POTTERTON
DIPLOMAT 41/48 CONVERTIBLE SB & STD - (Identification)
Appliance Code: 41-591-47

Appliance Diagram


Identification diagram for Potterton Diplomat 41/48 Convertible SB & StdClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE PILOT GOVERNOR - HONEYWELL V5102A 1027
Potterton part no. 903458
0   OBSOLETE SOLENOID OPERATOR - HONEYWELL V4254A 1084
Potterton part no. 902152
0   OBSOLETE FILTER PILOT HONEYWELL AB388 150
Potterton part no. 902160
1   OBSOLETE WATERWAY SECTION ASSEMBLY
Potterton part no. 906919
2   OBSOLETE FRONT MUD HOLE COVER CI TAPPED 1/2
Potterton part no. 314266
3   OBSOLETE GASKET MUD HOLE COVER
Potterton part no. 31426901
4   OBSOLETE REAR MUD HOLE COVER
Potterton part no. 314110
5   OBSOLETE GASKET MUD HOLE REAR EARLY R/
Potterton part no. 314111
6   OBSOLETE FLANGE 1 1/4 BSP 1 SEC R/
Potterton part no. 314192
7 Part number 376523, OBSOLETE FLOW HEADER GASKET OBSOLETE FLOW HEADER GASKET
Potterton part no. 376523
8   OBSOLETE STUD 3/8WH X 1.1/2 MS SF
Potterton part no. 618103
9   OBSOLETE STUD 3/8 BSW X 1 MS SELF
Potterton part no. 619801
10   OBSOLETE STUD 3/8WH X 2 MS SF
Potterton part no. 618104
14   OBSOLETE THERMOSTAT POCKET
Potterton part no. 405109
17   OBSOLETE COMBINED SUCTION TEE AND HEADER CI
Potterton part no. 314118
21   OBSOLETE DRAINING TAP 1/2INCH B.S.P.T
Potterton part no. 629751
22   OBSOLETE INSULATION RETAINER ASSEMBLY
Potterton part no. 375104
35   OBSOLETE DRAUGHT DIVERTER ALUMINIUM
Potterton part no. 314056
47   OBSOLETE CONTROL BOX SR KIT 240V R/R S
Potterton part no. 905303
48   OBSOLETE THERMOSTAT RANCO
Potterton part no. 314133
49   OBSOLETE KNOB THERMOSTAT DEG.F
Potterton part no. 405112
53   OBSOLETE BASE FRAME MS
Potterton part no. 374207
75   OBSOLETE PUMP CIRCULATOR - MYSON SD52 - FLANGED
Potterton part no. 904887
79   OBSOLETE PLUG 3 POLE MAINS L1436/P
Potterton part no. 640103
90   OBSOLETE PILOT ASSY
Potterton part no. 905278
90   BRKT B TYPE L LH TARGET
Potterton part no. 410483
93 Part number Q309A2788, THERMOCOUPLE THERMOCOUPLE
Potterton part no. Q309A2788		 £8.96
93 Part number 40225701, NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY
Potterton part no. 40225701
94 Part number 700723, ALUMINIUM TUBE KIT 6MM OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723
96   COMPRESSION NUT 1/8" BSP
Potterton part no. 401582		 £5.12
97   OBSOLETE GOVERNOR 1/8BSP J10 SSP JVNS
Potterton part no. 403171
100   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988
103   OBSOLETE GAS CONTROL HONEYWELL V4257A 1128 - COMPONENTS
Potterton part no. 402198
105   OBSOLETE GAS COCK LOOSE KEY UNION 1/2IN BSP BRASS
Potterton part no. 629824
145   OBSOLETE BRUSH FLUE 6 X 2 DIA X 24 LG
Potterton part no. 595012		 £4.68
146   OBSOLETE FLUE RAKE 27IN
Potterton part no. 595011
147   OBSOLETE FORTAFIX CEMENT
Potterton part no. 705004
152   OBSOLETE PASTE JOINTING STAG 500GRAM T
Potterton part no. 705013
155   OBSOLETE ELBOW 1/2 X 1/2 M&F GF 92
Potterton part no. 627101
156 Part number 410209, PILOT INJ HONEYWELL BCR 18 PILOT INJ HONEYWELL BCR 18
Potterton part no. 410209
156 Part number 102041, INJECTOR PILOT.NG.BCR-18 INJECTOR PILOT.NG.BCR-18
Potterton part no. 102041
158 Part number 402492, SHR OFF UNION 6MM LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492		 £5.88
160   OLIVE 6MM BORE
Potterton part no. 401624		 £2.95
