VAILLANT
MAG MINI 11-0/0 XZ 2004-2009 - (5 Gas Section)
Appliance Code: 11-0/0 XZ

Appliance Diagram


5 Gas Section diagram for Vaillant Mag Mini 11-0/0 XZ 2004-2009Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 117250, Gas section GAS SECTION
Vaillant part no. 117250		 £146.92
2 Part number 115325, Water deficcieny valve WATER DEFICCIENY VALVE
Vaillant part no. 115325		 £7.70
3 Part number 115329, Cover and packing ring COVER AND PACKING RING
Vaillant part no. 115329		 £6.71
4 Part number 115353, Magnet MAGNET
Vaillant part no. 115353		 £18.37
6 Part number 105829, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 105829		 £6.66
7 Part number 981125, Gasket (PK10) GASKET (PK10)
Vaillant part no. 981125		 £6.66
9 Part number 256618, Adapter ADAPTER
Vaillant part no. 256618		 £9.86
10 Part number 256619, Spring clamp (PK10) SPRING CLAMP (PK10)
Vaillant part no. 256619		 £11.24
