BAXI
COMBI 133 HE PLUS - (Outer Case)
Appliance Code: 47-075-14

Appliance Diagram


Outer Case diagram for Baxi Combi 133 HE PlusClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

101   ASSEMBLY OUTER CASE COMBI HE
Baxi part no. 5110726
£92.54
102 Part number 5110704, HINGE ASSEMBLY HINGE ASSEMBLY
Baxi part no. 5110704
£5.71
103   SCREW NO 6 X 1/4 PLASTITE
Baxi part no. 240982

104   PANEL SIDE O/CASE RH (PAINTED)
Baxi part no. 5110729
£7.79
105   PANEL SIDE O/CASE LH (PAINTED)
Baxi part no. 5110730
£7.55
106 Part number 225310BAX, SCR-ST-No6x1/4in FLHD POZI AB SCR-ST-NO6X1/4IN FLHD POZI AB
Baxi part no. 225310BAX
£3.12
107   PANEL FRONT COMBI/SYS(PAINTED)
Baxi part no. 240424
£13.92
108   DOOR PANEL ASSY COMBI (PAINT)
Baxi part no. 5110731
£15.63
109   OBSOLETE PANEL TOP O/CASE (PAINTED)
Baxi part no. 5109310
