REMEHA-COMMERCIAL
QUINTA ACE CASCADE KIT 160KW - (Cascade 2)
Appliance Code: CASCADE KIT 160KW

Appliance Diagram


Cascade 2 diagram for Remeha-Commercial Quinta ACE Cascade Kit 160kWClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2001 Part number 7608398, Grundfos UPML 25-105 modulating pump for n/a Quinta Pro 90 & 115* GRUNDFOS UPML 25-105 MODULATING PUMP FOR N/A QUINTA PRO 90 & 115*
Remeha-Commercial part no. 7608398
£418,50
2002 Part number 7637223, Pump Qace 160 - UPMXL25-105 PUMP QACE 160 - UPMXL25-105
Remeha-Commercial part no. 7637223
£571,95
2003   VALVE RETURN
Remeha-Commercial part no. 7638149
£220,06
2004   FLOW VALVE
Remeha-Commercial part no. 7638150
£426,78
2004   SAFETY VALVE 247.5KW 3 BAR
Remeha-Commercial part no. 7643118
£191,73
2005   GAS ISOLATION VALVE
Remeha-Commercial part no. S100110
£186,72
2006   RETURN PIPE
Remeha-Commercial part no. 7638089
£69,02
2007   FLOW PIPE
Remeha-Commercial part no. 7638086
£43,35
2008   GAS PIPE
Remeha-Commercial part no. 7638099
£48,34
2009   GAS PIPE
Remeha-Commercial part no. 7638116
£85,03
2010   FLOW PIPE
Remeha-Commercial part no. 7638115
£85,03
2011   RETURN PIPE
Remeha-Commercial part no. 7638114
£107,04
2012   RETURN PIPE
Remeha-Commercial part no. 7638106
£78,36
2013   FLOW PIPE
Remeha-Commercial part no. 7638101
£80,04
2014   GAS PIPE
Remeha-Commercial part no. 7638104
£76,71
2015   RETURN PIPE
Remeha-Commercial part no. 7638105
£60,52
2016   FLOW PIPE
Remeha-Commercial part no. 7638100
£63,36
2017   GAS PIPE
Remeha-Commercial part no. 7638103
£63,84
2018 Part number S100097, Coupling 1.1/4" - 1.1/2 COUPLING 1.1/4" - 1.1/2
Remeha-Commercial part no. S100097
£80,04
2019 Part number S100096, Coupling 3/4" - 1.1/4 COUPLING 3/4" - 1.1/4
Remeha-Commercial part no. S100096
£76,71
2020   COUPLING 1" - 1 1/4"
Remeha-Commercial part no. 7641014
£30,02
2021 Part number S100089, 1.5" Capped Nut 1.5" CAPPED NUT
Remeha-Commercial part no. S100089
£76,71
2022   CAP NUT 1.1/4" (10 PCS)
Remeha-Commercial part no. S100094
£148,54
2023 Part number S100174, Clamp Ring 28mm (10 pcs) CLAMP RING 28MM (10 PCS)
Remeha-Commercial part no. S100174
£72,54
2024 Part number S100173, 35mm Clamp Ring (10pcs)(Cascade) 35MM CLAMP RING (10PCS)(CASCADE)
Remeha-Commercial part no. S100173
£101,87
2025 Part number S100105, Gasket 44mm o/d x 32mm I/d x 3mm (10 pcs.) GASKET 44MM O/D X 32MM I/D X 3MM (10 PCS.)
Remeha-Commercial part no. S100105
£8,96
2026 Part number S100107, Gasket 38mm o/d x 25mm I/d x 3mm (10 pcs.) GASKET 38MM O/D X 25MM I/D X 3MM (10 PCS.)
Remeha-Commercial part no. S100107
£14,93
2027   RETURN PIPE
Remeha-Commercial part no. 7638118
£133,38
2027   FLOW PIPE
Remeha-Commercial part no. 7638119
£141,70
2028   RETURN PIPE
Remeha-Commercial part no. 7638120
£120,88
2028   FLOW PIPE
Remeha-Commercial part no. 7638121
£145,04
