IDEAL
INSTINCT HEAT 120 - (Boiler Exploded View)
Appliance Code: HEAT-120

Appliance Diagram


Boiler Exploded View diagram for Ideal Instinct Heat 120Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 176367, BURNER FIXINGS KIT BURNER FIXINGS KIT
Ideal part no. 176367		 £15.90
100   HEAT EXCHANGER ASSEMBLY KIT 120
Ideal part no. 176224		 £2,080.63
101 Part number 176233, FLOW/RETURN PIPE BONDED SEAL KIT FLOW/RETURN PIPE BONDED SEAL KIT
Ideal part no. 176233		 £27.68
102   FLOW PIPE KIT 100/120
Ideal part no. 176237		 £126.99
103   RETURN PIPE KIT 100/120/150
Ideal part no. 176239		 £93.19
104 Part number 176390, CONDENSATE ASSEMBLY 100/120KW KIT CONDENSATE ASSEMBLY 100/120KW KIT
Ideal part no. 176390		 £99.23
201   GAS INLET PIPE 120KW KIT
Ideal part no. 176334		 £85.58
202   FLUE MANIFOLD BOTTOM 100/120/150 KIT
Ideal part no. 176337		 £93.07
203 Part number 176339, FLUE MANIFOLD TOP 100/120 KIT FLUE MANIFOLD TOP 100/120 KIT
Ideal part no. 176339		 £96.72
204   HELMHOLTZ ASSEMBLY 120KW KIT
Ideal part no. 176345		 £97.24
205   BURNER BOX ASSEMBLY 120KW KIT
Ideal part no. 176351		 £263.06
206 Part number 176355, BURNER 100KW/120KW KIT BURNER 100KW/120KW KIT
Ideal part no. 176355		 £377.31
207 Part number 176365, BURNER SEAL 100/120KW KIT BURNER SEAL 100/120KW KIT
Ideal part no. 176365		 £41.70
230 Part number 176274, FAN - 120 & 150KW FAN - 120 & 150KW
Ideal part no. 176274		 £1,022.30
231 Part number 176777, GAS VALVE 120KW KIT GAS VALVE 120KW KIT
Ideal part no. 176777		 £265.60
232 Part number 174381, VENTURI - IMAX XTRA 80-120 VENTURI - IMAX XTRA 80-120
Ideal part no. 174381		 £82.81
234 Part number 176411, ELBOW 45 DEG 100KW ELBOW 45 DEG 100KW
Ideal part no. 176411		 £14.27
301 Part number 176203, DRY FIRE THERMISTOR KIT (FLOW / RTN) DRY FIRE THERMISTOR KIT (FLOW / RTN)
Ideal part no. 176203
302 Part number 173510, IGNITION LEAD - HE SERIES IGNITION LEAD - HE SERIES
Ideal part no. 173510		 £16.44
302 Part number 176204, NOW USE 173510 LEAD IGNITION KIT NOW USE 173510 LEAD IGNITION KIT
Ideal part no. 176204
304 Part number 175593, IGNITOR UNIT (PRE ADP) IGNITOR UNIT (PRE ADP)
Ideal part no. 175593		 £35.17
306 Part number 176207, IGNITION ELECTRODE KIT IGNITION ELECTRODE KIT
Ideal part no. 176207		 £28.44
307 Part number 176208, BUTTONS & POTENTIOMETER KNOB BUTTONS & POTENTIOMETER KNOB
Ideal part no. 176208		 £35.35
308   FASCIA PLASTIC
Ideal part no. 176209		 £89.16
501   JACKET ASSEMBLY INSTINCT HEAT
Ideal part no. 178940		 £122.36
502   DOOR ASSEMBLY INSTINCT HEAT
Ideal part no. 178942		 £96.15
503 Part number 176376, HINGE ASSEMBLY EVOMAX KIT HINGE ASSEMBLY EVOMAX KIT
Ideal part no. 176376		 £11.53
504 Part number 176385, WALL MOUNTING BRACKET KIT WALL MOUNTING BRACKET KIT
Ideal part no. 176385		 £23.13
505   SIDE PANEL 100/120KW KIT
Ideal part no. 176387		 £105.73
