BAXI
COMBI 133 HE PLUS - (Gas Valve)
Appliance Code: 47-075-14

Appliance Diagram


Gas Valve diagram for Baxi Combi 133 HE PlusClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

401 Part number 247222, KIT-GAS VALVE KIT-GAS VALVE
Baxi part no. 247222		 £197.86
402 Part number 240839, O-RING (GREEN) O-RING (GREEN)
Baxi part no. 240839		 £4.52
403   OBSOLETE SCREW SET M4 X 8MM POZI HEX
Baxi part no. 245747
404 Part number 241739, NOW USE 7683446 BOX MANIFOLD VALVE NOW USE 7683446 BOX MANIFOLD VALVE
Baxi part no. 241739
404 Part number 242228, GROMMET GROMMET
Baxi part no. 242228		 £4.45
404   BOX MANIFOLD VALVE
Baxi part no. 7683446		 £17.49
405 Part number 242229, GASKET GASKET
Baxi part no. 242229		 £3.16
406 Part number 242226, SCR SET M5x15mm CAP HD SOCKET SCR SET M5X15MM CAP HD SOCKET
Baxi part no. 242226		 £3.26
407 Part number 242475, 5mm PIPE - SPARES 5MM PIPE - SPARES
Baxi part no. 242475		 £19.61
408   OBSOLETE BRACKET SECURING FRAME
Baxi part no. 243077
409 Part number 633404, SCREW M6X20 SCREW M6X20
Baxi part no. 633404		 £3.06
410 Part number 243133, ADAPTER RETURN ASSEMBLY ADAPTER RETURN ASSEMBLY
Baxi part no. 243133		 £33.69
411 Part number 633404, SCREW M6X20 SCREW M6X20
Baxi part no. 633404		 £3.06
412 Part number 242459, FLOW SWITCH FLOW SWITCH
Baxi part no. 242459		 £49.78
413 Part number 242493, HEAT EX. MANIFOLD HEAT EX. MANIFOLD
Baxi part no. 242493		 £34.55
414 Part number 240676, NOW USE 7671969 SEAL MANIFOLD 2.62mm DIA NOW USE 7671969 SEAL MANIFOLD 2.62MM DIA
Baxi part no. 240676
414 Part number 7671969, SEAL MANIFOLD 2.62mm D-240676 SEAL MANIFOLD 2.62MM D-240676
Baxi part no. 7671969		 £7.63
415 Part number 240799, PIPE CLIP PIPE CLIP
Baxi part no. 240799		 £5.88
416 Part number 5107838, MANUAL AIR VENT 3/8" MANUAL AIR VENT 3/8"
Baxi part no. 5107838		 £5.74
417 Part number 242819, NUT COMPRESSION 28MM NUT COMPRESSION 28MM
Baxi part no. 242819		 £4.73
418 Part number 102218, OLIVE-28MM-CONEX OLIVE-28MM-CONEX
Baxi part no. 102218		 £5.38
419 Part number 240396, VENT AUTO VENT AUTO
Baxi part no. 240396		 £25.05
420 Part number 240812, O-RING 20.64 x 2.62mm O-RING 20.64 X 2.62MM
Baxi part no. 240812		 £3.26
421 Part number 243347, RETURN PIPE RETURN PIPE
Baxi part no. 243347
421 Part number 5121359, PIPE RETURN BOILER (SPARES) PIPE RETURN BOILER (SPARES)
Baxi part no. 5121359
422 Part number 7671970, THERMOSTAT BOILER-240670 THERMOSTAT BOILER-240670
Baxi part no. 7671970		 £13.59
422 Part number 240670, NOW USE 7671970 THERMOSTAT BOILER NOW USE 7671970 THERMOSTAT BOILER
Baxi part no. 240670
423 Part number 240799, PIPE CLIP PIPE CLIP
Baxi part no. 240799		 £5.88
423   OBSOLETE PIPE FLOW BOILER
Baxi part no. 243346
424 Part number 243341, DIVERTER VALVE PLASTIC DIVERTER VALVE PLASTIC
Baxi part no. 243341		 £125.67
425 Part number 243725, NOW USE 5113174 SCREW M4 x 25MM PLASTITE NOW USE 5113174 SCREW M4 X 25MM PLASTITE
Baxi part no. 243725
425 Part number 5113174, SCREW TAPTITE M4 X 35 SCREW TAPTITE M4 X 35
Baxi part no. 5113174		 £2.93
426 Part number 247310, VALVE BODY VALVE BODY
Baxi part no. 247310		 £92.79
427 Part number 245325, OBSOLETE PIPE CONNECTION FLOW OBSOLETE PIPE CONNECTION FLOW
Baxi part no. 245325
428 Part number 240395, NOW USE 5113411 PUMP NOW USE 5113411 PUMP
Baxi part no. 240395
428 Part number 5113411, PUMP HEAD REPLACEMENT INC SEAL PUMP HEAD REPLACEMENT INC SEAL
Baxi part no. 5113411
429 Part number 244663, SCREW M6 x 45MM SET PAN POZI SCREW M6 X 45MM SET PAN POZI
Baxi part no. 244663		 £2.33
430 Part number 062441, NUT-FULL HEX-6MM ZINC PLTD NUT-FULL HEX-6MM ZINC PLTD
Baxi part no. 062441		 £3.01
431 Part number 242369, MANIFOLD PUMP VALVE MANIFOLD PUMP VALVE
Baxi part no. 242369		 £66.86
432   OBSOLETE BRACKET SUPPORT PUMP
Baxi part no. 244027
433 Part number 062531, SCR-TF-M5x8MM-PAN POZI ZN PD SCR-TF-M5X8MM-PAN POZI ZN PD
Baxi part no. 062531		 £3.12
434 Part number 240390, NOW USE 5000721 SAFETY VALVE NOW USE 5000721 SAFETY VALVE
Baxi part no. 240390
434 Part number 5000721, VALVE PRESSURE RELIEF. VALVE PRESSURE RELIEF.
Baxi part no. 5000721		 £22.38
435   OBSOLETE PIPE VENT AUTO
Baxi part no. 247161
436   OBSOLETE PIPE FEED GAS
Baxi part no. 246556
437 Part number 240839, O-RING (GREEN) O-RING (GREEN)
Baxi part no. 240839		 £4.52
438 Part number 241806, PLUG DRAIN PLUG DRAIN
Baxi part no. 241806		 £7.09
