POTTERTON
PERFORMA SYSTEM 12E - (wall jig)
Appliance Code: 41-590-88

Appliance Diagram


wall jig diagram for Potterton Performa System 12eClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

600   CONNECTIONS-VACUUM PACK-SYSTEM
Potterton part no. 248494

601 Part number 248100, WALL JIG ASSEMBLY WALL JIG ASSEMBLY
Potterton part no. 248100
£28.54
602   CONNECTION TAIL - 22MM
Potterton part no. 248229
£9.51
604 Part number 247758, LOCK NUT - G3/4 LOCK NUT - G3/4
Potterton part no. 247758
£5.88
606 Part number 248231, PIPE-DISCHARGE-SAFETY VALVE PIPE-DISCHARGE-SAFETY VALVE
Potterton part no. 248231
£11.95
607 Part number 247744, SEALING WASHER G. 1/2 SEALING WASHER G. 1/2
Potterton part no. 247744
£3.16
608 Part number 247745, SEALING WASHER G. 3/4 SEALING WASHER G. 3/4
Potterton part no. 247745
£3.16
609 Part number 248224, TAP - ISOLATION - FLOW TAP - ISOLATION - FLOW
Potterton part no. 248224
£33.91
610 Part number 248225, TAP - ISOLATION - RETURN TAP - ISOLATION - RETURN
Potterton part no. 248225
£43.27
612 Part number 247764, RUBBER SEAL - GAS TAP RUBBER SEAL - GAS TAP
Potterton part no. 247764
£3.26
613 Part number 247485, TAP TAP
Potterton part no. 247485
£19.05
614 Part number 248230, ELBOW - GAS INLET ELBOW - GAS INLET
Potterton part no. 248230
£9.51
