POTTERTON
SLIMLINE ILLUSION 2 ASD 369 FACIA - (Assembly 5)
Appliance Code: 32-590-26

Appliance Diagram


Assembly 5 diagram for Potterton Slimline Illusion 2 ASD 369 FaciaClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

100   OBSOLETE FACIA ASSEMBLY COMPLETE
Potterton part no. 367/1190

100   OBSOLETE FIRESTAR FACIA BLACK
Potterton part no. 365/1190

101   OBSOLETE FACIA ASSY
Potterton part no. 366/1180

101   OBSOLETE FACIA ASSY
Potterton part no. 360/1180

101   OBSOLETE FACIA ASSY
Potterton part no. 365/1180

101   OBSOLETE 367/1180 FACIA ASSY
Potterton part no. 8005101

101   OBSOLETE FACIA ASSEMBLY
Potterton part no. 368/1180

102   OBSOLETE FACIA PAINTED
Potterton part no. 67/360/40

102   OBSOLETE FACIA S/W ASSEMBLY
Potterton part no. 362A/7020

102   OBSOLETE FACIA W/ASSY PAINTED
Potterton part no. 67/365/9448

103   OBSOLETE CANOPY ASSEMBLY
Potterton part no. 362A/1656

103   OBSOLETE CANOPY PAINTED
Potterton part no. 67/360/2555

104   OBSOLETE LOCATING PIN
Potterton part no. 1200799

105   OBSOLETE CANOPY H/SHIELD PAINTED
Potterton part no. 60/362A/1100

105 Part number S/54/36, NOW USE 062441 M6 FULL HEXAGON NUT. NOW USE 062441 M6 FULL HEXAGON NUT.
Potterton part no. S/54/36

105 Part number 062441, NUT-FULL HEX-6MM ZINC PLTD NUT-FULL HEX-6MM ZINC PLTD
Potterton part no. 062441
£3.01
106   OBSOLETE CANOPY HEATSHIELD PAINTED
Potterton part no. 60/360/1037

106   OBSOLETE SCREW NO 6 X 13 POZI PAN *
Potterton part no. S/108/33

107   OBSOLETE HEAT SHIELD - TOP
Potterton part no. 1201878

107   OBSOLETE FENDER ASSEMBLY
Potterton part no. 368/1504

107   OBSOLETE TOP TRIM
Potterton part no. 367/2130

107   OBSOLETE TOP TRIM
Potterton part no. 365/2130

108   OBSOLETE SIDE TRIM R/H
Potterton part no. 365/2200

108   OBSOLETE SIDE TRIM R/H
Potterton part no. 367/2200

108   OBSOLETE FENDER
Potterton part no. 362/2102

108   OBSOLETE SCREW M5X12 PN HD PZ STL BLACK
Potterton part no. S/256/30

109   OBSOLETE FINIAL
Potterton part no. 1207617

109   OBSOLETE TOP TRIM
Potterton part no. 360/2130

109   OBSOLETE SIDE TRIM L/H
Potterton part no. 365/2201

110   OBSOLETE FENDER ASSY
Potterton part no. 365/1504

110   OBSOLETE SIDE TRIM RH
Potterton part no. 360/2200

110   OBSOLETE M5 X 10 HEX HD POZI BLK
Potterton part no. S/265/19

111   OBSOLETE SIDE TRIM LH
Potterton part no. 360/2201

111   OBSOLETE FENDER 370 INSET LFE
Potterton part no. 365/2101

111   OBSOLETE LEG PAINTED
Potterton part no. 67/361/69

111   OBSOLETE FENDER
Potterton part no. 367/2102

112   OBSOLETE CORNER FINIAL
Potterton part no. 950/1047

112   OBSOLETE PLINTH ASSEMBLY
Potterton part no. 365/1788

112   OBSOLETE FRONT ASSY
Potterton part no. 360/1023

113   OBSOLETE PUSH-IN PANEL FASTENER BLACK
Potterton part no. 2018911

114   OBSOLETE SCREW M5 X 8MM HEX HEAD POZI
Potterton part no. 8005505

114   OBSOLETE PLINTH MOUNTING BRACKET
Potterton part no. 365/2920

115   OBSOLETE SCREW M6X30 PN HD PZ STL ZP
Potterton part no. S/256/40

115   OBSOLETE SCREW M3X8 MCPAN POZ SZ
Potterton part no. 670002

116   OBSOLETE DOG POINT SCREW#
Potterton part no. 960/320

116   OBSOLETE PLINTH ASSEMBLY
Potterton part no. 369/1788

117   OBSOLETE 365/1051 CONTROL KNOB ASSEMBLY
Potterton part no. 2011052

117   OBSOLETE 365HP/1051 CONTROL KNOB ASSEMBLY
Potterton part no. 2011152

118   OBSOLETE TAPPING SCREW ISO NO8AB X 13 RECESSED FLANGE H
Potterton part no. 2017646

118   OBSOLETE MOUNTING BRACKET
Potterton part no. 370/2655

119   OBSOLETE BLANKING PANEL PAINTED
Potterton part no. 70/369/1184

119   OBSOLETE S/132/32 SEALING STRIP
Potterton part no. 2011323

120 Part number 670037, NOW USE 062699 SCREWNO6X9.5 ABPAN POZ SZ NOW USE 062699 SCREWNO6X9.5 ABPAN POZ SZ
Potterton part no. 670037

120 Part number 062699, SCR-ST-No6x3/8 PAN HD PZ ZP SCR-ST-NO6X3/8 PAN HD PZ ZP
Potterton part no. 062699
£3.12
120   OBSOLETE 367/1051 CONTROL KNOB ASSEMBLY
Potterton part no. 2011051

120   OBSOLETE 367HP/1051 CONTROL KNOB ASSEMBLY
Potterton part no. 2011151

200   OBSOLETE CASE ASSEMBLY PAINTED
Potterton part no. 60/370/1049

201   OBSOLETE SPIGOT RESTRICTOR CTR
Potterton part no. 370/2504

202   OBSOLETE SPIGOT RESTRICTOR SIDE
Potterton part no. 370/2505

204   OBSOLETE FLUE SPIGOT
Potterton part no. 370/2099

205 Part number S/108/12, OBSOLETE SCREW NO.8X3/8 PN HD POZI OBSOLETE SCREW NO.8X3/8 PN HD POZI
Potterton part no. S/108/12

206   OBSOLETE COVER PLATE
Potterton part no. 370/2424

207   OBSOLETE SCREW M5 X 6MM HEX HEAD POZI
Potterton part no. 8005130

208   OBSOLETE FIREBOX CANOPY PAINTED
Potterton part no. 60/370/2096

210   OBSOLETE FIREBOX BOTTOM
Potterton part no. 370/20018

300   OBSOLETE CONTROLS ASSEMBLY
Potterton part no. 370/1966

301   OBSOLETE GAS TAP ASSEMBLY - COPRECI CPMM21400/131
Potterton part no. 2011044

302   OBSOLETE BURNER ASSEMBLY - PILOT - SIT OP9405
Potterton part no. 2011433

303   OBSOLETE PILOT PIPE
Potterton part no. 370/901

304   OBSOLETE INLET PIPE
Potterton part no. 370/900

305   OBSOLETE UNION ELBOW#
Potterton part no. 814/943

306   OBSOLETE BURNER PIPE
Potterton part no. 370/902

307   OBSOLETE INJECTOR CARRIER ASSEMBLY
Potterton part no. 370/740

308   OBSOLETE INJECTOR CARRIER
Potterton part no. 370/7287

309   OBSOLETE INJECTOR - MAIN BURNER - BRAY 28/415
Potterton part no. 2017705

310   OBSOLETE SCREW - PRESSURE TEST
Potterton part no. 2010332

311   OBSOLETE TAP SHIELD
Potterton part no. 370/104

312   OBSOLETE BURNER ASSEMBLY
Potterton part no. 370/1276

313   OBSOLETE BURNER SUPPORT
Potterton part no. 370/19

314   OBSOLETE HEAT SHIELD
Potterton part no. 370/2412

315   OBSOLETE NUT UNION
Potterton part no. 2101714

316   OBSOLETE 370/9393 ELECTRODE WIRE
Potterton part no. 2019393

317   OBSOLETE IGNITION BRACKET ASSEMBLY C/W
Potterton part no. 2010701

318   OBSOLETE SPARK GENERATOR
Potterton part no. 370/9388

319 Part number 670019, SCREW M4 X 6MM HEX.HD.POZI SCREW M4 X 6MM HEX.HD.POZI
Potterton part no. 670019
£3.16
400 Part number 370/982, OBSOLETE COAL PACK OBSOLETE COAL PACK
Potterton part no. 370/982

401 Part number 370/2040, OBSOLETE COAL NO.1 OBSOLETE COAL NO.1
Potterton part no. 370/2040

402   OBSOLETE MATRIX
Potterton part no. 370/2030

403   OBSOLETE FRONT COAL
Potterton part no. 370/984

404   OBSOLETE DYE - COAL TOUCH-UP
Potterton part no. 1205791
