POTTERTON
NETAHEAT ELECTRONIC 6/10 - (Identification)
Appliance Code: 41-601-68

Appliance Diagram


Identification diagram for Potterton Netaheat Electronic 6/10Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE W WAY MONO BLOC KIT N H
Potterton part no. 907223
2   OBSOLETE COVER PLATE LH
Potterton part no. 200459
3   OBSOLETE COVER PLATE RH
Potterton part no. 200487
4 Part number 200337, COVER PLATE GASKET COVER PLATE GASKET
Potterton part no. 200337
8   OBSOLETE THERMO.POCKET ASSY.
Potterton part no. 205810
8 Part number 631104, OBSOLETE SPLIT COTTER PIN OBSOLETE SPLIT COTTER PIN
Potterton part no. 631104
8   OBSOLETE THERMOSTAT LOCATOR - BOILER
Potterton part no. 205798
9   OBSOLETE FLOW PIPE
Potterton part no. 200338
10   OBSOLETE CLAMP PLATE
Potterton part no. 200339
11   OBSOLETE CLAMP SEAL
Potterton part no. 200340
14   OBSOLETE BACK PLATE ASSEMBLY - REPLACEMENT
Potterton part no. 907218
15   OBSOLETE SUPPORT ANGLE
Potterton part no. 205195
16   OBSOLETE BEARING PLATE
Potterton part no. 205197
17   OBSOLETE FLEXIBLE STRIP
Potterton part no. 205198
18   OBSOLETE REAR PANEL INSULATION
Potterton part no. 205694
19   OBSOLETE SHIM STRIP
Potterton part no. 205196
22   OBSOLETE PRESSURE TUBE - REAR
Potterton part no. 200850
23   OBSOLETE VACUUM TUBE
Potterton part no. 200849
23 Part number 700723, ALUMINIUM TUBE KIT 6MM OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723
24   OBSOLETE SCW PAN HD POSI M6 X 12MM
Potterton part no. 633955
25   OBSOLETE GROMMET SILICONE RUBBER
Potterton part no. 642417
26 Part number 642427, GROMMET 1.7 I/D SIL. RUBR GROMMET 1.7 I/D SIL. RUBR
Potterton part no. 642427
27   GROMMET
Potterton part no. 642439		 £1.98
28   OBSOLETE PRESSURE TUBE CLAMP
Potterton part no. 200443
29   OBSOLETE PRESSURE TUBE CLAMP
Potterton part no. 200525
31   OBSOLETE CONTROL PANEL BRACKET ASSEMBLY LH
Potterton part no. 210048
32   OBSOLETE CONT.PNL.BRKT RH.ASSY
Potterton part no. 210049
33   OBSOLETE SCREW.PAN.HD.POSI.M6X45MM
Potterton part no. 633974
34 Part number 200350, OBSOLETE SILICONE CORD SEAL OBSOLETE SILICONE CORD SEAL
Potterton part no. 200350
35   OBSOLETE SPIRE NUT RETAINER M6
Potterton part no. 630164
35   OBSOLETE PIPE SEAL
Potterton part no. 202546
41 Part number 642602, OBSOLETE TERMINAL BUSH HEYCO 2 WAY OBSOLETE TERMINAL BUSH HEYCO 2 WAY
Potterton part no. 642602
43   OBSOLETE C/CHBR PNL S/A RH N/HEAT
Potterton part no. 205277
44   OBSOLETE DEFLECTOR CHANNEL N/H E
Potterton part no. 205772
45   OBSOLETE DEFLECTOR SPACER
Potterton part no. 200375
48   OBSOLETE C/CHBR PNL S/A LH N/HEAT
Potterton part no. 205278
53 Part number 409568, FAN ASSY FFB 1706 008 FAN ASSY FFB 1706 008
Potterton part no. 409568		 £239.28
55   OBSOLETE FLUE HOOD ASSY
Potterton part no. 205843
57 Part number 65063701, ROPE CERAMIC CABLE12MM X 1M L ROPE CERAMIC CABLE12MM X 1M L
Potterton part no. 65063701
61   OBSOLETE C/CHBR FRONT PANEL ASSY
Potterton part no. 200368
63   OBSOLETE FRT PANEL INSULATION
Potterton part no. 200387
64   OBSOLETE FAN LEAD ASSY
Potterton part no. 205907
70   OBSOLETE CONT.PANEL ASS.N/H.E.
Potterton part no. 205654
72 Part number 404480, OBSOLETE BOILER STAT.N/H.E.10/16 OBSOLETE BOILER STAT.N/H.E.10/16
Potterton part no. 404480
73   OBSOLETE SWITCH FAN PRESSURE
Potterton part no. 64220401
74   OBSOLETE PRESS.SWITCH BRKT ASSY
Potterton part no. 205648
75   OBSOLETE PVC SLEEVING X 240MM
Potterton part no. 205816
77   OBSOLETE TERML BLK 12 WAY 10 AMP
Potterton part no. 640303
78   OBSOLETE INSULATION TERM.BLOCK
Potterton part no. 205651
81   OBSOLETE SNAP BUSH HEYCO SB 437 5
Potterton part no. 642422
82   OBSOLETE SNAP BUSH HEYCO SB 500 6
Potterton part no. 642425
83 Part number 407676, FLAM MONITOR/IGN.CONT.MK1A FLAM MONITOR/IGN.CONT.MK1A
Potterton part no. 407676		 £230.93
84   PCB SUPPORT
Potterton part no. 630785		 £2.76
85   OBSOLETE PCB SUPPORT SPACER
Potterton part no. 630786
86   OBSOLETE TAB 45 DEGREE ANGLE
Potterton part no. 642604
87 Part number 200468, HOSE COUPLING HOSE COUPLING
Potterton part no. 200468
88   OBSOLETE WASHER FLAT SPECIAL
Potterton part no. 630792
89   OBSOLETE PVC SLEEVE.641250 X 200MM
Potterton part no. 205818
93   OBSOLETE SCREW S/T POZ 4BX22MM ZP
Potterton part no. 612364
94   OBSOLETE SCREW S/T POZ 6BX1/2 ZP
Potterton part no. 613434
95   OBSOLETE TERMINAL CONNECTOR 4 WAY
Potterton part no. 640826
102   OBSOLETE CONTROLS COVER ASSEMBLY
Potterton part no. 205850
103   OBSOLETE CONTROLS COVER SUB ASSEMBLY
Potterton part no. 210054
104   OBSOLETE CONTROL CVR FACIA PAINTED
Potterton part no. 205835
105   OBSOLETE FACIA WINDOW SLIDING
Potterton part no. 205618
106   OBSOLETE FACIA WINDOW FIXED
Potterton part no. 205619
107   OBSOLETE WINDOW RETAINING PLATE
Potterton part no. 205640
108   OBSOLETE PUSHNUT FASTENER
Potterton part no. 630341
109   OBSOLETE PLUG FOR 14.3MM HOLE - BLACK NYLON TYPE DP-562
Potterton part no. 642437
113   OBSOLETE SCREW.M5X20MM.DOG POINT
Potterton part no. 633910
114 Part number 200505, SCREW RETAINING WASHER SCREW RETAINING WASHER
Potterton part no. 200505		 £2.40
116 Part number 200277, THERMOSTAT KNOB THERMOSTAT KNOB
Potterton part no. 200277
117 Part number 205743, ELECTRODE LEAD ASS.N/H E ELECTRODE LEAD ASS.N/H E
Potterton part no. 205743
118   OBSOLETE BURNER MAIN CW INJ NHT/E 6/1
Potterton part no. 907220
120   OBSOLETE STRAIGHT UNION 3/8INCH BSP
Potterton part no. 625824
121   OBSOLETE MAIN BURNER INJECTOR - 2.8MM ORIFICE - SPECIAL
Potterton part no. 410955
122   OBSOLETE INJECTOR WASHER
Potterton part no. 375993
123   OBSOLETE SCW HEX HD 2BA X 1/4IN
Potterton part no. 601428
126 Part number 402492, SHR OFF UNION 6MM LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492		 £5.88
126 Part number 402890, PILOT ASSY, PREC SP EQUIP N'HT PILOT ASSY, PREC SP EQUIP N'HT
Potterton part no. 402890		 £78.18
126   OBSOLETE CIRCLIP
Potterton part no. 402896
126   OBSOLETE PILOT INJECTOR 0.48DIA
Potterton part no. 402899
127 Part number 407675, OBSOLETE IGNITION ELECTRODE OBSOLETE IGNITION ELECTRODE
Potterton part no. 407675
128 Part number 205705, OBSOLETE SPARK EARTHING BRACKET OBSOLETE SPARK EARTHING BRACKET
Potterton part no. 205705
130   OBSOLETE PILOT SHIELD
Potterton part no. 205849
132   OBSOLETE PILOT SUPPLY ELBOW
Potterton part no. 205929
133   OBSOLETE LOCKNUT
Potterton part no. 629680
134   COMPRESSION NUT 1/8" BSP
Potterton part no. 401582		 £5.12
135   OLIVE 6MM BORE
Potterton part no. 401624		 £2.95
136   WASHER INJ
Potterton part no. 400984		 £3.16
137   OBSOLETE BURNER GASKET
Potterton part no. 200725
140   OBSOLETE CONTROL GAS N HT/
Potterton part no. 907219
142   OBSOLETE ELBOW - MALE/FEMALE 1/8IN BSP
Potterton part no. 627102
143   OBSOLETE REDUC BUSH 3/8X1/8BSP MS
Potterton part no. 629130
144   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988
145   OBSOLETE GAS COCK MULTI ANGLED INTER ALBION 10A
Potterton part no. 629854
147   OBSOLETE FLUE HOOD GASKET
Potterton part no. 200520
148   OBSOLETE FLUE OUTLT.ASS.N/H/E10/16
Potterton part no. 205689
149   OBSOLETE SEAL.RNG.ASS.N/H/E.
Potterton part no. 205779
150   OBSOLETE SEALING PLATE INNER
Potterton part no. 205636
151   GASKET INNER
Potterton part no. 205642
152   OBSOLETE SEALING PLATE OUTER
Potterton part no. 205637
153   OBSOLETE GASKET OUTER
Potterton part no. 205641
154   OBSOLETE INNER CHAMBER INSULATION
Potterton part no. 205691
155   OBSOLETE ROPE GASKET 1.22 METRE
Potterton part no. 650606
157   SCREW M4X16 MCPAN POZ SN
Potterton part no. 633973		 £2.59
159   OBSOLETE OUTER DUCT ASS.N.H.E.
Potterton part no. 205634
160   OBSOLETE INNER DUCT ASS.N/H/E.
Potterton part no. 205646
163 Part number 205635, NOW USE 5106693 TERMINAL GRILLE NOW USE 5106693 TERMINAL GRILLE
Potterton part no. 205635
163 Part number 5106693, REMEDIAL FLUE DUCT KIT 30/50 REMEDIAL FLUE DUCT KIT 30/50
Potterton part no. 5106693		 £46.57
164   OBSOLETE SPARES REPLACE.CASING.NH/E
Potterton part no. 907217
168   OBSOLETE ESCUTCHEON PLATE ASSN/H
Potterton part no. 205144
169   OBSOLETE SIGHT GLASS
Potterton part no. 205142
170   OBSOLETE SIGHT GLASS GASKET
Potterton part no. 205143
171   OBSOLETE CASE END PLATE INSUL
Potterton part no. 200265
173   OBSOLETE WASHER M6 SHAKEPROOF EXT
Potterton part no. 617411
174   OBSOLETE SCREW RETAINING WASHER
Potterton part no. 200548
177   OBSOLETE INFILL SIDE PANEL PACK - ONE PAIR
Potterton part no. 905813
186   OBSOLETE INTERNAL FITMENT KIT
Potterton part no. 205775
189   OBSOLETE DUCTING KIT 72IN SQUARE SECTION
Potterton part no. 205754
190   OBSOLETE KIT TERMINAL GUARD
Potterton part no. 205792
198   OBSOLETE DUCTING KIT 42IN CIRCULAR SECTION
Potterton part no. 205890
