POTTERTON
NETAHEAT MK 1 BF 10/16 - (Identification)
Appliance Code: 41-601-03

Appliance Diagram


Identification diagram for Potterton Netaheat MK 1 BF 10/16Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2   OBSOLETE SUPPORT ANGLE
Potterton part no. 205195
3   OBSOLETE BEARING PLATE
Potterton part no. 205197
4   OBSOLETE FLEXIBLE STRIP
Potterton part no. 205198
6   OBSOLETE SHIM STRIP
Potterton part no. 205196
9   OBSOLETE W WAY MONO BLOC KIT N H
Potterton part no. 907223
11   OBSOLETE COVER PLATE LH
Potterton part no. 200459
12   OBSOLETE COVER PLATE RH
Potterton part no. 200487
13 Part number 200337, COVER PLATE GASKET COVER PLATE GASKET
Potterton part no. 200337
31   OBSOLETE THERMOSTAT POCKET ASSY
Potterton part no. 206750
33   OBSOLETE FLUE HOOD ASSY
Potterton part no. 200304
34 Part number 65063701, ROPE CERAMIC CABLE12mm X 1M L ROPE CERAMIC CABLE12MM X 1M L
Potterton part no. 65063701
39 Part number 409568, FAN ASSY FFB 1706 008 FAN ASSY FFB 1706 008
Potterton part no. 409568		 £239.28
41   OBSOLETE FAN LEAD ASSY
Potterton part no. 200530
47   OBSOLETE KIT INSUL COMB CHAMBER NETA/
Potterton part no. 905814
51 Part number 700723, ALUMINIUM TUBE KIT 6mm OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723
57   STUD MINI COUPLING
Potterton part no. 401584		 £2.59
60   OBSOLETE C/CHBR PNL S/A RH N/HEAT
Potterton part no. 205277
61   OBSOLETE C/CHBR PNL S/A LH N/HEAT
Potterton part no. 205278
64 Part number 200396, SIDE PANEL INSULATION SIDE PANEL INSULATION
Potterton part no. 200396
65   OBSOLETE DEFLECTOR SPACER
Potterton part no. 200375
67 Part number 65063601, ROPE CERAMIC TWIST 5mm 1 MTR ROPE CERAMIC TWIST 5MM 1 MTR
Potterton part no. 65063601
68   OBSOLETE REAR PANEL INSULATION
Potterton part no. 205694
69   OBSOLETE C/CHBR FRONT PANEL ASSY
Potterton part no. 200368
71   OBSOLETE FRT PANEL INSULATION
Potterton part no. 200387
77   OBSOLETE SEAL SILICONE 45MM LONG N/H M
Potterton part no. 200349
77 Part number 200350, OBSOLETE SILICONE CORD SEAL OBSOLETE SILICONE CORD SEAL
Potterton part no. 200350
81   OBSOLETE BURNER BLADE
Potterton part no. 356165
86   OBSOLETE INJECTOR WATTS 0 95 NETA 10
Potterton part no. 410455
86   OBSOLETE INJECTOR MAIN BURNER SIZE 1.05MM ORIFICE
Potterton part no. 410454
96   OBSOLETE KIT ELECTRODE HOUSING AND GASKET
Potterton part no. 905816
97 Part number 905346, OBSOLETE ELECTRODE+LEAD, KIT N OBSOLETE ELECTRODE+LEAD, KIT N
Potterton part no. 905346
100   OBSOLETE PROTECTOR ELECTRODE NHEAT
Potterton part no. 200636
100   OBSOLETE GASKET ELECTRODE HOUSING N HT
Potterton part no. 200481
103   OBSOLETE PILOT BURNER AND FEED ASSEMBLY
Potterton part no. 200447
104   OBSOLETE PILOT ONLY CONC NHT
Potterton part no. 402483
105   OBSOLETE INJECTOR PILOT BURNER - CONCENTRIC M/SA/249
Potterton part no. 410440
106   COMPRESSION NUT 1/8" BSP
Potterton part no. 401582		 £5.12
106   OBSOLETE LOCKNUT 1/4 X 28UNF NETAHEAT
Potterton part no. 200529
113   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988
116   OBSOLETE INJECTOR WASHER
Potterton part no. 375993
117   OBSOLETE ELBOW 1/2 X 1/2 M&F GF 92
Potterton part no. 627101
118   OBSOLETE VALVE M/VAP MFL/A 16/22 N HT
Potterton part no. 404452
118   OBSOLETE VALVE M/VAP MF/A 10/16 N HT
Potterton part no. 404451
123   OBSOLETE GOVERNOR 1/2" BSP 150DJ 23 JVN
Potterton part no. 403310
125   OBSOLETE VALVE SOLENOID 1/2" BSP NHT
Potterton part no. 40253501
126 Part number 629828, GASCOCK ASY L/K 1/2MF BRS GASCOCK ASY L/K 1/2MF BRS
Potterton part no. 629828
156   OBSOLETE SWITCH FAN PRESSURE
Potterton part no. 64220401
158   OBSOLETE FUSE HOLDER
Potterton part no. 640120
159   FUSE 1AMP 1/4'DIA X1.1/4'
Potterton part no. 641902		 £4.57
163   OBSOLETE RELAY SOCKET 8 WAY
Potterton part no. 640699
166 Part number 407654, OBSOLETE SPARK GENR PLESSEY OBSOLETE SPARK GENR PLESSEY
Potterton part no. 407654
181 Part number 905815, TUBE ASSY, PRESSURE PVC, NETA TUBE ASSY, PRESSURE PVC, NETA
Potterton part no. 905815
185 Part number 200277, THERMOSTAT KNOB THERMOSTAT KNOB
Potterton part no. 200277
186   OBSOLETE FLUE OUTLET AND FLUE DUCT ASSEMBLY - SERVICE K
Potterton part no. 210086
187   OBSOLETE GASKET
Potterton part no. 200313
191   OBSOLETE TERML BOX S/A N/H 10/16
Potterton part no. 205272
193   OBSOLETE TERMINAL BOX GRILLE
Potterton part no. 356191
196   OBSOLETE TAPE 1M SECTION GLASS FIBRE
Potterton part no. 650639
199   OBSOLETE TERMINAL WALL LINER
Potterton part no. 205968
202   OBSOLETE FLUE OUTLET ASSEMBLY - SERVICE KIT
Potterton part no. 210087
203   OBSOLETE GASKET TERMINAL DUCT NETAHEAT
Potterton part no. 200376
206   OBSOLETE TERMINAL ASSEMBLY
Potterton part no. 200324
207   OBSOLETE TERM.INLET DUCT ASSY
Potterton part no. 205827
214   OBSOLETE ROPE CERAMIC BRAID 20MM 1 MT
Potterton part no. 65063101
220   OBSOLETE TERM BAFFLE W/ASY 16/22
Potterton part no. 200326
220   OBSOLETE SEALING RING
Potterton part no. 20032701
220   OBSOLETE TERMINAL - OUTER HALF
Potterton part no. 200325
221   OBSOLETE CASING SPARES REPLACEMENT N/H
Potterton part no. 905348
230   OBSOLETE INFILL SIDE PANEL PACK - ONE PAIR
Potterton part no. 905813
