POTTERTON
NETAHEAT MK 2E 10/16 (FIELD TRIAL) - (Identification)
Appliance Code: 41-601-62

Appliance Diagram


Identification diagram for Potterton Netaheat MK 2E 10/16 (Field Trial)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE W WAY MONO BLOC KIT N H
Potterton part no. 907223

3   OBSOLETE COVER PLATE LH
Potterton part no. 200459

4   OBSOLETE COVER PLATE RH
Potterton part no. 200487

5 Part number 200337, COVER PLATE GASKET COVER PLATE GASKET
Potterton part no. 200337

9   OBSOLETE THERMOSTAT POCKET ASSY
Potterton part no. 206750

16   OBSOLETE SUPPORT ANGLE
Potterton part no. 205195

17   OBSOLETE BEARING PLATE
Potterton part no. 205197

18   OBSOLETE FLEXIBLE STRIP
Potterton part no. 205198

19   OBSOLETE SHIM STRIP
Potterton part no. 205196

20   OBSOLETE REAR PANEL INSULATION
Potterton part no. 205694

24 Part number 200350, OBSOLETE SILICONE CORD SEAL OBSOLETE SILICONE CORD SEAL
Potterton part no. 200350

30   OBSOLETE M8 X 18MM STUD
Potterton part no. 635225
£2.89
34   OBSOLETE C/CHBR PNL S/A RH N/HEAT
Potterton part no. 205277

35   OBSOLETE DEFLECTOR CHANNEL RH
Potterton part no. 200756

36   OBSOLETE DEFLECTOR SPACER
Potterton part no. 200375

40   OBSOLETE C/CHBR PNL S/A LH N/HEAT
Potterton part no. 205278

44 Part number 65063601, ROPE CERAMIC TWIST 5MM 1 MTR ROPE CERAMIC TWIST 5MM 1 MTR
Potterton part no. 65063601

46 Part number 409568, FAN ASSY FFB 1706 008 FAN ASSY FFB 1706 008
Potterton part no. 409568
£239.28
48   OBSOLETE FLUE HOOD ASSY
Potterton part no. 200304

50 Part number 65063701, ROPE CERAMIC CABLE12MM X 1M L ROPE CERAMIC CABLE12MM X 1M L
Potterton part no. 65063701

52   OBSOLETE GROMMET 9/16
Potterton part no. 640551

55 Part number 200396, SIDE PANEL INSULATION SIDE PANEL INSULATION
Potterton part no. 200396

56   OBSOLETE CABLE TIE 95MM LONG (MS SERIES) - NATURAL NYLO
Potterton part no. 640684

57   OBSOLETE C/CHBR FRONT PANEL ASSY
Potterton part no. 200368

59   OBSOLETE FRT PANEL INSULATION
Potterton part no. 200387

61   OBSOLETE SWITCH FAN PRESSURE
Potterton part no. 64220401

65 Part number 200468, HOSE COUPLING HOSE COUPLING
Potterton part no. 200468

87 Part number 404456, THERMOSTAT RANCO CL.6 THERMOSTAT RANCO CL.6
Potterton part no. 404456

93   OBSOLETE CONTROL IG N S CE KIT N HT E/
Potterton part no. 40766101

105   OBSOLETE CONT COVER ASSY SPARES
Potterton part no. 205264

112 Part number 200277, THERMOSTAT KNOB THERMOSTAT KNOB
Potterton part no. 200277

113   OBSOLETE CONT PNL BKT/A RH
Potterton part no. 205155

116   OBSOLETE CONT PNL BKT/A LH
Potterton part no. 205156

122   OBSOLETE FLUE OUTLET AND FLUE DUCT ASSEMBLY - SERVICE K
Potterton part no. 210086

125   OBSOLETE GASKET
Potterton part no. 200313

127   OBSOLETE ROPE CERAMIC BRAID 20MM 1 MT
Potterton part no. 65063101

128   OBSOLETE TERML BOX S/A N/H 10/16
Potterton part no. 205272

129   OBSOLETE TERM.BOX W/ASSY.N/H/E.GLC
Potterton part no. 205604

130   OBSOLETE TERMINAL BOX GRILLE
Potterton part no. 356191

139   OBSOLETE TERMINAL WALL LINER
Potterton part no. 205968

142   OBSOLETE CONTROL GAS K25 KIT NHT
Potterton part no. 905371

145   OBSOLETE NIPPLE TAPER 3/8BSP MS
Potterton part no. 625403

146   OBSOLETE ELBO REDUC F/F 1/2X3/8BSP
Potterton part no. 626914

147   OBSOLETE ELBOW - MALE/FEMALE 1/8IN BSP
Potterton part no. 627102

148   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988

149   OBSOLETE REDUC BUSH 3/8X1/8BSP MS
Potterton part no. 629130

152   OBSOLETE BURNER MAIN CW INJNHT/2F 10/1
Potterton part no. 906160

153   OBSOLETE ELBOW - FEMALE 3/8IN BSP
Potterton part no. 626933

155   OBSOLETE STRAIGHT UNION 3/8INCH BSP
Potterton part no. 625824

156   OBSOLETE MAIN BURNER INJECTOR 3.6
Potterton part no. 410497

157   OBSOLETE INJECTOR WASHER
Potterton part no. 375993

159   NOW USE 5102870 TUBE ALUM 6MM OD
Potterton part no. 700705

159   TUBE ALUMINIUM 6MM X 4FT
Potterton part no. 5102870
£6.71
160   OBSOLETE PILOT SHIELD
Potterton part no. 200769

161 Part number 402492, SHR OFF UNION 6MM LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492
£5.88
161   OBSOLETE PILOT ASSY W/ROG N HT
Potterton part no. 402842

161   OBSOLETE INJECTOR PILOT NG 2033 NHT 2
Potterton part no. 905476

170   OBSOLETE BURNER GASKET
Potterton part no. 200725

172   OBSOLETE CASING SPARES REPLACEMENT N/H
Potterton part no. 905348

174   OBSOLETE CASE END PLATE INSUL
Potterton part no. 200265

176   OBSOLETE SIGHT GLASS
Potterton part no. 205142

178   OBSOLETE SIGHT GLASS GASKET
Potterton part no. 205143

179   OBSOLETE ANTI-VIBRATION PANEL
Potterton part no. 205600

196   OBSOLETE INFILL SIDE PANEL PACK - ONE PAIR
Potterton part no. 905813

197   OBSOLETE FLUE TERM L GUARD N HT 10/16 1
Potterton part no. 903618

207   OBSOLETE WALL LINER 36
Potterton part no. 205859
