BAXI
DUO TEC 2 28 GA RANGE - (Hydraulics)
Appliance Code: 47-075-55

Appliance Diagram


Hydraulics diagram for Baxi Duo Tec 2 28 GA RangeClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

401 Part number 720752301, GAS VALVE GAS VALVE
Baxi part no. 720752301
£94.54
402   INJECTOR DIAM 4.6MM
Baxi part no. 720775801
£13.32
403   TUBE GAS-24-28-33KW
Baxi part no. 720786801
£36.78
404 Part number 720787201, PRESSURE GAUGE INC WASHER PRESSURE GAUGE INC WASHER
Baxi part no. 720787201
£18.62
405 Part number 710109701, O RING 22 x 3 EPDM O RING 22 X 3 EPDM
Baxi part no. 710109701
£2.55
405 Part number 720787401, NOW USE 7724945 PUMP NOW USE 7724945 PUMP
Baxi part no. 720787401

405   PUMP KIT - UPM3-6M LUNA 4
Baxi part no. 7724945
£148.77
406 Part number 720777601, AIR VENT VALVE AIR VENT VALVE
Baxi part no. 720777601
£31.80
407 Part number 720787801, SAFETY VALVE 3 BAR SAFETY VALVE 3 BAR
Baxi part no. 720787801
£22.54
408 Part number 720788001, DRAIN TAP DRAIN TAP
Baxi part no. 720788001
£18.62
409 Part number 247429, O RING 22mm X 3mm O RING 22MM X 3MM
Baxi part no. 247429
£3.16
409   PUMP CONNECTION
Baxi part no. 7223320
£7.62
410   HALL SENSOR
Baxi part no. 720788201
£29.30
411   BRACKET HYDROBLOCK
Baxi part no. 720788401
£19.75
412 Part number 7216534, MOTOR BLACK/WHITE INC CLIP MOTOR BLACK/WHITE INC CLIP
Baxi part no. 7216534
£46.67
413 Part number 248736, CLIP-RETAINING CLIP-RETAINING
Baxi part no. 248736
£4.57
414 Part number 720789001, PRESSURE SENSOR VALVE PRESSURE SENSOR VALVE
Baxi part no. 720789001
£18.62
415 Part number 720789201, NTC SENSOR NTC SENSOR
Baxi part no. 720789201
£18.62
417   BRSS FLOW ASSY WTHOUT BY PASS
Baxi part no. 720789401
£91.94
418 Part number 720789601, BRASS RETURN ASSY 12L BRASS RETURN ASSY 12L
Baxi part no. 720789601
£37.02
419   PIPE EXPANSION VESSEL
Baxi part no. 720789801
£26.53
420 Part number 720884901, SEAL PLATE H/EX SEAL PLATE H/EX
Baxi part no. 720884901
£15.92
421 Part number 720790001, PT TO PT HT EX 14PS 24-28-33KW PT TO PT HT EX 14PS 24-28-33KW
Baxi part no. 720790001
£91.86
