REMEHA-BROAG
AVANTA PLUS SYSTEM 30S - (Heat Exchanger)
Appliance Code: 41-288-12

Appliance Diagram


Heat Exchanger diagram for Remeha-Broag Avanta Plus System 30SClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2001 Part number 720544601, HEAT EXCHANGER 24/28KW HEAT EXCHANGER 24/28KW
Remeha-Broag part no. 720544601		 £574.46
2001 Part number 720593901, NOW USE S100014 HEAT EXCHANGER 35C NOW USE S100014 HEAT EXCHANGER 35C
Remeha-Broag part no. 720593901
2001 Part number S100014, HEAT EXCHANGER 35C HEAT EXCHANGER 35C
Remeha-Broag part no. S100014		 £825.38
2003 Part number S100017, BURNER 35KW(39KW LPG) BURNER 35KW(39KW LPG)
Remeha-Broag part no. S100017		 £66.31
2003 Part number 720435501, NOW USE S100017 BURNER 35/39KW (LPG) NOW USE S100017 BURNER 35/39KW (LPG)
Remeha-Broag part no. 720435501
2003 Part number 720541701, BURNER 18/24/28KW BURNER 18/24/28KW
Remeha-Broag part no. 720541701		 £78.30
2004 Part number 720481201, NOW USE S62743 ELECTRODE IGNITION/IONISATION C/W LEAD NOW USE S62743 ELECTRODE IGNITION/IONISATION C/W LEAD
Remeha-Broag part no. 720481201
2004 Part number S62743, ignition/ionisation electrode IGNITION/IONISATION ELECTRODE
Remeha-Broag part no. S62743		 £35.78
2005   GLASS INSPECTION SET
Baxi part no. S59118		 £42.99
2005 Part number 720537401, NOW USE S59118 GLASS INSPECTION SET NOW USE S59118 GLASS INSPECTION SET
Remeha-Broag part no. 720537401
2006 Part number 720557701, NOW USE 7219281 INSULATION BURNER FRONT PLATE NOW USE 7219281 INSULATION BURNER FRONT PLATE
Remeha-Broag part no. 720557701
2006 Part number 7219281, INSULATION BURNER FRONT PLATE INSULATION BURNER FRONT PLATE
Remeha-Broag part no. 7219281		 £78.82
2007 Part number 720714701, ADAPTER LOW PROFILE ADAPTER LOW PROFILE
Remeha-Broag part no. 720714701		 £11.16
2008 Part number 720538801, NOW USE S62232 SCREW CAP FLUE GAS MEASURE POINT (5 PCS) NOW USE S62232 SCREW CAP FLUE GAS MEASURE POINT (5 PCS)
Remeha-Broag part no. 720538801
2008 Part number S62232, Screw cap flue gas measure point (5 pcs) Quinta PRO SCREW CAP FLUE GAS MEASURE POINT (5 PCS) QUINTA PRO
Remeha-Commercial part no. S62232		 £36.90
2009 Part number 720534401, PIPING SET HYDRAULIC (28CECO) PIPING SET HYDRAULIC (28CECO)
Remeha-Broag part no. 720534401		 £245.32
2009   OBSOLETE PIPING SET HYDRAULIC 24S 28C 35C
Remeha-Broag part no. 720542501
2010 Part number 720480901, NOW USE S62728 VENT AUTO AIR BLEED DEVICE NOW USE S62728 VENT AUTO AIR BLEED DEVICE
Remeha-Broag part no. 720480901
2010   AUTO AIR VENT BLEED DEVICE 3/8
Baxi part no. S62728		 £42.99
2011 Part number 7731044, ERP PUMP - CONTROL ERP PUMP - CONTROL
Remeha-Broag part no. 7731044		 £296.93
2011 Part number 720481301, NOW USE 7731044 PUMP GRUNDFOS 15-60 FOR 24/28KW NOW USE 7731044 PUMP GRUNDFOS 15-60 FOR 24/28KW
Remeha-Broag part no. 720481301
2012 Part number 720542001, NOW USE S62749 SYPHON ASSEMBLY NOW USE S62749 SYPHON ASSEMBLY
Remeha-Broag part no. 720542001
2012 Part number S62749, SYPHON ASSEMBLY SYPHON ASSEMBLY
Remeha-Commercial part no. S62749		 £28.44
2013 Part number 720480501, SENSOR TEMPERATURE (2 PCS) SENSOR TEMPERATURE (2 PCS)
Remeha-Broag part no. 720480501		 £53.47
2014   GASKET FOR COVER PLATE HEAT EXCHANGER (10 PCS)
Remeha-Broag part no. 720538401		 £66.79
2015 Part number 720480101, GASKET FOR BURNER (5 PCS) GASKET FOR BURNER (5 PCS)
Remeha-Broag part no. 720480101		 £36.85
2016 Part number 720540101, NOW USE S62718 O RING 94X2 (10 PCS) NOW USE S62718 O RING 94X2 (10 PCS)
Remeha-Broag part no. 720540101
2016 Part number S62718, O-RING 94 X 2 (10 PCS.) O-RING 94 X 2 (10 PCS.)
Remeha-Broag part no. S62718		 £25.18
2017 Part number S62105, Gasket for electrode (10 pcs.) GASKET FOR ELECTRODE (10 PCS.)
Remeha-Commercial part no. S62105		 £28.98
2017 Part number 720538601, NOW USE S62105 GASKET FOR ELECTRODE (10 PCS) NOW USE S62105 GASKET FOR ELECTRODE (10 PCS)
Remeha-Broag part no. 720538601
2018 Part number 720538301, HAIRPIN SPRING (10 PCS) HAIRPIN SPRING (10 PCS)
Remeha-Broag part no. 720538301		 £28.71
2019 Part number 720536101, HAIRPIN SPRING (10 PCS) HAIRPIN SPRING (10 PCS)
Remeha-Broag part no. 720536101		 £16.01
2020 Part number 720538501, O RING (10 PCS) O RING (10 PCS)
Remeha-Broag part no. 720538501		 £16.49
2021 Part number 720535601, NOW USE S56155 GASKET 23.8MM O/D X 17.2MM I/D X 2MM (20 PCS) NOW USE S56155 GASKET 23.8MM O/D X 17.2MM I/D X 2MM (20 PCS)
Remeha-Broag part no. 720535601
2021 Part number S56155, Gasket 23.8 x 17.2 (20pc) GASKET 23.8 X 17.2 (20PC)
Remeha-Commercial part no. S56155		 £29.81
2023 Part number S54755, FLANGE NUT M6 FLANGE NUT M6
Remeha-Commercial part no. S54755		 £25.55
2023 Part number 720535501, NOW USE S54755 NUT FLANGE M6 (20 PCS) NOW USE S54755 NUT FLANGE M6 (20 PCS)
Remeha-Broag part no. 720535501
2024 Part number 720535301, NOW USE S48950 SCREW M4X10 (50 PCS) NOW USE S48950 SCREW M4X10 (50 PCS)
Remeha-Broag part no. 720535301
2024 Part number S48950, Screw M4x10 (50 pcs.) SCREW M4X10 (50 PCS.)
Remeha-Commercial part no. S48950		 £17.74
2025 Part number 720536001, O RING (10 PCS) O RING (10 PCS)
Remeha-Broag part no. 720536001		 £14.58
2026 Part number 720481001, NOW USE S62733 GAUGE PRESSURE C/W CAPILLARY NOW USE S62733 GAUGE PRESSURE C/W CAPILLARY
Remeha-Broag part no. 720481001
2026 Part number S62733, Manometer Pressure Gauge MANOMETER PRESSURE GAUGE
Remeha-Broag part no. S62733		 £26.77
2027 Part number 720542101, COVER GAS/AIR CHAMBER COVER GAS/AIR CHAMBER
Remeha-Broag part no. 720542101		 £62.51
2028 Part number 720540201, NOW USE S62719 GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS) NOW USE S62719 GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS)
Remeha-Broag part no. 720540201
2028 Part number S62719, GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS.) GASKET BETWEEN FRONT PLATE AND MIXING CHAMBER (10 PCS.)
Remeha-Broag part no. S62719		 £39.98
2029 Part number S62742, COVER PLATE FOR BURNER COVER PLATE FOR BURNER
Remeha-Broag part no. S62742		 £39.11
2029 Part number 720541801, NOW USE S62742 COVER PLATE FOR BURNER NOW USE S62742 COVER PLATE FOR BURNER
Remeha-Broag part no. 720541801
2030 Part number 720541001, NOW USE S62729 VALVE NON RETURN (FOR AUTO AIR VENT) (5 PCS) NOW USE S62729 VALVE NON RETURN (FOR AUTO AIR VENT) (5 PCS)
Remeha-Broag part no. 720541001
2030   VALVE NON RETURN (FOR AUTO AIR
Baxi part no. S62729		 £34.86
2031 Part number S62711, GROMMET 48MM X 28MM. (5 PCS) GROMMET 48MM X 28MM. (5 PCS)
Remeha-Broag part no. S62711		 £25.05
2031 Part number 720539601, NOW USE S62711 GROMMET 48MMX28MM (5 PCS) NOW USE S62711 GROMMET 48MMX28MM (5 PCS)
Remeha-Broag part no. 720539601
2032 Part number 720534901, NOW USE S44483 NUT M8 (10 PCS) NOW USE S44483 NUT M8 (10 PCS)
Remeha-Broag part no. 720534901
2032 Part number S44483, Nut M 8 (10 pcs.) NUT M 8 (10 PCS.)
Remeha-Commercial part no. S44483		 £17.49
2035 Part number S62753, EXPANSION VESSEL EXPANSION VESSEL
Remeha-Broag part no. S62753		 £94.73
2035 Part number 720542301, NOW USE S62753 EXPANSION VESSEL NOW USE S62753 EXPANSION VESSEL
Remeha-Broag part no. 720542301
2037 Part number 720539901, NOW USE S62714 O RING 9.19X2.62 (10 PCS) NOW USE S62714 O RING 9.19X2.62 (10 PCS)
Remeha-Broag part no. 720539901
2037 Part number S62714, O-RING 9.19 X 2.62 (10 PCS.) O-RING 9.19 X 2.62 (10 PCS.)
Remeha-Broag part no. S62714		 £15.37
2038   HAIRPIN SPRING (10 PCS)
Remeha-Broag part no. 720539701		 £9.82
2039 Part number 720539001, SEALING RING SYPHON SEALING RING SYPHON
Remeha-Broag part no. 720539001		 £31.98
2040 Part number 720539801, NOW USE S62713 O RING 20X2.5 (10 PCS) NOW USE S62713 O RING 20X2.5 (10 PCS)
Remeha-Commercial part no. 720539801
2040   O-RING 20 X 2,5 (10PCS)
Baxi part no. S62713		 £16.09
2041   SPACER 15MM (5 PCS)
Remeha-Broag part no. 720545801		 £26.56
2042   PIPE BETWEEN PUMP AND EXPANSION VESSEL
Remeha-Broag part no. 720542701		 £16.69
2043 Part number 720538901, NOW USE S62233 CAP MEASURE POINT AIR INLET (5 PCS) NOW USE S62233 CAP MEASURE POINT AIR INLET (5 PCS)
Remeha-Broag part no. 720538901
2043 Part number S62233, CAP CAP
Remeha-Commercial part no. S62233		 £28.98
2046 Part number 720532801, PUMP AIR VENT PUMP AIR VENT
Remeha-Broag part no. 720532801		 £54.69
