POTTERTON
TATTLER RS 46 AEROMATIC - (Outer Case)
Appliance Code: 41-601-09

Appliance Diagram


Outer Case diagram for Potterton Tattler RS 46 AeromaticClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE COMB.CHMBR ASSY. RS.50
Potterton part no. 206593

7 Part number 65063701, ROPE CERAMIC CABLE12MM X 1M L ROPE CERAMIC CABLE12MM X 1M L
Potterton part no. 65063701

10   OBSOLETE COMB CHAMB INSUL REAR
Potterton part no. 202091

11   OBSOLETE COMB CHAMB INSUL FRONT
Potterton part no. 202092

12   OBSOLETE C/CHBR INSUL LH FL/KFISH
Potterton part no. 202093

13 Part number 202094, OBSOLETE C/CHBR INSUL RH FL/KFISH OBSOLETE C/CHBR INSUL RH FL/KFISH
Potterton part no. 202094

16   OBSOLETE HEAT EXCH ASSY K/F RS50
Potterton part no. 204017

18   OBSOLETE COVER PLATE LH
Potterton part no. 200459

19   OBSOLETE COVER PLATE RH
Potterton part no. 200487

20 Part number 200337, COVER PLATE GASKET COVER PLATE GASKET
Potterton part no. 200337

24   OBSOLETE THERMOSTAT POCKET ASSY
Potterton part no. 206750

28   OBSOLETE CONT COVER ASSY SPARES
Potterton part no. 205264

33   OBSOLETE M8 X 18MM STUD
Potterton part no. 635225
£2.89
34   OBSOLETE FLUE HOOD ASS.K/F.RS50
Potterton part no. 202047

40   OBSOLETE FLUE HOOD CLAMPING BRKT
Potterton part no. 202682

41   OBSOLETE FLUE HOOD CLAMPING ROD
Potterton part no. 202702

44   OBSOLETE CNTRL MODULE ASSY K/F
Potterton part no. 204091

49 Part number 404456, THERMOSTAT RANCO CL.6 THERMOSTAT RANCO CL.6
Potterton part no. 404456

50 Part number 200277, THERMOSTAT KNOB THERMOSTAT KNOB
Potterton part no. 200277

51   OBSOLETE SKT 3 POLE BULGIN SA 2404
Potterton part no. 640253

61   OBSOLETE CONTROL MOD HSG ASYCF40ETC
Potterton part no. 203087

71   OBSOLETE AEROMATIC BRNR INJ 3.4MM
Potterton part no. 410488

72   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988

75   OBSOLETE CONTROL GAS V4400C S VCE KIT
Potterton part no. 906223

75   OBSOLETE POWER UNIT
Potterton part no. 904752

75   OBSOLETE REGULATOR PRESS V5306A/E HW
Potterton part no. 904751

75   OBSOLETE OPERATOR SOLENOID TRADELINE
Potterton part no. 904750

75   OBSOLETE GAS VALVE BOXED
Potterton part no. 402809

76   OBSOLETE CONTROL VALVE LEAD ASSY
Potterton part no. 204244

78 Part number 301461, MANIFOLD GASKET MANIFOLD GASKET
Potterton part no. 301461

82   OBSOLETE PIEZO GENR VERNITRON
Potterton part no. 407627

93   OBSOLETE PILOT SHIELD - FURIGAS
Potterton part no. 202175

94   OBSOLETE PILOT BRNR ASSY F/G RS 13
Potterton part no. 402489

96 Part number 102041, INJECTOR PILOT.NG.BCR-18 INJECTOR PILOT.NG.BCR-18
Potterton part no. 102041

96 Part number 410209, PILOT INJ HONEYWELL BCR 18 PILOT INJ HONEYWELL BCR 18
Potterton part no. 410209

97 Part number 402492, SHR OFF UNION 6MM LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492
£5.88
99 Part number 407625, OBSOLETE ELECTRODE ASSEMBLY OBSOLETE ELECTRODE ASSEMBLY
Potterton part no. 407625

101   OBSOLETE BURNER BAR FURIGAS
Potterton part no. 414533

105   OBSOLETE MINI COUPLING BODY - 1/8IN BSP PARALLEL
Potterton part no. 401625

106   OLIVE 6MM BORE
Potterton part no. 401624
£2.95
107   COMPRESSION NUT 1/8" BSP
Potterton part no. 401582
£5.12
108 Part number 700723, ALUMINIUM TUBE KIT 6MM OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723

110   OBSOLETE C/CHBR SEAL PL/A RS40&50S
Potterton part no. 202725

112   OBSOLETE COVER PLATE INSULATION
Potterton part no. 202095

113   OBSOLETE GASKET SIGHT GLASS PR K/F F
Potterton part no. 907166

114 Part number 413501, OBSOLETE SIGHT GLASS OBSOLETE SIGHT GLASS
Potterton part no. 413501

119   OBSOLETE SIGHT GLASS RETAINER
Potterton part no. 202100

120 Part number 40225701, NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY
Potterton part no. 40225701

120 Part number Q309A2788, THERMOCOUPLE THERMOCOUPLE
Potterton part no. Q309A2788
£6.97
122 Part number 407626, ELECTRODE LEAD ELECTRODE LEAD
Potterton part no. 407626

146   OBSOLETE AIR DUCT ASSEMBLY RS13 50 6
Potterton part no. 907404

154   OBSOLETE TERMINAL PACK K/F2.
Potterton part no. 203660

158   OBSOLETE TERMINAL GRILLE
Potterton part no. 202022

159   OBSOLETE TERMINAL FRONT PLATE
Potterton part no. 202031
