POTTERTON
NETAHEAT MK 2E 16/22 (FIELD TRIAL) - (Identification)
Appliance Code: 41-601-63

Appliance Diagram


Identification diagram for Potterton Netaheat MK 2E 16/22 (Field Trial)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE W WAY MONO BLOC KIT N H
Potterton part no. 907223

3   OBSOLETE COVER PLATE LH
Potterton part no. 200459

4   OBSOLETE COVER PLATE RH
Potterton part no. 200487

5 Part number 200337, COVER PLATE GASKET COVER PLATE GASKET
Potterton part no. 200337

9   OBSOLETE THERMOSTAT POCKET ASSY
Potterton part no. 206750

16   OBSOLETE SUPPORT ANGLE
Potterton part no. 205195

17   OBSOLETE BEARING PLATE
Potterton part no. 205197

18   OBSOLETE FLEXIBLE STRIP
Potterton part no. 205198

19   OBSOLETE SHIM STRIP
Potterton part no. 205196

20   OBSOLETE REAR PANEL INSULATION
Potterton part no. 205694

24 Part number 200350, OBSOLETE SILICONE CORD SEAL OBSOLETE SILICONE CORD SEAL
Potterton part no. 200350

31   OBSOLETE M8 X 18MM STUD
Potterton part no. 635225
£2.89
35   OBSOLETE C/CHBR PNL S/A RH N/HEAT
Potterton part no. 205277

37   OBSOLETE DEFLECTOR SPACER
Potterton part no. 200375

41   OBSOLETE C/CHBR PNL S/A LH N/HEAT
Potterton part no. 205278

42   OBSOLETE DEFLECTOR CHANNEL RH
Potterton part no. 200756

45 Part number 65063601, ROPE CERAMIC TWIST 5MM 1 MTR ROPE CERAMIC TWIST 5MM 1 MTR
Potterton part no. 65063601

47 Part number 409568, FAN ASSY FFB 1706 008 FAN ASSY FFB 1706 008
Potterton part no. 409568
£239.28
49   OBSOLETE FLUE HOOD ASSY
Potterton part no. 200304

51 Part number 65063701, ROPE CERAMIC CABLE12MM X 1M L ROPE CERAMIC CABLE12MM X 1M L
Potterton part no. 65063701

56 Part number 200396, SIDE PANEL INSULATION SIDE PANEL INSULATION
Potterton part no. 200396

58   OBSOLETE C/CHBR FRONT PANEL ASSY
Potterton part no. 200368

60   OBSOLETE FRT PANEL INSULATION
Potterton part no. 200387

62   OBSOLETE SWITCH FAN PRESSURE
Potterton part no. 64220401

66 Part number 200468, HOSE COUPLING HOSE COUPLING
Potterton part no. 200468

67   OBSOLETE DUCT RETAINING SPACER
Potterton part no. 200329

95   OBSOLETE TERML BLK 12 WAY 10 AMP
Potterton part no. 640303

97   OBSOLETE CONTROL IG N S CE KIT N HT E/
Potterton part no. 40766101

109   OBSOLETE CONT COVER ASSY SPARES
Potterton part no. 205264

116 Part number 200277, THERMOSTAT KNOB THERMOSTAT KNOB
Potterton part no. 200277

117   OBSOLETE CONT PNL BKT/A RH
Potterton part no. 205155

120   OBSOLETE CONT PNL BKT/A LH
Potterton part no. 205156

126   OBSOLETE FLUE OUTLET ASSEMBLY - SERVICE KIT
Potterton part no. 210087

131   OBSOLETE ROPE CERAMIC BRAID 20MM 1 MT
Potterton part no. 65063101

132   OBSOLETE TERMINAL ASSEMBLY
Potterton part no. 200324

137   OBSOLETE TERM BAFFLE W/ASY 16/22
Potterton part no. 200326

138   OBSOLETE TERMINAL - OUTER HALF
Potterton part no. 200325

139   OBSOLETE GASKET TERMINAL DUCT NETAHEAT
Potterton part no. 200376

141   OBSOLETE TERM.INLET DUCT ASSY
Potterton part no. 205827

146   OBSOLETE CONTROL GAS K25 KIT NHT
Potterton part no. 905371

149   OBSOLETE NIPPLE TAPER 3/8BSP MS
Potterton part no. 625403

150   OBSOLETE ELBO REDUC F/F 1/2X3/8BSP
Potterton part no. 626914

151   OBSOLETE ELBOW - MALE/FEMALE 1/8IN BSP
Potterton part no. 627102

152   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988

153   OBSOLETE REDUC BUSH 3/8X1/8BSP MS
Potterton part no. 629130

156   OBSOLETE BURNER MAIN CW INJ NHT/2F 16/
Potterton part no. 906161

157   OBSOLETE ELBOW - FEMALE 3/8IN BSP
Potterton part no. 626933

159   OBSOLETE STRAIGHT UNION 3/8INCH BSP
Potterton part no. 625824

160   OBSOLETE FURIGAS INJECTOR 4.2MM
Potterton part no. 410903

161   OBSOLETE INJECTOR WASHER
Potterton part no. 375993

163   TUBE ALUMINIUM 6MM X 4FT
Potterton part no. 5102870
£6.71
163   NOW USE 5102870 TUBE ALUM 6MM OD
Potterton part no. 700705

164   OBSOLETE PILOT SHIELD
Potterton part no. 200769

165   OBSOLETE PILOT ASSY W/ROG N HT
Potterton part no. 402842

165 Part number 402492, SHR OFF UNION 6MM LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492
£5.88
165   OBSOLETE INJECTOR PILOT NG 2033 NHT 2
Potterton part no. 905476

174   OBSOLETE BURNER GASKET
Potterton part no. 200725

176   OBSOLETE CASING SPARES REPLACEMENT N/H
Potterton part no. 905348

178   OBSOLETE CASE END PLATE INSUL
Potterton part no. 200265

181   OBSOLETE SIGHT GLASS
Potterton part no. 205142

182   OBSOLETE SIGHT GLASS GASKET
Potterton part no. 205143

183   OBSOLETE ANTI-VIBRATION PANEL
Potterton part no. 205600

200   OBSOLETE SEALING RING
Potterton part no. 20032701

205   OBSOLETE INFILL SIDE PANEL PACK - ONE PAIR
Potterton part no. 905813

206   OBSOLETE OPTION FLUE TERM L GUARD 16/
Potterton part no. 200493

210   OBSOLETE WALL LINER EXTENSION KIT
Potterton part no. 200620
