POTTERTON
FIRESIDE 52 FIRE/BBU CAT 1N - (First Line Spares)
Appliance Code: 44-590-06

Appliance Diagram


First Line Spares diagram for Potterton Fireside 52 Fire/BBU CAT 1NClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2   OBSOLETE RH WATERWAY SECT
Potterton part no. 301524

3   OBSOLETE WATERWAY SECTION INTERMEDIATE
Potterton part no. 301112

6   OBSOLETE O RING SEAL SIZE 341
Potterton part no. 401605

7   OBSOLETE O RING SEAL SIZE 333
Potterton part no. 401606

8   OBSOLETE TIE BOLT
Potterton part no. 301155

11 Part number 376523, OBSOLETE FLOW HEADER GASKET OBSOLETE FLOW HEADER GASKET
Potterton part no. 376523

15   OBSOLETE PLUG RECESSED SOCKET 1IN
Potterton part no. 629414

15   OBSOLETE SUCTION TEE AND FLANGE - 1 IN BSP
Potterton part no. 301510

18   OBSOLETE STUD M10 X 30MM M.S.
Potterton part no. 635208

21   OBSOLETE DRAINING TAP 1/2INCH B.S.P.T
Potterton part no. 629751

22   OBSOLETE THERMOSTAT POCKET
Potterton part no. 405109

24 Part number 65063701, ROPE CERAMIC CABLE12MM X 1M L ROPE CERAMIC CABLE12MM X 1M L
Potterton part no. 65063701

26   OBSOLETE STUD BOLT M8 X25MM
Potterton part no. 619806

27   OBSOLETE COMBUSTION CHAMBER COMPLETE
Potterton part no. 301484

38   OBSOLETE ELECTRODE+LEAD KIT FIRE FS50
Potterton part no. 90391201

49   OBSOLETE DRAUGHT DIVERTER ASSEMBLY
Potterton part no. 30123201

57   OBSOLETE BURNER BAR FS51
Potterton part no. 414096

59   OBSOLETE INJECTOR - NO 30 MORSE - 0.128IN
Potterton part no. 410375

60   OBSOLETE PILOT ASSY
Potterton part no. 905278

60   BRKT B TYPE L LH TARGET
Potterton part no. 410483

61 Part number 102041, INJECTOR PILOT.NG.BCR-18 INJECTOR PILOT.NG.BCR-18
Potterton part no. 102041

61 Part number 410209, PILOT INJ HONEYWELL BCR 18 PILOT INJ HONEYWELL BCR 18
Potterton part no. 410209

65 Part number 905346, OBSOLETE ELECTRODE+LEAD, KIT N OBSOLETE ELECTRODE+LEAD, KIT N
Potterton part no. 905346

66 Part number 40225701, NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY
Potterton part no. 40225701

66 Part number Q309A2788, THERMOCOUPLE THERMOCOUPLE
Potterton part no. Q309A2788
£8.96
68   OBSOLETE ELBO REDUC F/F 1/2X3/8BSP
Potterton part no. 626914

73 Part number 301461, MANIFOLD GASKET MANIFOLD GASKET
Potterton part no. 301461

74   OBSOLETE CONTROL GAS V4400C S VCE KIT
Potterton part no. 906223

75   OBSOLETE OPERATOR SOLENOID TRADELINE
Potterton part no. 904750

76   OBSOLETE REGULATOR PRESS V5306A/E HW
Potterton part no. 904751

78   OBSOLETE POWER UNIT
Potterton part no. 904752

81   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988

93   OBSOLETE KIT PIPE ASSY FS 51 & 52
Potterton part no. 904847

97 Part number 402492, SHR OFF UNION 6MM LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492
£5.88
98 Part number 700723, ALUMINIUM TUBE KIT 6MM OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723

99   OLIVE 6MM BORE
Potterton part no. 401624
£2.95
107   OBSOLETE STAT RANCO T 9301
Potterton part no. 404435

108   OBSOLETE KNOB
Potterton part no. 404446

109   OBSOLETE SPARK GENERATOR KIGASS REPL T
Potterton part no. 90391101

112   OBSOLETE TERML BLK 12 WAY 10 AMP
Potterton part no. 640303

119   OBSOLETE SOCKET BULGIN SA 2111
Potterton part no. 640204

157   OBSOLETE RADIANT CARRIER FS50 52 PLEAS
Potterton part no. 903937

157   OBSOLETE RADIANT FIRE SINGLE FS50 5
Potterton part no. 904844

161   OBSOLETE BURNER BAR
Potterton part no. 904973

164   OBSOLETE INJECTOR BURNER BAR 6 HOLES 380 NAT GAS
Potterton part no. 904955

170   OBSOLETE CONTROL TAP CONCENTRIC JC/A/197
Potterton part no. 903910

173   OBSOLETE KNOB CONTROL VALVE
Potterton part no. 903909

176   OBSOLETE BURNER AEROMATIC LINT RESISTANT 16/12830/LR
Potterton part no. 413909

205   OBSOLETE GAS COCK - 3 WAY TYPE
Potterton part no. 905299

219   COMPRESSION NUT 1/8" BSP
Potterton part no. 401582
£5.12
221   STUD MINI COUPLING
Potterton part no. 401584
£2.59
