VAILLANT
ECOMAX 618/2E VU186/2-C 2001-2007 - (08 Connection Parts)
Appliance Code: 41-044-28

Appliance Diagram


08 Connection Parts diagram for Vaillant Ecomax 618/2E VU186/2-C 2001-2007Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 022736, Tube TUBE
Vaillant part no. 022736		 £30.77
2 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140		 £7.05
3 Part number 140015, Screw - De-aeration SCREW - DE-AERATION
Vaillant part no. 140015		 £6.66
4 Part number 080387, Tube, flexible TUBE, FLEXIBLE
Vaillant part no. 080387		 £12.57
5 Part number 0020052092, Clamp (PK2) CLAMP (PK2)
Vaillant part no. 0020052092		 £6.66
6 Part number 252805, Sensor - NTC SENSOR - NTC
Vaillant part no. 252805		 £22.68
6 Part number 733171, flat plug FLAT PLUG
Vaillant part no. 733171
7 Part number 022747, Connection tube CONNECTION TUBE
Vaillant part no. 022747
8 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
9 Part number 061707, automatic de-aerator AUTOMATIC DE-AERATOR
Vaillant part no. 061707		 £19.76
10 Part number 022739, Connection tube CONNECTION TUBE
Vaillant part no. 022739
11 Part number 981151, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981151		 £7.86
12 Part number 981234, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981234		 £7.05
13 Part number 160949, pump PUMP
Vaillant part no. 160949		 £147.54
14 Part number 118951, Pan head screw, M6x28,5 PAN HEAD SCREW, M6X28,5
Vaillant part no. 118951		 £4.92
15 Part number 022740, Connection tube CONNECTION TUBE
Vaillant part no. 022740
16 Part number 981149, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981149		 £7.96
17 Part number 181051, Expansion vessel 10 ltr. EXPANSION VESSEL 10 LTR.
Vaillant part no. 181051		 £135.15
18 Part number 150238, automatic bypass valve AUTOMATIC BYPASS VALVE
Vaillant part no. 150238		 £32.27
19   CONNECTION PIECE
Vaillant part no. 084984		 £18.19
20 Part number 022741, Connection tube CONNECTION TUBE
Vaillant part no. 022741
21 Part number 256134, Wiring harness WIRING HARNESS
Vaillant part no. 256134
21 Part number 256149, Wiring harness WIRING HARNESS
Vaillant part no. 256149
22 Part number 160969, pump PUMP
Vaillant part no. 160969		 £186.53
23 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
24 Part number 022669, Connection tube CONNECTION TUBE
Vaillant part no. 022669		 £29.58
25 Part number 022668, Tube TUBE
Vaillant part no. 022668		 £37.75
26 Part number 113952, Tube TUBE
Vaillant part no. 113952		 £30.16
27 Part number 712087, pressure sensor PRESSURE SENSOR
Vaillant part no. 712087		 £22.89
28 Part number 981154, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981154		 £6.69
29 Part number 0020107694, Clip, (PK5) CLIP, (PK5)
Vaillant part no. 0020107694		 £7.03
