POTTERTON
DIPLOMAT 35/40 SB CONVERTIBLE - (First Line Spares)
Appliance Code: 41-591-46

Appliance Diagram


First Line Spares diagram for Potterton Diplomat 35/40 SB ConvertibleClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2   OBSOLETE FRONT MUD HOLE COVER CI TAPPED 1/2
Potterton part no. 314266
3   OBSOLETE GASKET MUD HOLE COVER
Potterton part no. 31426901
4   OBSOLETE REAR MUD HOLE COVER
Potterton part no. 314110
5   OBSOLETE GASKET MUD HOLE REAR EARLY R/
Potterton part no. 314111
6   OBSOLETE FLANGE 1 1/4 BSP 1 SEC R/
Potterton part no. 314192
7 Part number 376523, OBSOLETE FLOW HEADER GASKET OBSOLETE FLOW HEADER GASKET
Potterton part no. 376523
8   OBSOLETE STUD 3/8WH X 1.1/2 MS SF
Potterton part no. 618103
9   OBSOLETE STUD 3/8 BSW X 1 MS SELF
Potterton part no. 619801
10   OBSOLETE STUD 3/8WH X 2 MS SF
Potterton part no. 618104
14   OBSOLETE THERMOSTAT POCKET
Potterton part no. 405109
17   OBSOLETE COMBINED SUCTION TEE AND HEADER CI
Potterton part no. 314118
21   OBSOLETE DRAINING TAP 1/2INCH B.S.P.T
Potterton part no. 629751
22   OBSOLETE INSULATION RETAINER ASSEMBLY
Potterton part no. 314104
47   OBSOLETE CONTROL BOX SR KIT 240V R/R S
Potterton part no. 905303
48   OBSOLETE THERMOSTAT RANCO
Potterton part no. 314133
49   OBSOLETE KNOB THERMOSTAT DEG.F
Potterton part no. 405112
75   OBSOLETE PUMP CIRCULATOR - MYSON SD52 - FLANGED
Potterton part no. 904887
90   OBSOLETE PILOT ASSY
Potterton part no. 905278
90   BRKT B TYPE L LH TARGET
Potterton part no. 410483
93 Part number Q309A2788, THERMOCOUPLE THERMOCOUPLE
Potterton part no. Q309A2788		 £8.96
93 Part number 40225701, NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY
Potterton part no. 40225701
94 Part number 700723, ALUMINIUM TUBE KIT 6MM OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723
100   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988
105   OBSOLETE GAS COCK LOOSE KEY UNION 1/2IN BSP BRASS
Potterton part no. 629824
151   OBSOLETE BRUSH FLUE 6 X 2 DIA X 24 LG
Potterton part no. 595012		 £4.68
