POTTERTON
C70/21 BE SB CAT 2TN (FURIGAS BNR - (Assembly 4)
Appliance Code: 41-595-65

Appliance Diagram


Assembly 4 diagram for Potterton C70/21 BE SB CAT 2TN (Furigas BNRClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2   OBSOLETE WATERWAY SECTION SUB ASSEMBLY KIT 55/68
Potterton part no. 906920
3   OBSOLETE COVER MUD HOLE FRONT R/
Potterton part no. 314265
4   OBSOLETE GASKET MUD HOLE COVER
Potterton part no. 31426901
5   OBSOLETE STUD 3/8 BSW X 1 MS SELF
Potterton part no. 619801
6   OBSOLETE STUD 3/8WH X 1.1/2 MS SF
Potterton part no. 618103
7   OBSOLETE STUD 3/8WH X 2 MS SF
Potterton part no. 618104
11   OBSOLETE FRONT MUD HOLE COVER CI TAPPED 1/2
Potterton part no. 314266
18   OBSOLETE THERMOSTAT POCKET
Potterton part no. 405109
21   OBSOLETE HEADER FLOW AND RETURN
Potterton part no. 315116
22 Part number 376523, OBSOLETE FLOW HEADER GASKET OBSOLETE FLOW HEADER GASKET
Potterton part no. 376523
25   OBSOLETE COMBINED SUCTION TEE AND HEADER CI SPECIAL
Potterton part no. 315118
29   OBSOLETE DRAINING TAP 1/2INCH B.S.P.T
Potterton part no. 629751
32   OBSOLETE COVER FLUEWAY R/
Potterton part no. 315110
33   OBSOLETE GASKET FLUEWAY COVER
Potterton part no. 31511101
36   OBSOLETE BASE FRAME KIT
Potterton part no. 905343
39   OBSOLETE BASE TRAY MS SPECIAL
Potterton part no. 315150
52   OBSOLETE DRAUGHT DIVERTER ALUMINIUM
Potterton part no. 314056
53   OBSOLETE INSULATION RETAINER ASSEMBLY
Potterton part no. 315104
62   OBSOLETE THERMOSTAT KNOB RANCO
Potterton part no. 374646
62   OBSOLETE FUSE 3 AMP 1/4 X 1
Potterton part no. 640564
62   OBSOLETE CONTROL THERMOSTAT
Potterton part no. 404384
62   OBSOLETE CONTROL MODULE SERVICE KIT
Potterton part no. 90412501
74   OBSOLETE PUMP CIRCULATOR - MYSON SD52 - FLANGED
Potterton part no. 904887
83   OBSOLETE BURNER BAR AB12062A C70/2
Potterton part no. 414064
84   OBSOLETE HOLDER INJECTOR C/W NUT CAT
Potterton part no. 410186
86   OBSOLETE INJECTOR CAT 11 SIZE 505 BRA
Potterton part no. 410225
92 Part number 410209, PILOT INJ HONEYWELL BCR 18 PILOT INJ HONEYWELL BCR 18
Potterton part no. 410209
92   OBSOLETE PILOT ASSY Q314A 4834 R/H
Potterton part no. 905326
92 Part number 102041, INJECTOR PILOT.NG.BCR-18 INJECTOR PILOT.NG.BCR-18
Potterton part no. 102041
92 Part number 402492, SHR OFF UNION 6MM LG SHNK (STD SHR OFF UNION 6MM LG SHNK (STD
Potterton part no. 402492		 £5.88
93 Part number Q309A2788, THERMOCOUPLE THERMOCOUPLE
Potterton part no. Q309A2788		 £8.96
93 Part number 40225701, NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY NOW USE Q309A2788 THERMOCOUPLE 1000MM Q309/MTRL TY
Potterton part no. 40225701
105   OLIVE 6MM BORE
Potterton part no. 401624		 £2.95
105 Part number 700723, ALUMINIUM TUBE KIT 6MM OD ALUMINIUM TUBE KIT 6MM OD
Potterton part no. 700723
106   COMPRESSION NUT 1/8" BSP
Potterton part no. 401582		 £5.12
108   OBSOLETE PRES TEST NIPPLE 1/8 BSP
Potterton part no. 400988
154   OBSOLETE BRUSH FLUE 6 X 2 DIA X 24 LG
Potterton part no. 595012		 £4.68
161   OBSOLETE SHIELD INJECTOR FURIGAS
Potterton part no. 314380
161   OBSOLETE GAUZE ASSY FLAT TYPE
Potterton part no. 314383
161   OBSOLETE BURNER ASSY (FURIGAS, LINT RESISTANT)
Potterton part no. 904520
162   OBSOLETE BRNR INJ 3.0MM FURIGAS
Potterton part no. 410365
163   OBSOLETE PILOT E31/14 NG 6MM WHITE/RO
Potterton part no. 402469
163   OBSOLETE PILOT ASSY
Potterton part no. 905278
163   BRKT B TYPE L LH TARGET
Potterton part no. 410483
164   OBSOLETE INJECTOR PILOT NG 2033 NHT 2
Potterton part no. 905476
181   OBSOLETE GAS VALVE BOXED
Potterton part no. 402809
182   OBSOLETE KNOB - PLASTIC WHITE - WHITE ROGERS
Potterton part no. 904977
182   OBSOLETE POWER UNIT - WHITE ROGERS F144-0035
Potterton part no. 904976
182   OBSOLETE OPERATOR SOL D C/W PLUG 36C W
Potterton part no. 904975
182   OBSOLETE CONTROL GAS W/ROGERS REPL T K
Potterton part no. 40247301
183   OBSOLETE OPERATOR SOLENOID TRADELINE
Potterton part no. 904750
184   OBSOLETE REGULATOR PRESS V5306A/E HW
Potterton part no. 904751
185   OBSOLETE POWER UNIT
Potterton part no. 904752
