POTTERTON
DIPLOMAT 41/48 BI GAS STD SB Q303 - (Identification)
Appliance Code: 41-591-52

Appliance Diagram


Identification diagram for Potterton Diplomat 41/48 BI Gas Std SB Q303Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE WATERWAY SECTION ASSEMBLY
Potterton part no. 906919
2   OBSOLETE FRONT MUD HOLE COVER CI TAPPED 1/2
Potterton part no. 314266
3   OBSOLETE GASKET MUD HOLE COVER
Potterton part no. 31426901
4   OBSOLETE REAR MUD HOLE COVER
Potterton part no. 314110
5   OBSOLETE GASKET MUD HOLE REAR EARLY R/
Potterton part no. 314111
6   OBSOLETE FLANGE 1 1/4 BSP 1 SEC R/
Potterton part no. 314192
7 Part number 376523, OBSOLETE FLOW HEADER GASKET OBSOLETE FLOW HEADER GASKET
Potterton part no. 376523
8   OBSOLETE STUD 3/8WH X 1.1/2 MS SF
Potterton part no. 618103
9   OBSOLETE STUD 3/8 BSW X 1 MS SELF
Potterton part no. 619801
10   OBSOLETE STUD 3/8WH X 2 MS SF
Potterton part no. 618104
14   OBSOLETE THERMOSTAT POCKET
Potterton part no. 405109
17   OBSOLETE COMBINED SUCTION TEE AND HEADER CI
Potterton part no. 314118
21   OBSOLETE DRAINING TAP 1/2INCH B.S.P.T
Potterton part no. 629751
22   OBSOLETE INSULATION RETAINER ASSEMBLY
Potterton part no. 375104
35   OBSOLETE DRAUGHT DIVERTER - ALUMINIUM 4IN DIA
Potterton part no. 314088
35   OBSOLETE DRAUGHT DIVERTER ALUMINIUM
Potterton part no. 314056
47   OBSOLETE CONTROL BOX
Potterton part no. 405128
48   OBSOLETE THERMOSTAT RANCO
Potterton part no. 314133
49   OBSOLETE KNOB THERMOSTAT DEG.F
Potterton part no. 405112
75   OBSOLETE PUMP CIRCULATOR - MYSON SD52 - FLANGED
Potterton part no. 904887
90   OBSOLETE HOLDER INJECTOR C/W NUT CAT
Potterton part no. 410186
91   OBSOLETE INJECTOR CAT 11 SIZE 650 BRA
Potterton part no. 410224
97 Part number 402492, SHR OFF UNION 6MM LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492		 £5.88
98 Part number Q309A2788, THERMOCOUPLE THERMOCOUPLE
Potterton part no. Q309A2788		 £8.96
98 Part number 40225701, NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY
Potterton part no. 40225701
109   OLIVE 6MM BORE
Potterton part no. 401624		 £2.95
109 Part number 700723, ALUMINIUM TUBE KIT 6MM OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723
111   STUD MINI COUPLING
Potterton part no. 401584		 £2.59
116   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988
122   OBSOLETE COCK GAS 3/4 F/F UNION ASSY
Potterton part no. 629765
159   OBSOLETE BRUSH FLUE 6 X 2 DIA X 24 LG
Potterton part no. 595012		 £4.68
