POTTERTON
KINGFISHER CF40 - (Identification)
Appliance Code: 41-601-57

Appliance Diagram


Identification diagram for Potterton Kingfisher CF40Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE FLUE HOOD REPL T KIT KFI CF40
Potterton part no. 906150

2   OBSOLETE FLUE HOOD REDUC PLT CF40/50
Potterton part no. 204585

2   OBSOLETE FLUE HOOD REDUCING PLATE
Potterton part no. 203027

4   OBSOLETE FLUE HOOD SEALING PLATE
Potterton part no. 203032

5 Part number 65063701, ROPE CERAMIC CABLE12mm X 1M L ROPE CERAMIC CABLE12MM X 1M L
Potterton part no. 65063701

5   OBSOLETE GLASS ROPE 12MM DIA
Potterton part no. 650613

11   OBSOLETE HEAT EXCH ASSY K/F RS50
Potterton part no. 204017

12   OBSOLETE COVER PLATE LH
Potterton part no. 200459

13   OBSOLETE COVER PLATE RH
Potterton part no. 200487

14 Part number 200337, COVER PLATE GASKET COVER PLATE GASKET
Potterton part no. 200337

16   OBSOLETE STUD M8 X 36MM LG
Potterton part no. 635226

19   OBSOLETE THERMOSTAT POCKET ASSY
Potterton part no. 206750

27   OBSOLETE COMB.CHBR ASSY CF.40 60
Potterton part no. 206580

28 Part number 203038, OBSOLETE SIDE INSULATION OBSOLETE SIDE INSULATION
Potterton part no. 203038

29   OBSOLETE REAR INSULATION
Potterton part no. 203037

34   OBSOLETE C/CHBR FRONT ASY K/F CF60
Potterton part no. 204801

35   OBSOLETE FRONT PLATE INSUL/N
Potterton part no. 204804

39   OBSOLETE BASE TRAY ASSY CF.40 60
Potterton part no. 206498

103   OBSOLETE BURNER BAR K/F CF40 45
Potterton part no. 414524

105 Part number 905359, OBSOLETE GASKET BURNER KF CF40 45 OBSOLETE GASKET BURNER KF CF40 45
Potterton part no. 905359

109   OBSOLETE GASKET
Potterton part no. 905358

109   OBSOLETE BURNER BAR FURIGAS K/F CF5
Potterton part no. 414572

109   GASKET BURNER END FOR 414572
Potterton part no. 906242

112   OBSOLETE INTERNAL GAUZE
Potterton part no. 905357

112   OBSOLETE INTERNAL GAUZE - FURIGAS BURNER
Potterton part no. 906240

113   OBSOLETE EXTERNAL GAUZE
Potterton part no. 203098

113   OBSOLETE FILTER S/W ASY LH CF40ETC
Potterton part no. 203131

113   OBSOLETE FILTER S/W ASY RH CF40ETC
Potterton part no. 203130

119   OBSOLETE BRNR INJ 3.5 AEROMATIC
Potterton part no. 410902

122   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988

126 Part number 301461, MANIFOLD GASKET MANIFOLD GASKET
Potterton part no. 301461

127   OBSOLETE GAS VALVE BOXED
Potterton part no. 402809

127   OBSOLETE REGULATOR PRESS V5306A/E HW
Potterton part no. 904751

127   OBSOLETE OPERATOR SOLENOID TRADELINE
Potterton part no. 904750

128   OBSOLETE CONTROL VALVE LEAD ASSY
Potterton part no. 204244

129   OBSOLETE PLUG 3POLE BULGIN SA 2403
Potterton part no. 640249

130   OBSOLETE STRAIN RELIEF BUSH
Potterton part no. 640773

131 Part number 629828, GASCOCK ASY L/K 1/2MF BRS GASCOCK ASY L/K 1/2MF BRS
Potterton part no. 629828

131 Part number 629860, NOW USE 042811 UNION NUT 7/8inch BSP NOW USE 042811 UNION NUT 7/8INCH BSP
Potterton part no. 629860

131   LINER 1/2" BSP
Potterton part no. 629863
£6.09
131 Part number 042811, NUT-UNION- (for 7/8 BSP LINER) NUT-UNION- (FOR 7/8 BSP LINER)
Potterton part no. 042811
£9.11
132 Part number 402492, SHR OFF UNION 6mm LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492
£5.88
133 Part number 700723, ALUMINIUM TUBE KIT 6mm OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723

135   OBSOLETE PILOT ASSY
Potterton part no. 905278

135   BRKT B TYPE L LH TARGET
Potterton part no. 410483

136 Part number 102041, INJECTOR PILOT.NG.BCR-18 INJECTOR PILOT.NG.BCR-18
Potterton part no. 102041

136 Part number 410209, PILOT INJ HONEYWELL BCR 18 PILOT INJ HONEYWELL BCR 18
Potterton part no. 410209

140 Part number 40225701, NOW USE Q309A2788 THERMOCOUPLE 1000mm Q309/MTRL TY NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY
Potterton part no. 40225701

140 Part number Q309A2788, THERMOCOUPLE THERMOCOUPLE
Potterton part no. Q309A2788
£8.96
143 Part number 200277, THERMOSTAT KNOB THERMOSTAT KNOB
Potterton part no. 200277

144 Part number 404456, THERMOSTAT RANCO CL.6 THERMOSTAT RANCO CL.6
Potterton part no. 404456

151   OBSOLETE SKT 3 POLE BULGIN SA 2404
Potterton part no. 640253

154   OBSOLETE TERML BLK 12 WAY 10 AMP
Potterton part no. 640303

305 Part number 200455, OBSOLETE FLUE BRUSH OBSOLETE FLUE BRUSH
Potterton part no. 200455
£2.78
