]%20sep%2012%20exploded%20view/111/200629125840286123 "Exploded View diagram for Riello RLS 68/M MX 20034839 (Type 779 T)")
You can then pinch & zoom to adjust the size.
| 1 | AIR DAMPER ASSEMBLY Riello part no. 3003948 |
£54.24 | ||
| 2 | GRID (RS70-RS130) Riello part no. 3003949 |
£29.45 | ||
| 3 | SOUND DAMPER Riello part no. 3003952 |
£43.58 | ||
| 4 |  |
INSPECTION WINDOW Riello part no. 3003763 |
£29.45 | |
| 5 |  |
CONNECTOR Riello part no. 3003891 |
£17.62 | |
| 6 |  |
FAN FOR RS 100 Riello part no. 3003964 |
£168.12 | |
| 7 | STARTER Riello part no. 3003960 |
£126.25 | ||
| 8 |  |
SWITCH Riello part no. 3012080 |
£33.51 | |
| 9 |  |
TRANSFORMER Riello part no. 3003785 |
£92.67 | |
| 10 |  |
U BOLT (10PCS) Riello part no. 3003409 |
£23.46 | |
| 11 | FRONT PIECE Riello part no. 3012413 |
|||
| 12 |  |
AIR PRESSURE SW (REPLACES 8016 Riello part no. 3007444 |
£86.27 | |
| 13 | BASE PLATE Riello part no. 3013171 |
|||
| 14 |  |
NOW USE 20144923L CONTROL BOX LFL 1.322 Riello part no. 3006090 |
||
| 14 | CONTROL BOX ASSY Riello part no. 20144923L |
£641.16 | ||
| 15 |  |
PRESSURE SWITCH PLUG Riello part no. 3012347 |
£28.15 | |
| 16 |  |
SEAL Riello part no. 3005482 |
£13.18 | |
| 17 |  |
BRACKET - RS130/M Riello part no. 3012343 |
£19.99 | |
| 18 | JOINT Riello part no. 3013828 |
£50.75 | ||
| 19 | TUBE Riello part no. 3013378 |
|||
| 19 | TUBE Riello part no. 3013385 |
|||
| 20 |  |
COVER Riello part no. 3013119 |
£217.33 | |
| 21 |  |
MOTOR (RS/RL100) Riello part no. 3003967 |
£449.96 | |
| 22 | ANCHOR PLATE Riello part no. 3012585 |
|||
| 23 |  |
SERVO MOTOR RS70-130/M Riello part no. 3012345 |
£939.10 | |
| 24 |  |
SHAFT Riello part no. 3012349 |
£59.42 | |
| 25 | HALF SHELL Riello part no. 3012012 |
|||
| 26 |  |
SCREWS (UP TO SERIAL NO 02406XXXXXX) Riello part no. 3003481 |
£22.87 | |
| 27 | SELECTOR SWITCH Riello part no. 3012310 |
£53.30 | ||
| 28 | BAR Riello part no. 3012213 |
|||
| 29 | TUBE Riello part no. 3013381 |
|||
| 30 |  |
ELEC. LEAD Riello part no. 3003795 |
£53.47 | |
| 31 | ELECTRODE Riello part no. 3013382 |
£62.99 | ||
| 32 | ELECTRODE Riello part no. 3013383 |
£66.33 | ||
| 33 | TUBE Riello part no. 3013377 |
|||
| 34 | AIR DIFFUSER Riello part no. 3013372 |
|||
| 35 | GAS HEAD Riello part no. 3013375 |
£800.22 | ||
| 36 |  |
CONNECTOR 3/8 X 3/8 Riello part no. 3009068 |
£3.92 | |
| 37 | SUPPORT Riello part no. 3013380 |
|||
| 38 | EXTERIOR TUBE Riello part no. 3012039 |
|||
| 39 | ELBOW Riello part no. 3012412 |
|||
| 40 | PUMP MOTOR (FROM SERIAL NO 02446000000) Riello part no. 3013829 |
|||
| 41 | SEAL Riello part no. 3007166 |
£9.35 | ||
| 42 | CONNECTOR Riello part no. 3003864 |
£19.62 | ||
| 43 |  |
GAS PRESSURE SWITCH Riello part no. 3003660 |
£82.62 | |
| 44 | PLUG (10 PCS) Riello part no. 3003996 |
£17.26 | ||
| 45 | FLANGE AND ELBOW Riello part no. 3006803 |
£50.58 | ||
| 46 | CAPACITOR Riello part no. 3013875 |
|||
| 47 |  |
SCREW Riello part no. 3012352 |
£12.99 | |
| 48 |  |
BEARING Riello part no. 3003841 |
£17.05 | |
| 49 |  |
RETURN SPRING Riello part no. 3012356 |
£21.62 | |
| 50 | TIE ROD Riello part no. 3012351 |
|||
| 51 |  |
ANCHOR PLATE Riello part no. 3012594 |
£35.95 | |
| 52 | AIR INTAKE Riello part no. 3012454 |
|||
| 53 |  |
SCREW Riello part no. 3012049 |
£34.11 | |
| 54 | CONTROL DEVICE Riello part no. 3012929 |
|||
| 55 | SHUTTER Riello part no. 3012416 |
|||
| 56 |  |
SEAL (10 PCS) Riello part no. 3007079 |
£7.82 | |
| 57 |  |
SEAL (10 PCS) Riello part no. 3007088 |
£7.40 | |
| 58 | END CONE Riello part no. 3012930 |
£266.52 | ||
| 59 |  |
FLANGE GASKET (RS70-RS1 30) Riello part no. 3003991 |
£15.32 | |
| 60 |  |
CONNECTOR Riello part no. 3003322 |
£8.29 | |
| 61 | MANIFOLD Riello part no. 3013368 |
|||
| 62 | SPRING Riello part no. 3012059 |
£37.50 | ||
| 63 | GRADUATE SECTOR Riello part no. 3012599 |
£38.39 | ||
| 64 | TIE ROD Riello part no. 3012060 |
£14.15 | ||
| 65 |  |
BALL JOINT Riello part no. 3006098 |
£39.77 | |
| 66 | LEVER Riello part no. 3012359 |
|||
| 67 |  |
LEVER Riello part no. 3012354 |
||
| 68 |  |
CAM ASSEMBLY RS/M Riello part no. 3012358 |
£261.21 | |
| 69 |  |
LEVER Riello part no. 3012350 |
£33.99 | |
| 70 |  |
BEARING Riello part no. 3012357 |
£44.60 | |
| 71 | SCREW Riello part no. 3012353 |
|||
| 72 | ADAPTER 3/8 X 1/4 Riello part no. 3005739 |
£12.39 | ||
| 73 |  |
COVER & CLIP 5 PM SPRING (2PCS) Riello part no. 3006097 |
£36.31 | |
| 74 |  |
FLEXIBLE HOSE OIL Riello part no. 20033716 |
£37.61 | |
| 75 | UV DETECTOR Riello part no. 3003396 |
£300.94 | ||
| 76 |  |
PUMP AJ6CC Riello part no. 20033467 |
£425.49 | |
| 77 | SEAL (10 PCS) Riello part no. 3003381 |
£16.83 | ||
| 78 |  |
EXTENSION BARS (UP TO SERIAL NO 02406XXXXXX) Riello part no. 3003956 |
£97.83 | |
| 79 | FILTER + SEAL Riello part no. 20033434 |
|||
| 80 | SUPPORT Riello part no. 3013189 |
|||
| 81 | OVERLOAD Riello part no. 3013190 |
|||
| 82 | RELAY Riello part no. 3012292 |
£109.11 | ||
| 83 | SOCKET Riello part no. 3006953 |
£8.57 | ||
| 84 |  |
SOLENOID VALVE RL130 Riello part no. 3012002 |
£65.76 | |
| 85 | SOCKET Riello part no. 3003592 |
£10.68 | ||
| 86 |  |
WASHER SEAL 10 PCS Riello part no. 3007077 |
£7.57 | |
| 87 | MANIFOLD Riello part no. 3012569 |
|||
| 88 | SUPPORT Riello part no. 3012423 |
|||
| 89 | CONNECTOR Riello part no. 3006722 |
£13.52 | ||
| 90 | TUBE Riello part no. 3013384 |
|||
| 91 |  |
WIELAND PLUG 93.932.5250.0 Riello part no. 3006948 |
£12.99 | |
| 92 |  |
PLUG - 7 PIN - MALE Riello part no. 3006937 |
£25.54 | |
| 93 | 6 POLE PLUG - SOCKET Riello part no. 3013202 |
£30.38 | ||
| 94 |  |
SOCKET 7 PIN Riello part no. 3006938 |
£50.96 | |
| 95 |  |
SOCKET 4 PIN Riello part no. 3006949 |
£15.74 | |
