POTTERTON
FLAMINGO RS 13 FURIGAS BURNERS - (Outer Case)
Appliance Code: 41-601-12

Appliance Diagram


Outer Case diagram for Potterton Flamingo RS 13 Furigas BurnersClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE BACK PLATE ASSY F/G RS 40
Potterton part no. 202204

3   OBSOLETE HEAT EXCH ASSY K/F RS50
Potterton part no. 204017

5   OBSOLETE COVER PLATE LH
Potterton part no. 200459

6   OBSOLETE COVER PLATE RH
Potterton part no. 200487

7 Part number 200337, COVER PLATE GASKET COVER PLATE GASKET
Potterton part no. 200337

12   OBSOLETE THERMOSTAT POCKET ASSY
Potterton part no. 206750

18   OBSOLETE FLUE HOOD ASS.K/F.RS50
Potterton part no. 202047

20 Part number 65063701, ROPE CERAMIC CABLE12MM X 1M L ROPE CERAMIC CABLE12MM X 1M L
Potterton part no. 65063701

24   OBSOLETE FLUE HOOD CLAMPING BRKT
Potterton part no. 202682

25   OBSOLETE FLUE HOOD CLAMPING ROD
Potterton part no. 202702

32   OBSOLETE COMBUSTION CHAMBER ASSEMBLY RS13
Potterton part no. 907232

34   OBSOLETE COMB CHAMB INSUL REAR
Potterton part no. 202091

35   OBSOLETE COMB CHAMB INSUL FRONT
Potterton part no. 202092

36   OBSOLETE C/CHBR INSUL LH FL/KFISH
Potterton part no. 202093

37 Part number 202094, OBSOLETE C/CHBR INSUL RH FL/KFISH OBSOLETE C/CHBR INSUL RH FL/KFISH
Potterton part no. 202094

49   OBSOLETE GASKET SIGHT GLASS PR K/F F
Potterton part no. 907166

50 Part number 413501, OBSOLETE SIGHT GLASS OBSOLETE SIGHT GLASS
Potterton part no. 413501

55   OBSOLETE SIGHT GLASS RETAINER
Potterton part no. 202100

60   OBSOLETE PILOT BRNR ASSY F/G RS 13
Potterton part no. 402489

61 Part number 410209, PILOT INJ HONEYWELL BCR 18 PILOT INJ HONEYWELL BCR 18
Potterton part no. 410209

61 Part number 102041, INJECTOR PILOT.NG.BCR-18 INJECTOR PILOT.NG.BCR-18
Potterton part no. 102041

62 Part number 402492, SHR OFF UNION 6MM LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492
£5.88
64 Part number 407625, OBSOLETE ELECTRODE ASSEMBLY OBSOLETE ELECTRODE ASSEMBLY
Potterton part no. 407625

65 Part number 407626, ELECTRODE LEAD ELECTRODE LEAD
Potterton part no. 407626

66 Part number 40225701, NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY
Potterton part no. 40225701

66 Part number Q309A2788, THERMOCOUPLE THERMOCOUPLE
Potterton part no. Q309A2788
£8.96
69   OBSOLETE BURNER BAR FURIGAS
Potterton part no. 414533

74   OLIVE 6MM BORE
Potterton part no. 401624
£2.95
75   COMPRESSION NUT 1/8" BSP
Potterton part no. 401582
£5.12
76 Part number 700723, ALUMINIUM TUBE KIT 6MM OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723

80   OBSOLETE AEROMATIC BRNR INJ 3.4MM
Potterton part no. 410488

81   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988

85   OBSOLETE POWER UNIT
Potterton part no. 904752

85   OBSOLETE OPERATOR SOLENOID TRADELINE
Potterton part no. 904750

85   OBSOLETE REGULATOR PRESS V5306A/E HW
Potterton part no. 904751

85   OBSOLETE CONTROL GAS V4400C S VCE KIT
Potterton part no. 906223

96 Part number 629828, GASCOCK ASY L/K 1/2MF BRS GASCOCK ASY L/K 1/2MF BRS
Potterton part no. 629828

121   OBSOLETE PIEZO GENR VERNITRON
Potterton part no. 407627

125 Part number 404456, THERMOSTAT RANCO CL.6 THERMOSTAT RANCO CL.6
Potterton part no. 404456

126 Part number 200277, THERMOSTAT KNOB THERMOSTAT KNOB
Potterton part no. 200277

134   OBSOLETE AIR DUCT ASSEMBLY RS13 50 6
Potterton part no. 907404

137   OBSOLETE TERMINAL PACK K/F2.
Potterton part no. 203660

138   OBSOLETE TERMINAL GRILLE
Potterton part no. 202022

163 Part number 200455, OBSOLETE FLUE BRUSH OBSOLETE FLUE BRUSH
Potterton part no. 200455
£2.78
165   OBSOLETE TERMINAL GUARD RS.80
Potterton part no. 903766
