POTTERTON
KINGFISHER CF80 - (Identification)
Appliance Code: 41-601-39

Appliance Diagram


Identification diagram for Potterton Kingfisher CF80Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE PILOT ONLY L/H
Potterton part no. 410498

0   OBSOLETE REGULATOR PRESS V5306A/E HW
Potterton part no. 904751

0 Part number 200455, OBSOLETE FLUE BRUSH OBSOLETE FLUE BRUSH
Potterton part no. 200455
£2.78
1   OBSOLETE FLUE HOOD ASSEMBLY
Potterton part no. 204421

3 Part number 65063701, ROPE CERAMIC CABLE12MM X 1M L ROPE CERAMIC CABLE12MM X 1M L
Potterton part no. 65063701

10   OBSOLETE HEAT EXCH ASSY K/F RS 80
Potterton part no. 204382

11   OBSOLETE W/WAY SECTION L/H K/F REAR F
Potterton part no. 906168

12   OBSOLETE PLUG RECESSED SOCKET 1IN
Potterton part no. 629414

13   OBSOLETE HEAT EXCHANGER INTER
Potterton part no. 204227

14   OBSOLETE THERMOSTAT POCKET ASSY
Potterton part no. 206750

16   OBSOLETE DIVERTER DISC
Potterton part no. 204771

16   OBSOLETE WATERWAY SECTION - RH
Potterton part no. 906154

18 Part number 401631, OBSOLETE O RING GACO OBSOLETE O RING GACO
Potterton part no. 401631

19   OBSOLETE TIE ROD M8 X 295MM
Potterton part no. 635813

22   OBSOLETE STUD M6 X20MM MS
Potterton part no. 635207

23   OBSOLETE M8 X 18MM STUD
Potterton part no. 635225
£2.89
24   OBSOLETE H/EXCH FIXING BRKT
Potterton part no. 204258

34   OBSOLETE COMBUSTION CHAMBER ASSY
Potterton part no. 204401

36   OBSOLETE INSULATION SIDE
Potterton part no. 204291

37   OBSOLETE INSULATION BACK
Potterton part no. 204293

38   OBSOLETE INSULATION FRONT
Potterton part no. 204403

39   OBSOLETE HEATSHIELD
Potterton part no. 204404

102 Part number 629828, GASCOCK ASY L/K 1/2MF BRS GASCOCK ASY L/K 1/2MF BRS
Potterton part no. 629828

108 Part number 402492, SHR OFF UNION 6MM LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492
£5.88
108   OBSOLETE GAS VALVE BOXED
Potterton part no. 402809

109   OBSOLETE CONTROL VALVE LEAD ASSY
Potterton part no. 204244

111   OBSOLETE TOP OUTLET COVER
Potterton part no. 402816

113   OBSOLETE OPERATOR SOLENOID TRADELINE
Potterton part no. 904750

117   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988

119   OBSOLETE C/CHBR DOOR ASY K/F CF80
Potterton part no. 204412

122 Part number 700723, ALUMINIUM TUBE KIT 6MM OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723

122 Part number 40225701, NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY
Potterton part no. 40225701

122 Part number Q309A2788, THERMOCOUPLE THERMOCOUPLE
Potterton part no. Q309A2788
£8.96
124 Part number 410917, PILOT INJ DUAL ORIFICE PILOT INJ DUAL ORIFICE
Potterton part no. 410917

131   OBSOLETE BURNER ASSY FURIGAS
Potterton part no. 414561

131   OBSOLETE BURNER ASSEMBLY
Potterton part no. 414566

132 Part number 906155, OBSOLETE FILTER L/R INTL 414561 41456 OBSOLETE FILTER L/R INTL 414561 41456
Potterton part no. 906155

133   OBSOLETE PLATE BURNER END K/F CF8
Potterton part no. 906157

134 Part number 906162, NOW USE 308S111 GASKET BURNER CF20/30 80 10 NOW USE 308S111 GASKET BURNER CF20/30 80 10
Potterton part no. 906162

134 Part number 308S111, END PLATE GASKET END PLATE GASKET
Potterton part no. 308S111
£7.73
138   OBSOLETE BRNR INJ 3.1MM AEROMATIC
Potterton part no. 410908

148 Part number 404456, THERMOSTAT RANCO CL.6 THERMOSTAT RANCO CL.6
Potterton part no. 404456

151 Part number 200277, THERMOSTAT KNOB THERMOSTAT KNOB
Potterton part no. 200277

162   OBSOLETE TERML BLK 12 WAY 10 AMP
Potterton part no. 640303
