VOKERA
OPTION 24 - (Combustion Components)
Appliance Code: 47-094-32

Appliance Diagram


Combustion Components diagram for Vokera Option 24Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   AIR CHAMBER
Vokera part no. 10020894

2 Part number 1005272, NOW USE 01005272 Pressure Switch Replaced 0963 / 7070 / 8195 / 9232 NOW USE 01005272 PRESSURE SWITCH REPLACED 0963 / 7070 / 8195 / 9232
Vokera part no. 1005272

2 Part number 01005272, Air Pressure Switch Rep 7070/8195/9232 AIR PRESSURE SWITCH REP 7070/8195/9232
Vokera part no. 01005272
£58.89
3   WASHER
Vokera part no. 8975
£2.82
4 Part number 8084, Air Box Hole Cap AIR BOX HOLE CAP
Vokera part no. 8084
£4.08
5 Part number 2233, Blanking Plate BLANKING PLATE
Vokera part no. 2233

6 Part number 10020624, TEST PLATE TEST PLATE
Vokera part no. 10020624
£1.62
7 Part number 10020625, Square Plastic Nut underneath Test Plate SQUARE PLASTIC NUT UNDERNEATH TEST PLATE
Vokera part no. 10020625
£2.61
10 Part number 10020626, Stop clip (individual) STOP CLIP (INDIVIDUAL)
Vokera part no. 10020626
£0.69
11   FUMES TESTING CONNECTION PIPE
Vokera part no. 10020627
£4.37
12 Part number 1457, Silicone tube (1 Metre) SILICONE TUBE (1 METRE)
Vokera part no. 1457
£2.12
13 Part number 10020793, Fan Assembly (Includes Venturi) FAN ASSEMBLY (INCLUDES VENTURI)
Vokera part no. 10020793
£96.19
14 Part number 2230, Rear Insulation Panel for Combustion Chamber REAR INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 2230
£14.54
15 Part number 2231, Side Insulation Panel for Combustion Chamber SIDE INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 2231
£14.33
16 Part number 2232, Front Insulation Panel for Combustion Chamber FRONT INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 2232
£15.98
17   NOW USE 10024670 COMBUSTION COVER
Vokera part no. 2228

17   COMBUSTION CHAMBER FRONT COVER
Vokera part no. 10024670
£17.49
20   GLASS
Vokera part no. 10021558
£13.51
23 Part number 5079, Screw SCREW
Vokera part no. 5079
£0.35
24   SCREW
Vokera part no. 5077
£0.15
25   SCREW
Vokera part no. 5080
£0.21
26   SCREW
Vokera part no. 5212

27 Part number 2586, 44mm Restrictor Ring 44MM RESTRICTOR RING
Vokera part no. 2586
£1.35
28 Part number 2237, Connection CONNECTION
Vokera part no. 2237
£11.24
