POTTERTON
PERFORMA 30 HE - (Control Assembly)
Appliance Code: 47-393-13

Appliance Diagram


Control Assembly diagram for Potterton Performa 30 HEClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

501 Part number 248088, COVER - ELECTRICAL BOX COVER - ELECTRICAL BOX
Potterton part no. 248088
£9.83
502 Part number 248072, PANEL - ACCESS PANEL - ACCESS
Potterton part no. 248072
£5.88
505 Part number 5112380, PRINTED CIRCUIT BOARD PRINTED CIRCUIT BOARD
Potterton part no. 5112380
£186.11
506 Part number 247481, FUSE HOLDER FUSE HOLDER
Potterton part no. 247481
£4.57
507 Part number 248089, NOW USE 7727139 FUSE (2A 250V) NOW USE 7727139 FUSE (2A 250V)
Potterton part no. 248089

507 Part number 720853801, NOW USE 7727139 FUSE 2A 250V IN FUSE HOLDER NOW USE 7727139 FUSE 2A 250V IN FUSE HOLDER
Potterton part no. 720853801

507 Part number 7727139, FUSE 2A 250V IN FUSEHOLDER FUSE 2A 250V IN FUSEHOLDER
Baxi part no. 7727139
£29.61
507   KIT TERMINAL BLOCK AND FUSES
Potterton part no. 7727139
£29.61
508 Part number 247480, TERMINAL BLOCK TERMINAL BLOCK
Potterton part no. 247480
£7.15
509 Part number 248095, SWITCH - SELECTOR SWITCH - SELECTOR
Potterton part no. 248095
£11.95
510   LENS - NEON
Potterton part no. 248196

511 Part number 248096, DRIVE PIN - POTENTIOMETER DRIVE PIN - POTENTIOMETER
Potterton part no. 248096
£3.26
512 Part number 248091, RETAINER - PRESSURE GAUGE RETAINER - PRESSURE GAUGE
Potterton part no. 248091
£5.88
513 Part number 248090, GAUGE PRESSURE C/W RETAINER GAUGE PRESSURE C/W RETAINER
Potterton part no. 248090
£23.80
515 Part number 248076, COVER - INTEGRAL TIMER COVER - INTEGRAL TIMER
Potterton part no. 248076
£5.88
516 Part number 248194, PIN - HINGED FACIA PANEL PIN - HINGED FACIA PANEL
Potterton part no. 248194
£2.29
517   PANEL - FACIA
Potterton part no. 5112664
£10.51
518 Part number 5107344, KNOB SELECTOR KNOB SELECTOR
Potterton part no. 5107344
£4.57
519 Part number 5112692, COVER - CONTROL FACIA COVER - CONTROL FACIA
Potterton part no. 5112692
£14.28
521 Part number 5107345, KNOB CONTROL KNOB CONTROL
Potterton part no. 5107345
£3.28
