REMEHA-COMMERCIAL
GAS 220 ACE 200 KW AFTER SERIAL NO STARTING 20251 - (Exploded View)
Appliance Code: GAS 220 ACE 200 KW AFTER

Appliance Diagram


Exploded View diagram for Remeha-Commercial Gas 220 ACE 200 kW AFTER SERIAL NO STARTING 20251Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 7669093, Service kit -A- (200-300 kW) SERVICE KIT -A- (200-300 KW)
Remeha-Commercial part no. 7669093		 £103.28
  SERVICE KIT -B- (200-300 KW)
Remeha-Commercial part no. 7669095		 £139.73
  SERVICE KIT -C- (200-300 KW)
Remeha-Commercial part no. 7669097		 £252.72
1001   CASING FRONT (GAS 220)
Remeha-Commercial part no. 7656887		 £613.58
1002   SCREW & WASHER (2X)
Remeha-Commercial part no. 7656698		 £10.15
1003 Part number S62709, SEAL FOR FRONT CASING (10M) SEAL FOR FRONT CASING (10M)
Remeha-Broag part no. S62709		 £46.06
1004   CABLE COVER
Remeha-Commercial part no. 7656809		 £35.79
1005   THULE
Remeha-Commercial part no. 7656583		 £11.09
1006 Part number 7623421, Quint Ace Light QUINT ACE LIGHT
Remeha-Commercial part no. 7623421		 £69.26
1007   PIPE CLAMP (2X)
Remeha-Commercial part no. 7664558		 £9.26
1008   AIR INLET DAMPER - 150MM
Remeha-Broag part no. 7639307
1009   FLUE CONNECTION 150 MM
Remeha-Commercial part no. 7656693		 £40.68
1010 Part number S57163, Cap for connection piece chimney (Pk2) CAP FOR CONNECTION PIECE CHIMNEY (PK2)
Remeha-Commercial part no. S57163		 £23.60
1011   FLUE SEALING RING 150MM (2PCS)
Remeha-Commercial part no. 7624778		 £21.98
1012   SCREW 4.2X9.5MM (10PCS)
Remeha-Broag part no. 7638951		 £2.53
1013   SCREW M5X12 (10 PCS)
Remeha-Commercial part no. S100468		 £21.98
1014   ADAPTER RING 200-150
Remeha-Commercial part no. 7656690		 £18.55
1015   GROMMET BLIND 80MM (2X)
Remeha-Commercial part no. 7656581		 £11.09
2001   HEAT EXCHANGER 150 KW FSB
Remeha-Commercial part no. 7651638		 £4,988.79
2002 Part number 7624346, Heat Exchanger Access Plate (Quinta Ace) HEAT EXCHANGER ACCESS PLATE (QUINTA ACE)
Remeha-Commercial part no. 7624346		 £48.95
2003 Part number 7624368, Access Plate Gasket (Quinta Ace) ACCESS PLATE GASKET (QUINTA ACE)
Remeha-Commercial part no. 7624368		 £23.60
2004   PREMIX BURNER (QUINTA ACE)
Remeha-Commercial part no. 7628638		 £777.60
2005   ELECTRODE IGNITION/IONISATION (QUINTA ACE)
Remeha-Commercial part no. 7624711		 £45.54
2006 Part number S62105, Gasket for electrode (10 pcs.) GASKET FOR ELECTRODE (10 PCS.)
Remeha-Commercial part no. S62105		 £33.22
2007 Part number S101509, Screw 7985 M4X8 (5 Pcs) SCREW 7985 M4X8 (5 PCS)
Remeha-Commercial part no. S101509		 £15.36
2009 Part number 7638972, Burner Gasket (Quinta Ace) BURNER GASKET (QUINTA ACE)
Remeha-Commercial part no. 7638972		 £15.53
2010 Part number S44483, Nut M 8 (10 pcs.) NUT M 8 (10 PCS.)
Remeha-Commercial part no. S44483		 £20.05
2011   FASTENER SET (GAS/AIR SYSTEM)(QUINTA ACE)
Remeha-Broag part no. 7628712		 £29.05
2012 Part number 7623718, Resonator Foam (6pcs) (Quinta Ace) RESONATOR FOAM (6PCS) (QUINTA ACE)
Remeha-Commercial part no. 7623718		 £37.43
2013 Part number S59118, GLASS INSPECTION SET GLASS INSPECTION SET
Remeha-Commercial part no. S59118		 £50.58
2014 Part number S54755, FLANGE NUT M6 FLANGE NUT M6
Remeha-Commercial part no. S54755		 £29.29
2015   MIXING ADAPTER - BURNER SIDE (QUINTA ACE)
Remeha-Broag part no. 7628637		 £187.11
2016   PIPE RETURN UPPER
Remeha-Commercial part no. 7656755		 £227.21
2017   S PIPE RETURN LOWER 150KW FSB
Remeha-Broag part no. 7720058		 £220.00
2018 Part number S41601, Air vent 1/8" AIR VENT 1/8"
Remeha-Commercial part no. S41601		 £62.29
2019 Part number 7643604, Flange Blind FLANGE BLIND
Remeha-Broag part no. 7643604		 £22.79
2020 Part number 7643603, Gasket GASKET
Remeha-Broag part no. 7643603		 £9.09
2021 Part number S55703, Filling and drain cock 1/2" FILLING AND DRAIN COCK 1/2"
Remeha-Commercial part no. S55703		 £86.27
2022   CONNECTION AIR VENT/PRESSURE SENSOR
Remeha-Commercial part no. 7632712		 £16.75
2023 Part number 7624721, Set inserts (M4/M8) SET INSERTS (M4/M8)
Remeha-Commercial part no. 7624721		 £37.43
2023   SET STUDS M6 X 20MM (6X) + M8 X 25 (3X)
Remeha-Broag part no. 7651584		 £7.79
2024   BRACKET (2X)
Remeha-Commercial part no. 7662393		 £18.55
2025 Part number 7628285, O-Ring 40.64 x 5.33mm (5x) O-RING 40.64 X 5.33MM (5X)
Remeha-Broag part no. 7628285		 £13.75
2026   O-RING 56.52 X 5.33 MM (5X)
Remeha-Commercial part no. 7656695		 £13.86
2027 Part number 7625030, Screw M8 x 22 (10x) SCREW M8 X 22 (10X)
Remeha-Broag part no. 7625030		 £8.61
2032   CONDENSATE COLLECTOR FSB
Remeha-Commercial part no. 7656558		 £436.19
2033 Part number 7628372, Screw M8 x 12 (8x) SCREW M8 X 12 (8X)
Remeha-Broag part no. 7628372		 £8.46
2034 Part number 7632665, Cap Condensate Tray CAP CONDENSATE TRAY
Remeha-Commercial part no. 7632665		 £21.98
2035 Part number 7648647, Sealing Ring Ø 60 (2 pcs) SEALING RING Ø 60 (2 PCS)
Remeha-Broag part no. 7648647		 £9.78
2036 Part number S47170, Hose Silicone D:4Mm I/D-8Mm (1 Meter) HOSE SILICONE D:4MM I/D-8MM (1 METER)
Remeha-Commercial part no. S47170		 £21.98
2040   FLOW PIPE
Remeha-Commercial part no. 7656762		 £171.32
2041   SET GROMMETS (RED BLEU AND YE
Remeha-Commercial part no. 7656696		 £37.43
2045   FLUE SEALING RING 150MM (2PCS)
Remeha-Commercial part no. 7624778		 £21.98
2047   GROMMET FLUE GAS SENSOR
Remeha-Commercial part no. 7625053		 £6.26
2048   FLUE GAS PIPE 150
Remeha-Commercial part no. 7637749		 £144.59
2049 Part number 7624779, Sealing Ring Ø 118 (2x) SEALING RING Ø 118 (2X)
Remeha-Commercial part no. 7624779		 £12.82
2050   SIPHON
Remeha-Broag part no. 7720054		 £25.55
2051 Part number 7638948, Sealing Ring Siphon SEALING RING SIPHON
Remeha-Commercial part no. 7638948		 £6.40
2052 Part number 7638947, Siphon SIPHON
Remeha-Commercial part no. 7638947		 £28.39
2053 Part number 7639172, Condensate Drain CONDENSATE DRAIN
Remeha-Commercial part no. 7639172		 £12.60
3001 Part number 7628630, Fan including Venturi FAN INCLUDING VENTURI
Remeha-Commercial part no. 7628630		 £611.15
3002 Part number 7628636, Gas Valve 160 GAS VALVE 160
Remeha-Commercial part no. 7628636		 £725.36
3003 Part number 7628639, Venturi Lower VENTURI LOWER
Remeha-Commercial part no. 7628639		 £57.28
3004 Part number 7628710, Set Sealings SET SEALINGS
Remeha-Commercial part no. 7628710		 £43.92
3005   FASTENER SET (GAS/AIR SYSTEM)(QUINTA ACE)
Remeha-Broag part no. 7628712		 £29.05
3006   MIXING ADAPTER FAN SIDE
Remeha-Commercial part no. 7628462		 £126.36
3007 Part number 7628641, Gas Connection GAS CONNECTION
Remeha-Broag part no. 7628641		 £32.79
3008 Part number S100619, O-RING D:52,39X3,53 (5 PCS.) O-RING D:52,39X3,53 (5 PCS.)
Remeha-Commercial part no. S100619		 £11.25
3009   GAS PIPE
Remeha-Broag part no. 7628642		 £68.14
3010 Part number S44483, Nut M 8 (10 pcs.) NUT M 8 (10 PCS.)
Remeha-Commercial part no. S44483		 £20.05
3011 Part number S103356, Pressure Test Nipple 1/8" (2x) PRESSURE TEST NIPPLE 1/8" (2X)
Remeha-Commercial part no. S103356		 £48.95
3012   GAS PIPE
Remeha-Commercial part no. 7656688		 £185.90
3013   WASHER D8 X 24 X 3 MM (10X)
Remeha-Commercial part no. 7660018		 £21.98
3013 Part number S44483, Nut M 8 (10 pcs.) NUT M 8 (10 PCS.)
Remeha-Commercial part no. S44483		 £20.05
3014   SET GROMMETS (RED BLEU AND YE
Remeha-Commercial part no. 7656696		 £37.43
3015 Part number 7633294, Air Inlet Damper AIR INLET DAMPER
Remeha-Commercial part no. 7633294		 £52.22
3016 Part number S103260, Bolt M 8 X 20 (10 Pcs.) BOLT M 8 X 20 (10 PCS.)
Remeha-Commercial part no. S103260		 £12.21
3017   WASHER 8.4MM +Y - PACK OF 25
Remeha-Commercial part no. S100088		 £11.25
4001 Part number 7718238, NOW USE 7818339 CONTROLS PANEL NOW USE 7818339 CONTROLS PANEL
Remeha-Broag part no. 7718238
4001   CONTROLS FOR PCB-SCB-10
Remeha-Broag part no. 7818339		 £1,389.96
4002 Part number 7633327, Configuration Storage Unit CSU-01 CONFIGURATION STORAGE UNIT CSU-01
Remeha-Commercial part no. 7633327		 £37.43
4003 Part number 7628633, Housing Burner Control HOUSING BURNER CONTROL
Remeha-Broag part no. 7628633		 £22.39
4004   FASTENER SET (GAS/AIR SYSTEM)(QUINTA ACE)
Remeha-Broag part no. 7628712		 £29.05
4005 Part number 7623837, Sensors Set Double NTC 10k (1x) and NTC SENSORS SET DOUBLE NTC 10K (1X) AND NTC
Remeha-Commercial part no. 7623837		 £18.55
4006   SENSOR WATER PRESSURE (503)
Remeha-Commercial part no. 7656640		 £130.01
4007 Part number 7624619, Transformer Ignition TRANSFORMER IGNITION
Remeha-Commercial part no. 7624619		 £18.55
4009   SWITCH POWER ON/OFF BLACK
Remeha-Commercial part no. 7625392		 £23.60
4010   CONNECTOR RJ-11 BLACK
Remeha-Commercial part no. 7625393		 £23.60
4011   S HMI MK2 2.0 RMH
Remeha-Broag part no. 7669597		 £109.35
4012   NOW USE 7766829 MOUNTING PLATE - CONTROL PANEL
Remeha-Broag part no. 7640379
4012   MOUNTING PLATE + COVER PANEL
Remeha-Commercial part no. 7766829		 £216.27
4013   MOUNTING PLATE + COVER PANEL
Remeha-Commercial part no. 7766829		 £216.27
4013   NOW USE 7766829 FRONT INSTRUMENT PANEL
Remeha-Commercial part no. 7656874
4014 Part number 7612543, Set Strain Relief SET STRAIN RELIEF
Remeha-Broag part no. 7612543		 £26.71
4015 Part number 7636069, NOW USE 7734501 PCB SCB-02 (CURRENTLY UNAVAILABLE FROM REMEHA) NOW USE 7734501 PCB SCB-02 (CURRENTLY UNAVAILABLE FROM REMEHA)
Remeha-Commercial part no. 7636069
4015   S PCB SCB-02
Remeha-Commercial part no. 7734501		 £249.08
4016 Part number 7635886, PCB SCB-01 PCB SCB-01
Remeha-Commercial part no. 7635886		 £108.14
4017   COVER HMI
Remeha-Commercial part no. 7657321		 £37.43
4018 Part number 7635885, Connector Block CB-01 CONNECTOR BLOCK CB-01
Remeha-Commercial part no. 7635885		 £77.76
4019 Part number 7643773, Pressure Differential Switch PRESSURE DIFFERENTIAL SWITCH
Remeha-Commercial part no. 7643773		 £144.59
4020 Part number 7624643, Flue Gas Sensor NTC 2x 20k FLUE GAS SENSOR NTC 2X 20K
Remeha-Commercial part no. 7624643		 £16.44
4021 Part number 7628708, Cable Fan/gas valve CABLE FAN/GAS VALVE
Remeha-Commercial part no. 7628708		 £111.78
4022   CABLE HARNESS 24V
Remeha-Commercial part no. 7657380		 £116.64
4023   CABLE HARNESS 230V
Remeha-Commercial part no. 7657382		 £75.33
4024   SCREW M5X12 (10 PCS)
Remeha-Commercial part no. S100468		 £21.98
4025   CABLE POWER SUPPLY 230V
Remeha-Broag part no. 7667010		 £26.03
4026   SCREW (2X)
Remeha-Commercial part no. 7653638		 £5.56
4027   SLIDER CONTROL BOX (2X)
Remeha-Commercial part no. 7656853		 £9.26
4028 Part number 7637776, Cable Control Box internal 24v CABLE CONTROL BOX INTERNAL 24V
Remeha-Commercial part no. 7637776		 £42.29
4029 Part number 7637775, Cable Control Box internal 230v CABLE CONTROL BOX INTERNAL 230V
Remeha-Commercial part no. 7637775		 £18.55
4030   CLIP TRANSFORMER IGNITION
Remeha-Broag part no. 7632708		 £7.11
4031 Part number S101509, Screw 7985 M4X8 (5 Pcs) SCREW 7985 M4X8 (5 PCS)
Remeha-Commercial part no. S101509		 £15.36
4032 Part number S103247, Clip Pressure Differential Switch (5x) CLIP PRESSURE DIFFERENTIAL SWITCH (5X)
Remeha-Commercial part no. S103247		 £16.92
4033 Part number S62185, Screw Kb30X8 (10 Pcs) SCREW KB30X8 (10 PCS)
Remeha-Commercial part no. S62185		 £20.34
4034 Part number S6778, Fuse Glass 6.3A Slow (pkt of 10) FUSE GLASS 6.3A SLOW (PKT OF 10)
Remeha-Commercial part no. S6778		 £42.29
4035   NOW USE 7706567 HMI MK3 BLACK
Remeha-Commercial part no. 7660024
4035   S MK3 REMEHA
Remeha-Commercial part no. 7706567		 £227.09
4036 Part number 7636070, PCB SCB-10 PCB SCB-10
Remeha-Commercial part no. 7636070		 £296.74
4037 Part number 7638965, Installer Box INSTALLER BOX
Remeha-Commercial part no. 7638965		 £95.99


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
