VAILLANT
HOME SYSTEM 12 -A - (07- Casing Parts)
Appliance Code: 41-044-94

Appliance Diagram


07- Casing Parts diagram for Vaillant Home System 12 -AClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   FRONT PANEL
Vaillant part no. 0020231156
£32.90
1A   PRICE ON APPLICATION
Vaillant part no. 0000

2 Part number 0020231137, Side panel SIDE PANEL
Vaillant part no. 0020231137
£53.23
3 Part number 0020073877, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020073877
£6.71
4 Part number 0020231111, Gasket, side panel GASKET, SIDE PANEL
Vaillant part no. 0020231111
£6.53
5 Part number 0020231112, Insulation, side panel INSULATION, SIDE PANEL
Vaillant part no. 0020231112
£8.39
6 Part number 0020231110, Gasket, front panel GASKET, FRONT PANEL
Vaillant part no. 0020231110
£6.53
7 Part number 0020231109, Gasket, front panel GASKET, FRONT PANEL
Vaillant part no. 0020231109
£6.53
7A   PRICE ON APPLICATION
Vaillant part no. 0000

8 Part number 0020231106, Support, wall SUPPORT, WALL
Vaillant part no. 0020231106
£6.64
9 Part number 0020231107, Support, expansion vessel SUPPORT, EXPANSION VESSEL
Vaillant part no. 0020231107
£6.53
10 Part number 0020073877, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020073877
£6.71
11 Part number 0020144596, Adapter, 60/100 ADAPTER, 60/100
Vaillant part no. 0020144596
£11.90
12 Part number 0020141347, Company plaque, Vaillant COMPANY PLAQUE, VAILLANT
Vaillant part no. 0020141347
£14.45
13 Part number 0020231113, Name badge, Home SYSTEM NAME BADGE, HOME SYSTEM
Vaillant part no. 0020231113
£6.53
13A   PRICE ON APPLICATION
Vaillant part no. 0000

14 Part number 0020195503, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020195503
£6.53
15 Part number 981227, Sealing ring EPDM (DN 80) SEALING RING EPDM (DN 80)
Vaillant part no. 981227
£6.69
16 Part number 0020195477, Gasket GASKET
Vaillant part no. 0020195477
£6.53
17 Part number 0020231138, Flue Adapter FLUE ADAPTER
Vaillant part no. 0020231138
£24.15
