REMEHA-COMMERCIAL
GAS 220 ACE 200 KW AFTER SERIAL NO STARTING 20251 - (Heat Exchanger)
Appliance Code: GAS 220 ACE 200 KW AFTER

Appliance Diagram


Heat Exchanger diagram for Remeha-Commercial Gas 220 ACE 200 kW AFTER SERIAL NO STARTING 20251Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 7669093, Service kit -A- (200-300 kW) SERVICE KIT -A- (200-300 KW)
Remeha-Commercial part no. 7669093		 £89.70
  SERVICE KIT -B- (200-300 KW)
Remeha-Commercial part no. 7669095		 £122.06
  SERVICE KIT -C- (200-300 KW)
Remeha-Commercial part no. 7669097		 £220.00
2001   HEAT EXCHANGER 200-300 KW
Remeha-Commercial part no. 7651658		 £5,884.59
2002 Part number 7624346, Heat Exchanger Access Plate (Quinta Ace) HEAT EXCHANGER ACCESS PLATE (QUINTA ACE)
Remeha-Commercial part no. 7624346		 £42.71
2003 Part number 7624368, Access Plate Gasket (Quinta Ace) ACCESS PLATE GASKET (QUINTA ACE)
Remeha-Commercial part no. 7624368		 £20.58
2004   PREMIX BURNER 200-300 KW
Remeha-Commercial part no. 7653025		 £1,863.60
2005   ELECTRODE IGNITION/IONISATION
Remeha-Commercial part no. 7666694		 £39.74
2006 Part number S62105, Gasket for electrode (10 pcs.) GASKET FOR ELECTRODE (10 PCS.)
Remeha-Commercial part no. S62105		 £28.98
2007 Part number S101509, Screw 7985 M4X8 (5 Pcs) SCREW 7985 M4X8 (5 PCS)
Remeha-Commercial part no. S101509		 £13.39
2009   GASKET FOR BURNER 200-300 KW
Remeha-Commercial part no. 7662766		 £17.74
2010 Part number S44483, Nut M 8 (10 pcs.) NUT M 8 (10 PCS.)
Remeha-Commercial part no. S44483		 £17.49
2011   SCREWS - MIXER GAS-AIR
Remeha-Broag part no. 7653268
2012 Part number 7623718, Resonator Foam (6pcs) (Quinta Ace) RESONATOR FOAM (6PCS) (QUINTA ACE)
Remeha-Commercial part no. 7623718		 £32.65
2013 Part number S59118, GLASS INSPECTION SET GLASS INSPECTION SET
Remeha-Commercial part no. S59118		 £44.14
2014 Part number S54755, FLANGE NUT M6 FLANGE NUT M6
Remeha-Commercial part no. S54755		 £25.55
2015   MIXING ADAPTER BURNER SIDE 200
Remeha-Commercial part no. 7653050		 £411.61
2016   PIPE RETURN UPPER
Remeha-Commercial part no. 7662727		 £214.33
2017   NOW USE 7720082 LOWER RETURN TUBE 200-300KW
Remeha-Broag part no. 7663601
2017   S PIPE RETURN LOWER 300KW FSB
Remeha-Broag part no. 7720082		 £364.63
2018 Part number S41601, Air vent 1/8" AIR VENT 1/8"
Remeha-Commercial part no. S41601		 £54.35
2019 Part number 7643604, Flange Blind FLANGE BLIND
Remeha-Broag part no. 7643604		 £19.88
2020 Part number 7643603, Gasket GASKET
Remeha-Broag part no. 7643603		 £7.91
2021 Part number S55703, Filling and drain cock -¢" FILLING AND DRAIN COCK -¢"
Remeha-Commercial part no. S55703		 £75.23
2022   CONNECTION AIR VENT/PRESSURE SENSOR
Remeha-Commercial part no. 7632712		 £14.61
2023   SET STUDS M6 X 20MM (6X) + M8 X 25 (3X)
Remeha-Broag part no. 7651584		 £6.79
2023 Part number 7624721, Set inserts (M4/M8) SET INSERTS (M4/M8)
Remeha-Commercial part no. 7624721		 £32.65
2024   BRACKET (2X)
Remeha-Commercial part no. 7662393		 £16.19
2025 Part number 7628285, O-Ring 40.64 x 5.33mm (5x) O-RING 40.64 X 5.33MM (5X)
Remeha-Broag part no. 7628285		 £11.99
2026   O RING 56.52X5.33MM (X5)
Remeha-Broag part no. 7677068		 £11.46
2027 Part number 7625030, Screw M8 x 22 (10x) SCREW M8 X 22 (10X)
Remeha-Broag part no. 7625030		 £7.51
2028   O RING 78.74X5.33MM (X2)
Remeha-Broag part no. 7666866		 £11.25
2032   CONDENSATE COLLECTOR 200 - 300
Remeha-Broag part no. 7664873		 £375.60
2032   CONDENSATE COLLECTOR 300
Remeha-Broag part no. 7720083
2033 Part number 7628372, Screw M8 x 12 (8x) SCREW M8 X 12 (8X)
Remeha-Broag part no. 7628372		 £7.38
2034 Part number 7632665, Cap Condensate Tray CAP CONDENSATE TRAY
Remeha-Commercial part no. 7632665		 £19.16
2035 Part number 7648647, Sealing Ring +© 60 (2 pcs) SEALING RING +© 60 (2 PCS)
Remeha-Broag part no. 7648647		 £3.87
2036 Part number S47170, Hose Silicone D:4Mm I/D-8Mm (1 Meter) HOSE SILICONE D:4MM I/D-8MM (1 METER)
Remeha-Commercial part no. S47170		 £19.16
2040   FLOW PIPE CENTRAL HEATING
Remeha-Commercial part no. 7662757		 £158.96
2041   SET GROMMETS (RED BLEU AND YE
Remeha-Commercial part no. 7666722		 £16.19
2045   SEALING RING FLUE DIA 200 (2 P
Remeha-Commercial part no. 7662701		 £16.19
2047   GROMMET FLUE GAS SENSOR
Remeha-Commercial part no. 7625053		 £5.45
2048   FLUE GAS PIPE 200 MM
Remeha-Commercial part no. 7662700		 £154.71
2049   SEALING RING DIA 188 (2X)
Remeha-Commercial part no. 7662708		 £14.61
2050   SIPHON CLICKER
Remeha-Broag part no. 7623417		 £21.60
2050   SIPHON
Remeha-Broag part no. 7720054		 £25.55
2051 Part number 7638948, Sealing Ring Siphon SEALING RING SIPHON
Remeha-Commercial part no. 7638948		 £5.59
2052 Part number 7638947, Siphon SIPHON
Remeha-Commercial part no. 7638947		 £28.39
2053 Part number 7639172, Condensate Drain CONDENSATE DRAIN
Remeha-Commercial part no. 7639172		 £11.00
