VAILLANT
COMBI COMPACT CF VCW GB 240T - (01 Water Valve 04/95)
Appliance Code: 47-044-15

Appliance Diagram


01 Water Valve 04/95 diagram for Vaillant Combi Compact CF VCW GB 240TClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2 Part number 013014, Water valve, upper part WATER VALVE, UPPER PART
Vaillant part no. 013014
3 Part number 981159, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981159		 £6.66
4 Part number 012156, stuffing box STUFFING BOX
Vaillant part no. 012156		 £7.03
5 Part number 981159, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981159		 £6.66
6 Part number 010050, screw SCREW
Vaillant part no. 010050		 £6.66
7 Part number 010003, Screw - Diaphragm SCREW - DIAPHRAGM
Vaillant part no. 010003		 £6.66
8 Part number 104263, spring SPRING
Vaillant part no. 104263		 £3.91
9 Part number 010007, diaphragm disc DIAPHRAGM DISC
Vaillant part no. 010007
10 Part number 010375, Diaphragm (PK5) DIAPHRAGM (PK5)
Vaillant part no. 010375
11 Part number 012944, water quantity regulator, cpl. WATER QUANTITY REGULATOR, CPL.
Vaillant part no. 012944
12 Part number 104267, spring SPRING
Vaillant part no. 104267		 £3.91
13 Part number 010020, Venturi VENTURI
Vaillant part no. 010020		 £8.70
14 Part number 0020107722, Valve VALVE
Vaillant part no. 0020107722		 £7.61
15 Part number 010053, water filter WATER FILTER
Vaillant part no. 010053
16 Part number 012533, Temperature selector TEMPERATURE SELECTOR
Vaillant part no. 012533
17 Part number 981154, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981154		 £6.69
18 Part number 981165, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981165		 £6.69
19 Part number 125117, handle HANDLE
Vaillant part no. 125117		 £5.13
20 Part number 105744, Cheese head screw CHEESE HEAD SCREW
Vaillant part no. 105744		 £3.91
21 Part number 981152, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981152		 £7.03
22 Part number 981150, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981150		 £6.66
23 Part number 010009, spring SPRING
Vaillant part no. 010009		 £6.66
24 Part number 191367, disc DISC
Vaillant part no. 191367		 £3.91
25 Part number 0020107738, OBSOLETE DIAPHRAGM DISC OBSOLETE DIAPHRAGM DISC
Vaillant part no. 0020107738
26 Part number 0020107704, diaphragm DIAPHRAGM
Vaillant part no. 0020107704
27 Part number 088617, fastening set FASTENING SET
Vaillant part no. 088617		 £5.13
31 Part number 012646, servo valve SERVO VALVE
Vaillant part no. 012646
32 Part number 010727, spindle SPINDLE
Vaillant part no. 010727		 £5.13
33   PRICE ON APPLICATION
Vaillant part no. 0000
34 Part number 0020107782, Switch SWITCH
Vaillant part no. 0020107782
35 Part number 150014, hexagonal nut HEXAGONAL NUT
Vaillant part no. 150014		 £3.91
36 Part number 150008, screw SCREW
Vaillant part no. 150008		 £3.91
37 Part number 280715, spring washer SPRING WASHER
Vaillant part no. 280715		 £3.91
38 Part number 0020107698, SPRING SPRING
Vaillant part no. 0020107698
39 Part number 213515, OBSOLETE lever OBSOLETE LEVER
Vaillant part no. 213515
40 Part number 213515, OBSOLETE lever OBSOLETE LEVER
Vaillant part no. 213515
41   DISC
Vaillant part no. 191420		 £3.91
42 Part number 118947, Lens head screw LENS HEAD SCREW
Vaillant part no. 118947		 £5.13
43 Part number 154132, bow BOW
Vaillant part no. 154132		 £5.13
44 Part number 0020107728, CLIP CLIP
Vaillant part no. 0020107728		 £5.13
45   PRICE ON APPLICATION
Vaillant part no. 0000
46 Part number 981155, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981155		 £6.34
47 Part number 235727, screw SCREW
Vaillant part no. 235727		 £5.13
48 Part number 0020107692, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020107692		 £5.13
49 Part number 0020107716, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020107716		 £5.13
50   SAFETY DISC
Vaillant part no. 090034		 £3.91
51 Part number 0020107703, SUPPORT SUPPORT
Vaillant part no. 0020107703
52 Part number 012947, Water quantity regulator WATER QUANTITY REGULATOR
Vaillant part no. 012947		 £7.92
53 Part number 010081, spring SPRING
Vaillant part no. 010081
