POTTERTON
GOLD 24 HE COMBI - (Wall Jig)
Appliance Code: 47-590-05

Appliance Diagram


Wall Jig diagram for Potterton Gold 24 HE CombiClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

601 Part number 248100, WALL JIG ASSEMBLY WALL JIG ASSEMBLY
Potterton part no. 248100
£28.54
602 Part number 248224, TAP - ISOLATION - FLOW TAP - ISOLATION - FLOW
Potterton part no. 248224
£33.91
603 Part number 248225, TAP - ISOLATION - RETURN TAP - ISOLATION - RETURN
Potterton part no. 248225
£43.27
604 Part number 248226, TAP - ISOLATION - DHW RETURN TAP - ISOLATION - DHW RETURN
Potterton part no. 248226
£31.48
605 Part number 248227, ELBOW - DHW OUTLET ELBOW - DHW OUTLET
Potterton part no. 248227
£9.51
606 Part number 248230, ELBOW - GAS INLET ELBOW - GAS INLET
Potterton part no. 248230
£9.51
607 Part number 248228, CONNECTION TAIL - 15MM CONNECTION TAIL - 15MM
Potterton part no. 248228
£7.15
608   CONNECTION TAIL - 22MM
Potterton part no. 248229
£9.51
609 Part number 248231, PIPE-DISCHARGE-SAFETY VALVE PIPE-DISCHARGE-SAFETY VALVE
Potterton part no. 248231
£11.95
610 Part number 247485, TAP TAP
Potterton part no. 247485
£19.05
611 Part number 247758, LOCK NUT - G3/4 LOCK NUT - G3/4
Potterton part no. 247758
£5.88
612 Part number 247760, LOCK NUT - G1/2 LOCK NUT - G1/2
Potterton part no. 247760
£5.88
613 Part number 247744, SEALING WASHER G. 1/2 SEALING WASHER G. 1/2
Potterton part no. 247744
£3.16
614 Part number 247745, SEALING WASHER G. 3/4 SEALING WASHER G. 3/4
Potterton part no. 247745
£3.16
616 Part number 247764, RUBBER SEAL - GAS TAP RUBBER SEAL - GAS TAP
Potterton part no. 247764
£3.26
617 Part number 5116018, FLOW RESTRICTOR 10L/MIN FLOW RESTRICTOR 10L/MIN
Potterton part no. 5116018
£7.62
617 Part number 5114712, FLOW RESTRICTOR FLOW RESTRICTOR
Potterton part no. 5114712
£7.74
618 Part number 248221, FILLING LOOP KIT (FLEXIBLE) FILLING LOOP KIT (FLEXIBLE)
Potterton part no. 248221
£21.94
