, Pump PUMP
Vaillant part no. 0020211454		 £604.19
13 Part number 236500, connection CONNECTION
Vaillant part no. 236500		 £16.66
14 Part number 140015, Screw - De-aeration SCREW - DE-AERATION
Vaillant part no. 140015		 £6.66
15 Part number 180923, Nut (PK2) NUT (PK2)
Vaillant part no. 180923		 £6.66
16   CONNECTION
Vaillant part no. 509684		 £25.09
17 Part number 980645, Gasket GASKET
Vaillant part no. 980645
18 Part number 193543, cap, cpl. CAP, CPL.
Vaillant part no. 193543		 £4.45
19   CONNECTION
Vaillant part no. 097057		 £39.18
20 Part number 106350, drain cock DRAIN COCK
Vaillant part no. 106350		 £7.61
21 Part number 193541, Tube TUBE
Vaillant part no. 193541		 £55.60
23 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
24 Part number 061707, automatic de-aerator AUTOMATIC DE-AERATOR
Vaillant part no. 061707		 £19.76
25   CONNECTION
Vaillant part no. 193542		 £132.94
26 Part number 981154, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981154		 £6.69
27 Part number 981155, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981155		 £6.34
28 Part number 712087, pressure sensor PRESSURE SENSOR
Vaillant part no. 712087		 £22.89
30   TUBE
Vaillant part no. 193544		 £48.88
31 Part number 180925, Sealing ring (PK2) SEALING RING (PK2)
Vaillant part no. 180925		 £6.66
32 Part number 180923, Nut (PK2) NUT (PK2)
Vaillant part no. 180923		 £6.66
33 Part number 101271, Pressure gauge PRESSURE GAUGE
Vaillant part no. 101271		 £38.09
34 Part number 085751, NOW USE 0020107709 pressure gauge clip NOW USE 0020107709 PRESSURE GAUGE CLIP
Vaillant part no. 085751
34 Part number 0020107709, Support SUPPORT
Vaillant part no. 0020107709		 £6.66
35 Part number 193545, Tube TUBE
Vaillant part no. 193545		 £62.55
36 Part number 180927, Flow switch FLOW SWITCH
Vaillant part no. 180927		 £70.43
37 Part number 180909, cable tree CABLE TREE
Vaillant part no. 180909		 £6.66
38 Part number 509229, Flow switch conduction FLOW SWITCH CONDUCTION
Vaillant part no. 509229		 £14.45
39 Part number 509230, Flow switch conduction FLOW SWITCH CONDUCTION
Vaillant part no. 509230
41 Part number 180906, cable tree CABLE TREE
Vaillant part no. 180906		 £44.70
42 Part number 0020045973, Adapter ADAPTER
Vaillant part no. 0020045973		 £239.90
43 Part number 0020045974, Filter FILTER
Vaillant part no. 0020045974		 £19.53
44 Part number 0020045975, O-Ring (Pk10) O-RING (PK10)
Vaillant part no. 0020045975		 £9.49
46   ISOLATION VALVE
Vaillant part no. 0020073076
47 Part number 0020073075, Isolation valve ISOLATION VALVE
Vaillant part no. 0020073075
