REMEHA-COMMERCIAL
QUINTA ACE CASCADE KIT 160KW - (Cascade 1)
Appliance Code: CASCADE KIT 160KW

Appliance Diagram


Cascade 1 diagram for Remeha-Commercial Quinta ACE Cascade Kit 160kWClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1001   MAIN PIPING SET DN100 - 3 BOILERS ACE
Remeha-Commercial part no. 7611306
£2,215.59
1001   MAIN PIPING SET DN100 - 2 BOILERS ACE
Remeha-Commercial part no. 7614795
£1,518.69
1002 Part number 7633244, Connection Piece DN100 to DN65 for LLH DN65 CONNECTION PIECE DN100 TO DN65 FOR LLH DN65
Remeha-Commercial part no. 7633244
£216.27
1002   LOW LOSS HEADER DN65
Remeha-Commercial part no. S100122
£1,105.66
1002   LOW LOSS HEADER DN100
Remeha-Commercial part no. S100123
£1,579.74
1002   LOW LOSS HEADER DN65 (<350KW)
Remeha-Commercial part no. S100645
£587.61
1003   EXTENSION GAS PIPE DN65
Remeha-Commercial part no. S100160
£357.68
1004   ELBOW DN100
Remeha-Commercial part no. S100166
£1,009.15
1004   ELBOW DN65
Remeha-Commercial part no. S100168
£647.23
1005 Part number S101656, Gas Filter DN65 GAS FILTER DN65
Remeha-Commercial part no. S101656
£1,157.50
1006   COUNTER FLANGES DN65 (W+G)
Remeha-Commercial part no. 7638518
£167.48
1006   FLANGE COUNTER DN1 00
Remeha-Commercial part no. S100278
£215.74
1007   FLANGE BLANK DIN252 7 DN100
Remeha-Commercial part no. S100091
£151.00
1008   FLANGE BLANK DIN2527 DN65
Remeha-Commercial part no. S100144
£238.45
1009   GASKET 100MM (5PCS)
Remeha-Commercial part no. S100146
£42.71
1009 Part number S100148, Gasket Dia65 (10 Pc s.) GASKET DIA65 (10 PC S.)
Remeha-Commercial part no. S100148
£42.71
1010   DN65 GASKET
Remeha-Commercial part no. S100099
£47.13
1011   WALL BRACKET 2 BOILERS ACE
Remeha-Commercial part no. 7637077
£39.04
1011   WALL BRACKET 3 BOILERS ACE
Remeha-Commercial part no. 7637088
£54.35
1012   L FRAME VERTICAL ACE
Remeha-Commercial part no. 7612942
£204.39
1013   I FRAME VERTICAL ACE
Remeha-Commercial part no. 7612941
£135.25
1014   FRAME HORIZONTAL ACE
Remeha-Commercial part no. 7621566
£214.33
1015   HEIGHT ADJUSTMENT
Remeha-Commercial part no. S100151
£14.76
1016   WASHER 8.4MM +Y - PACK OF 25
Remeha-Commercial part no. S100088
£9.81
1017   SCREW M8X90 (20 PCS)
Remeha-Commercial part no. 7632917
£14.61
1017   SCREW M8X70 (20 PCS)
Remeha-Commercial part no. S100108
£28.39
1018   BOLT M16 X 50MM (20 PCS)
Remeha-Commercial part no. S100115
£55.93
1019 Part number S100112, Bolt M12 X 45Mm (20 Pcs.) BOLT M12 X 45MM (20 PCS.)
Remeha-Commercial part no. S100112
£35.49
1020   NUT M8 (20 PCS)
Remeha-Commercial part no. S100109
£13.39
1021   WASHER 17MM (20 PCS)
Remeha-Commercial part no. S100117
£10.50
1022 Part number S100114, Washer (Pk 10) WASHER (PK 10)
Remeha-Commercial part no. S100114
£16.19
1023   NUT M16 (20PCS)
Remeha-Commercial part no. S100116
£24.13
1024 Part number S100113, Nut (Pk 10) NUT (PK 10)
Remeha-Commercial part no. S100113
£16.19
1025   MOUNTING PLATE WALL
Remeha-Commercial part no. 7636634
£66.71
1026   MOUNTING PLATE CONTROLLER
Remeha-Commercial part no. 7641015
£29.81
